- Page 1 VNI-WS15 DP3425/Rev01b - DI Wall bracket for GEOM6 / LS600 / PS15 Contents: X1 (Arm) X1 (Adapter) Weight: 2.8 kg / 6.2 lb - Read t his docum ent before using. - Keep t his docum ent . - Observe all warnings and caut ions.
- Page 2 Dimensions: Adapter mounting • Connect the VNI-WS15 adapter to the • Remove 2 screws from the LS600 / PS15 and use the 2 screws and the 2 washers GMT-LBUMP by using the M6x20 provided with the GMT-LBUMP provided to fix the adapter.
- Page 3 Tilt in vertical position with PS15 - Read t his docum ent before using. - Keep t his docum ent . - Observe all warnings and caut ions. PAGE 3 OF 4...
- Page 4 Adapter / Arm mounting For the wall mount of VNI-WS15, please select screws and mounting location supporting 4 times the system weight. Tighten well to cancel any float between the arm and the adapter. Safety device !! Use the parts provided •...
