Usage and Maintenance Instructions
Introduction
Your new digital blood pressure monitor uses the oscillometric method of blood pressure measurement.
This means the monitor detects your blood's movement through your brachial artery and converts the
movements into a digital reading. An oscillometric monitor does not need a stethoscope, so the monitor
is simple to use.
This automatic blood pressure monitor could measure the systolic pressure, diastolic pressure and pulse,
the components include the body, cuff and printed instruction manual. Batteries and adapter are optional.
This unit is intended for adult use.
Intelligent inflation will reduce the uncomfortable feeling caused by incorrect inflation, and shorten the
measurement time, prolonging the cuff's usage lifetime. 2*120 sets memory function, each measurement
result will be displayed on the screen, and automatically stored .This unit has blood classification index
and can easily check your blood pressure. Please read the manual carefully before you use the unit, and
keep the manual safe after using.
Statement
•
The intended use: the unit is intended to be used by adults at home or medical centers to measure
blood pressure and pulse rate from the upper arm.
•
The unit satisfies the requirements of EN 1060-1: 1995+A2 2009 Non invasive sphygmomanometers,
EN 1060-3: 1997+A2: 2009 Non-invasive sphygmomanometers.
•
Blood pressure measurements determined with this device are equivalent to those obtained by a
trained observer using the cuff/stethoscope auscultatory method, within the limits prescribed by the
American National Standard, manual, electronic, or automated sphygmomanometers.
•
The risk of patient and user can be lowered to an acceptable level.
CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Digi Blood Pressure Monitor - DL08146
www.careco.co.uk
1
Advertisement
Table of Contents
Summary of Contents for CareCo DL08146
- Page 1 Usage and Maintenance Instructions Digi Blood Pressure Monitor - DL08146 Introduction Your new digital blood pressure monitor uses the oscillometric method of blood pressure measurement. This means the monitor detects your blood’s movement through your brachial artery and converts the movements into a digital reading.
- Page 2 Digi Blood Pressure Monitor - DL08146 Specification Arm type automatic blood pressure monitor Description LCD digital display Display Oscillometric method Measuring Principle Upper Arm Measuring Localization Pressure 0-299 mmHg (0-39.9kPa) Measurement Range Pulse 40-199 pulses/min Pressure ±3mmHg (±0.4kPa) Accuracy Pulse ±5% of reading...
- Page 3 Digi Blood Pressure Monitor - DL08146 To assure the correct use of the product, basic safety measures should always be followed. Symbol Descriptions The following symbols may appear in this manual, on the label, on the device, or on it’s accessories.
-
Page 4: Safety Information
Digi Blood Pressure Monitor - DL08146 Safety Information • Those who have arrhythmia, diabetes, blood circulation or apoplexy problem, please use under a physician’s instruction. • Contact your physician for specific information about your blood pressure. Self diagnosis and treatment which use measured results may be dangerous. Follow the instructions of your physician or licensed healthcare provider. - Page 5 Digi Blood Pressure Monitor - DL08146 Error Indicators The following symbol will appear on the display when measuring abnormal activity. Symbol Cause Correction Wrap the cuff properly. Weak Signal or pressure change suddenly. Remeasure the correct way. When near a mobile phone or other high radiant the measurement will fail.
-
Page 6: Memory Button
Digi Blood Pressure Monitor - DL08146 Memory Button LCD Display START/STOP Button Time Button Cuff Socket The accessories cuff is M size, for upper-arm circumference 22-32cm use. The cuff is treated as the applied part. AC/DC Socket Insert the connector with cuff tube into the hole which is on the left side of the device as picture. -
Page 7: Battery Installation
Digi Blood Pressure Monitor - DL08146 Memory - clear of measurements If you are sure that you want to permanently remove all stored memories. Press the button until it is shown CL, after this press button then all the records will be cleared. - Page 8 Digi Blood Pressure Monitor - DL08146 Adapter usage (option) 1. Optional AC adapter should comply with the requirement of IEC 60601-1 :2005. Furthermore all configurations shall comply with the requirements for medical electrical systems (see IEC 60601- 1-1 or clause 16 of the 3Ed. of IEC 60601-1, respectively). Anybody connecting additional equipment to medical electrical equipment configures a medical system and is therefore responsible that the system complies with the requirements for medical electrical systems.
- Page 9 Digi Blood Pressure Monitor - DL08146 Measuring procedure: After the cuff has been appropriately positioned, the measurement can begin: 1. Press the START/STOP button, all symbols appear on the display, you can hear 2 short beeps after 0 flashes for 2 seconds, then the pump begins to inflate the cuff, the rising pressure in the cuff is shown on the display.
-
Page 10: Setting Mode
Digi Blood Pressure Monitor - DL08146 Fitting the cuff 1. Put the cuff on a table flatly with the velcro side down. Pass the end of the cuff through the metal loop so that a circle is formed. The velcro fastening will now be facing outwards (ignore this step if the cuff has already been prepared) . -
Page 11: Unit Setting
Digi Blood Pressure Monitor - DL08146 How to set Start to year: Press button when you power on , the year will be flashing, and then use button to set year, press button to confirm the year. Month and date setting... - Page 12 Digi Blood Pressure Monitor - DL08146 Common factors of wrong measurement • All efforts by the patient to support their arm can increase blood pressure. • Make sure you are in a comfortable, relaxed position and do not activate any of the muscles in the measurement arm during measurement.
