Page 1: Table Of Contents
Product Name: Rescue Winch Part #: 15028 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations Components and Specifications Installation and Use Maintenance, Cleaning, and Storage...
Page 2: Introduction
Introduction Thank you for purchasing a Guardian Fall Protection Rescue Winch. This manual User Information must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or Date of First Use: any applicable state agency.
Page 3: Product Specific Applications
Product Specific Applications Use of equipment in unintended applications may result in serious WARNING injury or death. Maximum 1 attachment per connection point. For all applications, the Rescue Winch MUST be used in combination with a tripod deemed compatible by a Competent Person, such as the Guardian Arc-O-Pod (part # 15030). Material Hoist: The Rescue Winch may be used to lift and lower materials and equipment.
Page 4: Components And Specifications
Two or more snap hooks or carabiners connected to each other. Components and Specifications #15028 #15027 Rescue Winch Tripod Adapter Bracket (sold separately). Materials: 3/16” galvanized steel cable & ABS housing. Materials: powder-coated steel. Cable length: 65’. Carabiner Winch Handle Cable (65’)
Page 5: Installation And Use
Installation and Use 1. Away from all fall hazards, set-up compatible tripod according to tripod manufacturer’s instructions. 2. Ensure selected installation location for corresponding tripod is free of any debris, loose materials, and slippery surfaces. Tripod installation location must meet all criteria specified in tripod manufacturer’s instructions.
Page 6: Maintenance, Cleaning, And Storage
Maintenance, Cleaning, and Storage If Rescue Winch fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair. Cleaning after use is important for maintaining the safety and longevity of Rescue Winch. Remove all dirt, corrosives, and contaminants from Rescue Winch before and after each use.
Page 7: Inspection Log
Inspection Log Date of First Use: __________________. Product lifetime is indefinite, as long as it passes pre-use and Competent Person inspections. User must inspect prior to EACH use. Competent Person other than user must complete formal inspection at least every 6 months. Competent Person to inspect and initial.
Page 8: Labels
Use trauma relief straps to reduce the effects of suspension trauma. Labels INSPECTION GRID Rescue Winch 90056 (Rev. A) Made in India Part #: 15028 Date of Manufacture: Working length: 65’ PRIOR to use, read and understand the manufacturer’s instructions included with the equipment at time of shipment from the manufacturer.
