Thermcraft LBO-24-10-10-1T-J14642/1A Instruction Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

APPRECIATES YOUR BUSINESS

We thank you for purchasing a Thermcraft, Inc. heat treating oven. Since

our establishment in 1971, Thermcraft, Inc. has manufactured reliable, high

quality, electric resistance and gas equipment. Our products are used in a variety

of applications both domestically and around the world.

For over 40 years, Thermcraft, Inc. has manufactured ovens and ovens to

comply with predetermined custom and industrial specifications. This oven has

been completely checked for mechanical and electrical compliance prior to

shipment.

We trust you have received your oven in acceptable condition and that

you will find it meets or exceeds your expectations and requirements.

Prior to installation and operation of your new Thermcraft, Inc. oven, we

strongly urge you to read this manual it its entirety and comply with all

instructions herein.

If you have any questions, feel free to contact us.

Sincerely,

Thermcraft, Inc.

3950 Overdale Road

Winston-Salem, NC 27117-2037, U.S.A.

Telephone (336) 784-4800

Fax (336) 784-0634

Email: tci@thermcraftinc.com

Web: www.thermcraftinc.com

100-340-726 A

Made in the U.S.A

Table of Contents

Need help?

Do you have a question about the LBO-24-10-10-1T-J14642/1A and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermcraft LBO-24-10-10-1T-J14642/1A

Page 1 APPRECIATES YOUR BUSINESS We thank you for purchasing a Thermcraft, Inc. heat treating oven. Since our establishment in 1971, Thermcraft, Inc. has manufactured reliable, high quality, electric resistance and gas equipment. Our products are used in a variety of applications both domestically and around the world.
Page 2: Table Of Contents
THERMCRAFT, INC. INSTRUCTION MANUAL CONTENTS Oven Specifications Inspection and Damaged Instructions Accessories Assembly Control Environmental Conditions Installation and Power Connection Operational Safety General Information Preventative Maintenance Thermocouple Enabling Cooling Replacement Parts List Oven Trouble-Shooting MSDS sheet Control System Operation Standard Configuration...
Page 3: Oven Specifications
OVEN SPECIFICATIONS Oven Type: Model #: LBO-24-10-10-1T-J14642/1A Serial #: Weight: 350 LBS Maximum Temperature: -150°C to +350°C Heater Type: Inconel covered air heaters Cooling: Liquid Nitrogen Incoming Power: Volts 208/230 Amps Watts 3000 Phase Hertz 50/60 Control System: Model #:...
Page 4: Inspection And Damaged Instructions
2.) INSPECTION AND DAMAGED INSTRUCTIONS INSPECTION Upon receipt of your new oven, inspect for visible exterior damage. Note and describe any damage found on the freight bill and file a claim with the carrier. Once unpacked, carefully inspect for concealed loss or damage on the unit itself, both the interior and exterior.
Page 5: Accessories
3.) ACCESSORIES / OPTIONS PURCHASED _X_ YES ___ NO LOAD PORTS QTY _2_ _X_ YES ___ NO VIEWPORT QTY _1_ _X_ YES ___ NO CRYOGENIC GAS INJECTOR QTY _2_ _X_ YES ___ NO EXHAUST PORT QTY _1_ _X_ YES ___ NO DOOR INTERLOCK SAFETY ___ YES _X_ NO...
Page 6: Assembly
Locate the thermocouple hole and carefully pull out the alignment pin. Carefully slide thermocouple into the hole, do not force. If any questions arise concerning assembly of the oven, please contact Thermcraft, Inc. at 336-784-4800.
Page 7: Control Environmental Conditions
5.) CONTROL ENVIRONMENTAL CONDITIONS Normal Operating Conditions Ambient temperature: 0 – 50°C Rate of change in temperature: 10°C/h or less Ambient humidity: 20-90% RH (no condensation allowed) Altitude: 2000m or less above sea level Maximum Effects from Operating Conditions Temperature effects 1.1.
Page 8: Installation And Power Connection
6.) INSTALLATION AND POWER CONNECTION After the above assembly procedures have been completed, the oven is ready for connection to incoming power as follows: Open the oven and remove the protective packing covering the heating elements. Consult an electrical professional and the NEC (National Electric Code) specifications to select wire size to adequately carry the line amperage shown in section 1.) Oven Specifications: Connect...
Page 9: Operational Safety
7.) OPERATIONAL SAFETY Safe operation of your new oven is mandatory. As manufacturer of your oven, we at Thermcraft, Inc. have adhered to all known safety standards and strongly suggest you install your oven in accordance with national electric and fire protection codes. Do not exceed the electrical and temperature rating printed on the oven rating plate.
Page 10 Avoid contact with any exposed heater coils / elements. Do not touch elements with bare hands or oily gloves. Contact Thermcraft, Inc. if unsure of the safety of the heating elements in the conditions you have observed. Only qualified electrical professionals should remove the upper and lower terminal covers of the terminal boxes.
Page 11: General Information
8.) GENERAL INFORMATION FOR TEST FRAME OVENS CAUTION! Failure to check thermocouple wiring and connection before initial start up could result in damage to the oven. INSPECTION Carefully inspect the oven upon its arrival for possible damage incurred during shipment. If damage is evident, immediately notify the carrier and file a claim.
Page 12 MOUNTING All ovens are supplied with slide mounting brackets. Before moving the oven, make sure the locking pins are engaged to prevent the slides from moving. The oven should only be moved via an overhead crane or fork truck using the supplied eyebolts on the top of the oven.
Page 13 OPERATION The conduit is permanently secured and the rear cover installed, apply power to the control system to test the oven's components. Then run the oven up to 200F to verify proper operation. CAUTION: Do not run up to maximum operating temperature until the control thermocouple has been positioned properly.
Page 14 AIR FLOW PATTERN An Oven Air Flow Pattern drawing for this oven is included in this manual. The exhaust is top and bottom with the inlet in the middle. The main plenum protects the working chamber from direct radiation from the heating elements. The secondary plenum adds turbulence and prevents the air from directly recirculating.
Page 15 REAR COVER LIGHT OVEN PORT (ON CENTER LINE) AREA (IF REQUIRED) DOOR SEAL INJECTOR FLOW LINES HEATER ELEMENT BLOWER MOTOR BLOWER WHEEL FLOW LINES FEED THROUGH AIR BAFFLE CHANNELS AIR FLOW ALL PLUMBING & ELECTRICAL ENTER @ FEED THROUGH NOTE: AIR FLOW FOR CONVENTIONAL OVEN IN TYPICAL MOUNTING POSITION...
Page 16: Preventative Maintenance
4. If applicable, check to ensure that all signal lamps light. REPLACEMENT PARTS is recommended that you obtain replacement parts from Thermcraft Inc. to insure that system safeguards are not compromised. Variations in component specifications could cause the equipment to be unsafe.
Page 17 FUSE REPLACEMENT Replace fuses with the same size and type as supplied. 1FU - Bussmann FNQ-R-3Y> (3.5 A, 600 V Dual element time delay fuse) 2FU, 3FU - Bussmann FNQ-R-1 (1 A, 600 V Dual element time delay fuse) 4FU - Bussmann FNM-1 Y. (1.25 A, 250 V Dual element time delay fuse) PORT PLUG MACHINING OPTION Port plugs can be purchased with or without a bore.
Page 18: Thermocouple
10.) THERMOCOUPLE A thermocouple is used to measure the voltage that is generated as the temperature increases. It provides an input signal for the control system that monitors the temperature of the heated chamber. At high temperatures, the elements within the thermocouple may undergo some oxidation or corrosion causing the signals to be read incorrectly by the control system.
Page 19 11.) ENABLING THE COOLING FUNCTION Thermcraft, Inc. does not enable the cooling function of your oven prior to shipment. Following are instructions to do so. To enable output 2A, access the configuration mode. Put in code, if any. Default is 2.
Page 20: Replacement Parts List
12.) REPLACEMENT PARTS LIST Description Item # Quantity Included HEATER ELEMENT A-7506 THERMOCOUPLE A-7502 FAN MOTOR FUSE CONTROL TRANS PRIMARY FUSE F2 – 3 CONTROL TRANS SECONDARY FUSE LN2 CONNECTION 850635K459...
Page 21: Oven Trouble-Shooting
13.) OVEN TROUBLE SHOOTING TROUBLE SHOOTING FOR FURNACE / OVEN PROBLEMS DAMAGED THERMOCOUPLE 2. THERMOCOUPLE PROBLEMS TEMPERATURE OVEN READING THERMOCOUPLE CIRCUIT UPSCALE THERMOCOUPLE CONTROL WIRING FAULTY TEMPERATURE THERNOCOUPLE READING WIRING DOWNSCALE REVERSED CHECK POWER/VOLTS AT BREAKER CHEK OPEN HEATER POWER/VOLTS CHECK CIRCUIT/ AMERAGE...
Page 22 14.) MSDS See attached documents Material Where used SVHC (SUBSTANCE BY WEIGHT OF PRODUCT %WT/WT) Marinite “I” U-Ports < .01% ( BNZ Materials) Marinite “I” Window Frame < .01% ( BNZ Materials) Marinite “I” Port Plugs < .01% ( BNZ Materials) Thick beige SG-70 Door Face...
Page 23: Control System Operation
15.) CONTROL SYSTEM OPERATION The temperature control system controls the amount of power to the resistive heating elements in order to achieve and maintain the desired temperature as measured through the control thermocouple. The temperature control system consists of the following: Setpoint temperature controller Solid state power controller or mechanical contactor Matching control thermocouple...
Page 24: Standard Configuration
16.) STANDARD CONFIGURATION Operator.SP Name Description Value Comments SPrHb Rate Limit Holdback Status OFF (0) RmpDis Ramp Rate disable SRLAct Rate Limit Active Status Rate Limit Complete SRLSta Status Hbkdis Holdback Disable SSEL Select SP1 to SP16 SP 1 (0) SP_1 Set point 1 ‐ SP_2 Set point 2 ‐ SP_L Set point 1 Low Limit ‐150.00 ...
Page 25 Config.INST Name Description Value Comments CtrL Control Type PID (0) Act Control Action REV (0) COOL Cooling Type LIN (0) Integral and Derivative Time titd Units SEC (0) dtyP Derivative Type PU (0) m‐A Manual Key Disable ENAB (0) r‐h Run/Hold Key Disable ENAB (0) PwrF Power Feedback Enable OFF NONE Fwdt Feedforward Type (0) ...
Page 26 Name Description Value Comments nSP Number of Set points available 2(1) nmTr Remote Tracking OFF (0) mTr Manual Track OFF (0) PrTr Programmer Track when in Reset OFF (0) nmPU Rate Limit Units PSEC (0) NONE nmt Remote Set point configuration (0) Config.HA Name Description Value Comments FX Comms Special Case Flags 0 id Module Identity CMS (7) ...
Page 27: Over-Temperature Controller Operation (If Applicable)
17.) OVER-TEMPERATURE CONTROLLER OPERATION Ovens equipped with this optional controller will have a complete independent control system, including a separate upper limit controller and a separate thermocouple. The over temperature controller is usually set 50°F higher than the oven chamber controller.
Page 28 Referenced Attachments Attachment DESCRIPTION Mechanical Overview Electrical Schematic Eurotherm Controller Manual Eurotherm High Limit Manual Marinite I MSDS Fiber Paper MSDS Mineral Wool MSDS SG-70 MSDS Rath REACH Statement ROXUL REACH Statement Fiberglass Door Gasket Product Information Change Log: 10/6/2014 Correction was made on SG-70 MSDS, corrected from The Lund Company to RATH 10/6/2014...
