  • Page 1 9468-ET 10/100Mb Ethernet Isolator Instruction Manual INM9468...
  • Page 2: Table Of Contents

    CoNteNts FeAtURes ............1 DesCRIPtIoN .
  • Page 3: Features

    9468-et - ethernet Isolator INM9468-2 May 2010 FeAtURes ♦ Intrinsically Safe ATEX / IECEx certified ♦ FM / FMC approved ♦ Ga Ex ia IIC T4 GD (surface), Ma Ex ia I M1 (mining) ♦ Zone 2 / Safe Area mounting with Hazardous Area connections into Zone 1 and 0.
  • Page 4: Description

    DesCRIPtIoN The 9468-ET 10/100Mbps Ethernet Isolator allows the interconnection of a Zone 2 or un-certified Safe Area device to the Intrinsically Safe 9400 series of Ethernet networking products, operating in the Hazardous Area. The isolator provides a compact alternative solution to fibre optic cable and media converters and for when it is desirable to use Cat5e cables in preference to fibre.
  • Page 5 3.3. electrical connections 3.3.1 screw terminals 14 15 terminal No. Function +20...30V dc in +20...30V dc in 5–13 No connection Supply in +12V - PoEx † Supply in 0V - PoEx † Note: Terminal pairs 1+2 and 3+4 are linked internally. †...
  • Page 6: Label Marking

    Zone 2 hazardous area. Tick (check) boxes Note: When a 9468-ET isolator has been used in (and marked for) a safe area, it may NOT be used in future in a Zone 2 hazardous area.
  • Page 7: Approvals

    † (for guidance on the Gc, nLc & nAc marking) * (see specification for operating temperature range) FM CeRtIFICAtIoN INFoRMAtIoN special Condition of Use - Factory Mutual (UsA & Canada) 1. The Model 9468-ET shall be installed in compliance with the enclosure, mounting, spacing and segregation requirements of the ultimate application. AteX & IeCex CeRtIFICAtIoN INFoRMAtIoN...
  • Page 8 The ‘nLc’ ‘nAc’ certified 9468-ET 10/100 Ethernet Isolator module shall be installed in an ATEX Component Approved Ex ‘e’ enclosure that provides a level of protection appropriate for its intended environment of use.
  • Page 11 INM9468-2 May 2010...
  • Page 12 Tel: +39 (0)2 61802011 Fax: +39 (0)2 61294560 3413 N. Sam Houston Parkway W. E-mail: info@mtl-inst.it Suite 210 Houston TX 77086 Tel: +1 281 571 8065 Fax: +1 281 571 8069 E-mail: csinfo@mtl-inst.com Group Internet home page http://www.mtl-inst.com/ Members of The MTL Instruments Group...
