Cryopak Contactless Temperature Logger Detailed User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Rev
1.2
CRYOPAK VERIFICATION TECHNOLOGIES, INC.
Contactless
Temperature
Logger

Advertisement

loading
Need help?

Need help?

Do you have a question about the Contactless Temperature Logger and is the answer not in the manual?

Questions and answers

Related Manuals for Cryopak Contactless Temperature Logger

Summary of Contents for Cryopak Contactless Temperature Logger

  • Page 1 CRYOPAK VERIFICATION TECHNOLOGIES, INC. Contactless Temperature Logger...
  • Page 2 E M P E R A T U R E O G G E R Detailed User Guide © Cryopak Verification Technologies, Inc. 120 Parkway Drive • PO Box 309 Buchanan • VA • 24066 • USA Phone 540.254.1433 • 732.346.9200 Ext.150 Fax 540.254.2433 •...

  • Page 3: Size And Dimensions

    • High accuracy • Waterproof pouch The new Contactless Temperature Logger, also known as just CTL, is now available for storage and transit temperature monitoring solutions. It is completely food safe with IP rating 65. CTL is an internal temperature sensor data logger with four alarm conditions, start /stop / refresh / status / RF connections buttons and much more.

  • Page 4: Product Code

    CTL Contactless Temperature Loggers are vulnerable to damage when contact with water takes place if the integrity of the sleeve has been compromised. Your CTL Contactless Temperature Logger is not to be subjected to a naked flame. Exposures to such conditions may damage the logger or possibly cause an explosion of the battery.

  • Page 5: Specifications

    Setup file can be downloaded from Google Play Store and Apple App Store. Mobile / tablet app will allow users to program the CTL Contactless Temperature Logger, change parameters (as needed), view data, export data into pdf and excel formats.
  • Page 6 Application features and calculate statistic parameters (max, min, avg, MKT, log duration, individual thermal zone durations) Show data in table and chart, generate report CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 7 Sending by email, share by messenger app (WhatsApp, Skype, Export mode Telegram) CTL - Contactless Temperature Logger Features → Internal temperature sensor, single use wireless data logger. → 30m LoS (Line of sight) range. → Product label specifying product code and serial number plus bar coded serial number according to QR Code.

  • Page 8: Minimum System Requirements

    Example: Cryopak RF-01 18:62:E4:3E:0E:89. According to the two permissions given through the initial part of app installation, app will create a ‘temp’ folder in internal shared storage of device that will contain all the downloaded PDF files of CTL Contactless Temperature Logger which are named with the serial number 18-62-E4-3E-0E-89.pdf.
  • Page 9 All LEDs Blink Together: Device is in Idle Mode (Not Started Yet). RF LEDs: Blink: Radio Module on but Device is not Connected to Application. Solid: Radio Module is on and Paired to Application. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 10 1.1. Download and install the CTL Contactless Temperature Logger from Google Play Store. (Figure 1.) Figure 1. Download and Install the CTL Contactless Temperature Logger application from Google Play Store. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 11 Connect with CTL Contactless Temperature Logger Application Launch the CTL Contactless Temperature Logger Application in your device you will see main page of application (Figure 2.). It will ask you for two permissions to be able to save your CTL downloaded data in a folder in internal shared storage of user`s device.
  • Page 12 Allow CTL application to have acces to files on the device for creating required folders and files in internal shared storage for reading and writing data. Figure 3.Application Asks for permission to have access to Photos, Media and files on device. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 13 1.4. Allow CTL application to have acces to the device`s location to be able to connect to the desired CTL Contactless Temperature Logger for programming or exporting recorded data (Figure 4.). Figure 4. Application asks for permission to have access to device`s location.
  • Page 14 Once permissions are allowed, the app will open and If the Bluetooth is not turned on it will ask to turn on Bluetooth so it can detect and connect to the CTL Contactless Temperature Logger. (Figure 5.) Figure 5. Application asks to turn on Bluetooth.
  • Page 15 Simple and Smart 1.6 Once Bluetooth is connected, the first page of application will appear and then application will be able to detect the online CTL Contactless Temperature Logger. (Figure 6.) Figure 6. First page of CTL Application. CTL- Contactless Temperature Logger detailed user guide version 1.2...
  • Page 16 (CTL, CGL, …) Desired one should be selected for any further activity. Figure 7. Application Detects the online CTL Contactless Temperature Logger and shows the device name and serial number. CTL- Contactless Temperature Logger detailed user guide version 1.2...
  • Page 17 Simple and Smart 1.8 Connect to the CTL Contactless Temperature Logger Click on the detected CTL Contactless Temperature Logger (e.g. Cryopak RF-01 18:62: E4:3E: 2F:B7). The application will open another page where the connected device information is shown (if the device is not connected yet it will be blank). Click on connect button to connect the CTL Contactless Temperature Logger with the device (Figure 8.).
  • Page 18 When the logger is successfully connected the GREEN and the ORANGE RF LEDs are on. All the information’s of that CTL Contactless Temperature Logger will appear on the screen (Figure 9). There are different buttons for different actions: • Connect: For manual connection. •...
  • Page 19 RF Timeout (sec) it will go to sleep mode. But in case that the user starts immediately by pressing the start button the CTL Contactless Temperature Logger will beep once and both LEDs will turn off then the Logger will start immediately by going to sleep mode.
  • Page 20 Once all the parameters are set as desired, click “Ok” to save and then click “Back” Figure 11. Device setup, Device setup tab to program the CTL Contactless Temperature Logger. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 21 C T L U S E R G U I D E Simple and Smart 1.12 Once the Start Program is pressed the CTL Contactless Temperature Logger will be programmed with the parameters set in the previous step (Figure.11). CTL application will show a pop-up message confirmation of successful programming return to its first page (Figure.13).
  • Page 22 C T L U S E R G U I D E Simple and Smart 1.13 Pop-Up message of successful programming. Figure13. Program confirmation pop-up for CTL Contactless Temperature Logger. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 23 GREEN LED will blink until the end of the logging trip. 1.16 Alarm The CTL Contactless Temperature Logger supports four alarm conditions, if temperature goes out of specification then corresponding LEDs will start flashing during logging or when stopped. Alarm...
  • Page 24 RF always On option activated there is no need to press the button), once logger is detected, press ‘connect’ and then press ‘download’ (Figure.14). Press Download Figure14. Download Logged data from CTL Contactless Temperature Logger. CTL- Contactless Temperature Logger detailed user guide version 1.2...
  • Page 25 Logger will beep until download finishes and status LED will flash, RF LED will be solid. Counter will display # of records downloaded Figure 15. Counter displays number of records downloaded. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 26 Simple and Smart 1.20 Export Data Once all the recorded DATA are downloaded and the CTL Contactless Temperature Logger stops beeping it will redirect to the EXPORT page. In Export page Select desired Report format, Details, Chart, Temp. Unit and 21 CFR 11 compliant format and then press EXPORT. There are three different type of reports: •...
  • Page 27 Share: User can directly email the generated report by providing Email address in “Email Address” field. Send to Mirador: Downloaded data can be transferred to Mirador Express as offline data, and report generation will be accessible through Mirador Express as well. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 28 Or immediately can be viewed and/ or exported in PDF or CSV format. Sample PDF • Details Brief - Chart Brief 21 CFR 11 Enabled Figure 17. Sample Report PDF Details Brief - Chart Brief and 21 CFR 11 Enabled. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 29 Simple and Smart • Details Full - Chart Brief (First Page) 21 CFR 11 Enabled Figure 18. Sample Report PDF Details Full - Chart Brief and 21 CFR 11 Enabled. (First page) CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 30 Simple and Smart • Details Full - Chart Brief (Second Page) 21 CFR 11 Enabled Figure 19. Sample Report PDF Details Full - Chart Brief and 21 CFR 11 Enabled (Second page) CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 31 Simple and Smart • Details Full – Chart Full (First Page) 21 CFR 11 Enabled Figure 20. Sample Report PDF Details Full - Cart Full and 21 CFR 11 Enabled (First page) CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 32 Simple and Smart • Details Full – Chart Full (Second Page) 21 CFR 11 Enabled Figure 21. Sample Report PDF Details Full - Chart Full and 21 CFR 11 Enabled (Second page) CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 33 C T L U S E R G U I D E Simple and Smart • Details Full – Chart Full 21 CFR 11 Disabled Figure 22. Sample Report PDF Details Full - Chart Full and 21 CFR 11 Disabled. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 34 L LED will start blinking LL (LOW LOW) enable Triggers raise an alarm when the temperature is lower than the LOW-LOW specification that has been recorded. The LL LED will start blinking CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...

  • Page 35: Warranty Information

    10.8 If the Product is returned outside the warranty period, a Traceability Certificate will be issued and charged regardless of the outcome of the test. 10.9 CVT will not pay for any performance tests undertaken by any outside organization, without prior approval. CTL- Contactless Temperature Logger detailed user guide version 1.2 Page...
  • Page 36 C T L U S E R G U I D E Recycling of electronic devices Some parts in products from Cryopak Verification Technologies consist of recyclable materials, but others should not be disposed of in household waste. To avoid pollution, we kindly ask you to adhere to national policies and regulations concerning waste disposal and recycling.
