Page 1 USER MANUAL - EN...
Page 2 Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 3: Table Of Contents
Table of Contents General Information General Precautions Restrictions Main Features Specifications Regulatory Standards Remote Control FCC, IC, CE & ARIB Battery Charger Lifting Procedure Working Angles Conformity Declaration & Manufacturer’s Certificate Warranty Inspection & Maintenance Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 4: General Information
It is the sole responsibility of the operator to ensure the correct manipulation and handling of any load while using any of the elebia official products. Automated processes in any lifting operation, whether attaching and/or releasing any load, or other, must always be submitted to visual inspection of the ope- rator.
Page 5: Restrictions
• Influences from acids/alkalines and chemicals The elebia automatic lifting clamps must not be exposed to acids/alkalines or their vapours, as certain production methods may release acids and/or vapours. Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 6: Main Features
Main Features of the elebia Automatic Lifting Clamps The automatic lifting clamps include a roller for chains or slings and a hand grip that can also be used as a second lifting point. Hand Grip Can be used as second lifting point...
Page 7: Specifications
Specifications 310 / 12.20 133 / 5.24 87 / 3.42 100 / 3.93 90 / 3.54 mm / inches Regulatory Standards Our Products certify with the following regulatory standards: ASME B30.10-2009 UNE-EN ISO12100:2012 Directive on Machine Safety (D2006/42/EC) ASME B30.20-2010 EN 10204 3.1.B UNE-EN 1050 D89/391/EEC...
Page 8: Remote Control
For more info on the eMAX remote control, please refer to the eMAX remote control user manual (downloadable from https://elebia.com/downloads/) The eMINI is a small and compact remote control. With the eMINI remote control, the operator can open and close the automatic lifting clamp and control its battery level.
Page 9: Fcc, Ic, Ce & Arib
Power Supply One 3V lithium battery (CR2032) Available Code Combinations 65,536 different combinations Detection of Errors in Transmission 2 CRC bytes + Forward Error Correction Buttons Frequency Selection Frequencies 865.95 MHz / 869.85 MHz Communication Bi-directional return of receiver battery status Radiated Power under 5 dBm Antenna...
Page 10: Battery
Battery The battery status is indicated by a 14 segment Eink display. The battery is fully charged when the 14 Eink segments are black, and as the battery discharges the segments turn white. The battery is completely discharged when all 14 Eink segments are white.
Page 11 Loading Procedure Operator must fix the lifting clamp on the load/cargo. Operator must lock the lifting clamp by use of the eMINI remote control / rigger button. Operator must confirm with visual inspection that all lifting clamps are blue in the LED Status Indicator. Crane operator confirms the locked status of the lifting clamps in the eMAX remote control.
Page 12 Release Procedure Place load on a horizontal surface. Signal operator unlocks lifting clamps by use of the eMINI remote control. Signal operator confirms with visual inspection that all lifting clamps are green in the LED Status Indicator. Crane operator confirms the unlocked status of the lifting clamps in the eMAX remote control.
Page 13: Working Angles
Working Angles Each element that conforms the load must be correctly placed on the automatic lifting clamp and firmly positioned at the end of the jaw opening. Clamps must be used in pairs (or múltiples thereof ). Make sure load is always balanced. Disclaimer: This user manual is for information only.
Page 14 Working angles must not exceed the maximum top angle as described in figures below 30º 30º Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 15 Do not lift item/load that may deflect/sag Do not lift items of circular or uneven form/shape Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 16 Do not lift item/load that is pinned to any surface Do not lift item/load over people. Make sure people are, and remain, outside of the area of any sustained load Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
Page 17: Conformity Declaration & Manufacturer's Certificate
Conformity Declaration and Manufacturer’s Certificate ELEBIA AUTOHOOKS, S.L.U., with registered office at Plaça Pere Llauger Prim, naus 10-11, Polígon Indus- trial Can Misser, 08360, Canet de Mar, (Barcelona), Spain, Tax Identification Certificate B65770265, and ISO 9001 certificate No. 9000041 DECLARES: Under its sole responsibility, that the following Automatic Lifting Clamp, with serial number ___________________, with a maximum operating load of 5,000 kg., complies with the EC Machinery...
Page 18: Warranty
At least once a year, or in case of any damage to the clamp, the clamp should be inspected, tested and if necessary returned to Elebia Autohooks SLU Technical Service for review. The frequency of inspections and tests may vary according to the intensity and type of use.
Page 19 Maintenance Check Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
