HASHIMA HN-2880C Instruction Manual

Needle detector
Hide thumbs

Advertisement

Table of Contents

ＮＥＥＤＬＥ ＤＥＴＥＣＴＯＲ
ＨＮ－２８８０Ｃ
ＨＮ－２７９０Ｇ
ＩＮＳＴＲＵＣＴＩＯＮ ＭＡＮＵＡＬ
この度はハシマ製品をご購入頂き、誠に有難うございます。
本機の性能を生かし、安全に使って頂くために、ご使用前にこの取扱い
説明書を必ずお読み下さい。
お読みになった後は、必ず保管して頂き、必要に応じてお読み下さい。
首先，非常感谢贵公司购买我司的产品。
为了更好地了解本机的性能并能
使用说明书
在阅读完后，请妥善保管; 以备必要时阅读使用。
Thank you very much for having bought our products.
Don't fail to fulfill the matters that demand special attention mentioned
below so that you could put this machine to use for a long time with safety.
Don't fail to read the user's manual first of all before use.
Keep this user's manual with care and read it as occasion demands.
検
針
检
针
取 扱 い 説 明 書
使 用 说 明 书
機
机

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HN-2880C and is the answer not in the manual?

Questions and answers

Related Manuals for HASHIMA HN-2880C

Summary of Contents for HASHIMA HN-2880C

  • Page 1 検 針 機 检 针 机 ＮＥＥＤＬＥ ＤＥＴＥＣＴＯＲ ＨＮ－２８８０Ｃ ＨＮ－２７９０Ｇ 取 扱 い 説 明 書 使 用 说 明 书 ＩＮＳＴＲＵＣＴＩＯＮ ＭＡＮＵＡＬ この度はハシマ製品をご購入頂き、誠に有難うございます。 本機の性能を生かし、安全に使って頂くために、ご使用前にこの取扱い 説明書を必ずお読み下さい。 お読みになった後は、必ず保管して頂き、必要に応じてお読み下さい。 首先，非常感谢贵公司购买我司的产品。 为了更好地了解本机的性能并能 使用说明书 在阅读完后，请妥善保管; 以备必要时阅读使用。 Thank you very much for having bought our products. Don’t fail to fulfill the matters that demand special attention mentioned below so that you could put this machine to use for a long time with safety.
  • Page 2 Prior to use  Please read this manual carefully before using the HN-2880C・HN-2790G to get the best results and stay safe follow maintenance procedures and practice good safety.  Keep this user's manual treat it with care and read it as the occasion demands.
  • Page 3 Attentions to be paid for safety Don’t fail to fulfill. You should fulfill following explanations to prevent the user and the others from being hurt and the properties from being damaged. ■ We classify and explain the degrees of peril and damage to be taken place when you neglect the contents of the display and the machine erroneously.
  • Page 4 WARNING Don’t fail to disconnect such Install the machine in Pay sufficient attention to power source as the plug and the accordance with the the conveyors at the time setting breaker from the origin, designated way of installation. you inspect the needles. prior to the maintenance and inspection.
  • Page 5 By putting “alarm label” onto every part of the machine, we rouse you to prevent the user and others from being hurt and proprieties from being damaged. Ensure the position and contents in regard to the “alarm label” prior to the use. ...

  • Page 6: Prior To Use

    ＣＯＮＴＥＮＴＳ PRIOR TO USE ATTENTIONS TO BE PAID FOR SAFETY INSTRUCTION MANUAL FEATURES, USEFULNESS, SPECIFICATIONS,PRECATIONS FOR USE,PRECATIONS FOR INSTALLATION OPERATING INSTRUCTIONS IN REGARD TO NEEDLE DETECTIVE OPERATION MATTERS THAT DEMAND SPECIAL ATTENTION AT THE TIME OF NEEDLE DETECTION HOW TO ADJUST THE BELT POSITION...
  • Page 7 INSTRUCTION MANUAL...
  • Page 8 FEATURES : ○This machine is equipped with the LCD panel for checking the current detecting level． ○Position lamp identifies exact location of Fe materials so that you can find it easily． ○This machine has the “Key Switch” as standard equipment ,and this switch can lock various settings not to be changed.

  • Page 9: Specifications

    SPECIFICATIONS Model name HN-2880C HN-2790G Detection method Magnetic induction type Detection capacity Iron ball Fe0.8 mm or more (120 mm high) Sensitivity adjustment Decimal (100 steps) and direct reading (6 steps) Detection width ６００ｍｍ Detection height 120mm (standard) Warning device...

  • Page 10: Home Screen

    Operating instructions Set the date and time first. LCD Panel Start/Stop Switch Power breaker １．Turn on the power breaker. The system on the LCD panel starts and the HOME screen opens. ２．Year, month, day, hour, minute, and second are displayed at the top of the screen. ３．At least , year, month, day, hour, and minute should be adjusted to local time as precisely as possible.

  • Page 11: Main Screen

    ５．Touch "Date and time setting" on the MAIN screen. MAIN SCREEN Date and time setting ６．Touch the number to display the numeric keyboard. Enter the correct value using the numeric keypad and press ENT to change the value. ７．Touch Back to return to the MENU screen. ８．Touch Back to return to the HOME screen.
  • Page 12 How to use 1．Turn on the power breaker. The system on the LCD panel starts and the HOME screen is displayed. Explanation of the HOME screen ③ ② ④ ⑦ ① ⑨ ⑧ ⑤ ⑥ ①Start/Stop button・・ Start and stop the conveyor belt. ②MENU button・・・・Moves to the menu screen.
  • Page 13 Main menu ・M/C setting: Sets various modes. Sets year, month, day, hour, minute, and second. ・Date: Displays the history. ・History: Sets the counter. ・Counter: Set the sensitivity. ・Sensitivity: Register the administrator. ・Administration: Prints data. ・Printer: Sets Japanese, Chinese, and English. ・Language: Used for maintenance.
  • Page 14 1. Mode setting The test card mode or the production mode can be selected. * Set normally in production mode. The photoelectric sensor recognizes the product passing through the belt in the production mode. When the inspecting sensor detects a piece of iron, the belt stops and returns the product to the front.
  • Page 15 Adjustment of the belt speed (40 m/min.-15 m/min.) Touch the numeric value to display the numeric keyboard. Enter a value and touch the ENT key. The speed changes. ２．Date Set the year, month, day, hour, minute, and second. Touch the numeric value to display the numeric keyboard. Enter the correct value and touch the ENT key.
  • Page 16 ３．History NO. : 0 is the latest information. Event : shows either START, STOP, or DETECT. START: Press the Start button to display the time at which the meter reading starts. STOP: Press the Start button to display the time at which the meter reading stops DETECT - displays the time when DETECT - detection is performed and stopped.
  • Page 17 ４．Counter Indication of defective products, defective products, and total number. Set the number of loops. Printing counter quantity Photoelectric tube setting Loop Count Setting allows the User to set the number of times to restart automatically after detection. You can set the number of times between 1 and 999 (maximum). Photoelectric tube Set the minimum loading interval between the product and the product.
  • Page 18 ５．Sensitivity Displays either the straight-reading or decimal method selected in the device setting. Note: If you set the password, you cannot change the sensitivity without entering the password. - 15 -...

  • Page 19: Password Change

    ６．Pass word change password entry input: You can set the password for one administrator and three workers on the machine. Initial password administrator A 88888 Always ON state operator B 111111 OFF status operator C 222222 OFF status operator D 333333 OFF status The administrator can freely cancel and change the password of himself and three workers.

  • Page 20: Printing History

    ７．Printer You can print the following data 《Counter printing》 《Printing History》 《Printing auto-pre-checker results》 《Printing of environmental noise measurement results》 ８．Language You can switch the language to Japanese, English, or Chinese. - 17 -...
  • Page 21 ９．Inspection Check time／ms: Touch the numeric value to display the ten-key board. Enter a value and touch the ENT key. Belt return adjust／ms: Touch the numeric value to display the numeric keyboard. Enter a value and touch the ENT key. Prechecker : Place the pre-check bar in the conveyor loading unit before the metering operation.

  • Page 22: Production Mode

    IN REGARD TO NEEDLE DETECTIVE OPERATION: １．Consecutive detection of the needle is possible as it is designed to let the non-defective products pass through when you put the products to be detected in order onto the conveyor in rotation． ２．When the device has sensed such a material as the broken needle during the needle detective operation, the buzzer sounds and the belt conveyor stops and the defective products will be returned to your side.
  • Page 23 HOW TO ADJUST THE BELT POSITION 1. Take out the bothside covers. 2. Loose the fixing bolts(2pcs). 3. Use the hex wrench to turn the hex holed screw and adjust the roller position. - 20 -...
  • Page 24 〒578-0984 大阪府東大阪市菱江 1 丁目 28-28 TEL 072-961-8400 FAX 072-961-8404 海外拠点 ／ 昆山・シンガポール・インド・バングラデシュ・ベトナム 製造拠点 ／ 揖斐工場 ＵＦＬ http://www.hashima.co.jp BUSSINESS OFFICE : 7-6 RYOGE GIFU-CITY JAPAN TEL 81-58-247-8400,81-58-245-4501 FAX 81-58-240-5775 SINGAPORE OFFICE : TEL 65-2858131 FAX 65-2858132 CHINA OFFICE : TEL 86-51257771838 FAX 86-51257771848 ＵＦＬ...

This manual is also suitable for:

Hn-2790g
