Clas Ohlson OXP-3B Instruction Manual

8/18 m Wall Mountable Cable Reel
Art.no 36-5570
36-5571
Please read the entire instruction manual before using the product and then save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our customer services.
Safety
• The cable reel needs to be mounted close to a wall
socket and with enough room for it to swivel round.
• Mount the cable reel out of children's reach.
• If the clicking sound stops when you are unwinding
the cable, it means that you have unwound it to
the maximum length. Let a little of the cable reel wind
back onto the reel until it locks in place.
• Do not overload the cable reel.
• Hold onto the cable whilst it is winding back onto
the reel to prevent any injuries.
• If the thermal protection has triggered, let the cable
cool before resetting it.
• If the cable does not reel in completely, pull it all
the way out and try again.
• Do not use the cable reel if the cable or any other part
of the product is damaged. Repairs must be carried
out by a qualified tradesman or workshop.
• Make sure that the electrical socket that the product
is plugged into is easily accessible in case it
and the connected product need to be quickly
disconnected from the mains electricity.
• Do not connect products of this type to each other.
• Do not cover the product.
Installation
The cable reel should be mounted onto a wall using
appropriate screws for the material and bearing capacity
of the wall.
Specifications
36-5570
Max load Wound 1400 W, unwound 2000 W
Cable H05VV-F 3G1.5 mm²
Total
cable length 10 m (8 + 2 m)
250 V. IP20.
UNITED KINGDOM • CUSTOMER SERVICE
tel 020 8247 9300 internet www.clasohlson.co.uk e-mail customerservice@clasohlson.co.uk
postal 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
Model OXP-3B
OXP-28B
Operating instructions
1. Plug the cable reel into a wall socket. The LED will
come on.
2. Unwind the desired length of cable; there is a clicking
sound when the cable is being unwound.
3. Release the cable to fix the desired length.
4. After use, pull the cable lightly and let it rewind
automatically onto the reel.
If the thermal protection has triggered:
1. Unplug the cable reel from the wall socket.
2. Allow the product to cool to room temperature.
3. Push the red button to reset it.
4. Plug the cable reel back into a wall socket – the LED
should come on again.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any
harm to the environment or health hazards
caused by incorrect waste disposal,
the product must be handed in for recycling
so that the material can be disposed of in
a responsible manner. When recycling your
product, take it to your local collection facility
or contact the place of purchase. They will
ensure that the product is disposed of in
an environmentally sound manner.
36-5571
Max load Wound 1000 W, unwound 3500 W
Cable H07RN-F 3G1.5 mm²
Total
cable length 20 m (18 + 2 m)
230 V. IP44.
