LeCroy MSO-MICTOR Manual

OVERVIEW

Included with the MSO-MICTOR cable shipment are the following:
•
Qty 1 - 36 channel Mictor cable
•
Qty 1 – MSO-MICTOR Instruction sheet (this document)
•
Qty 1 - Mictor Connector Shroud.
Note: Additional shrouds can be purchased in a 3 pack. The LeCroy part number is MSO-MICTOR-
SHROUD.

OPERATING ENVIRONMENT

Before using the MSO-MICTOR cable, ensure that its operating environment will be maintained within
these parameters:
Temperature:
Humidity:

SAFETY REQUIREMENTS

CAUTION
To avoid personal injury or damage to the MSO-MICTOR or any equipment connected to it, review and
comply with the following safety precautions.
•
Use only as intended. The MSO-MICTOR cable is intended to be used only with LeCroy MS-250,
MS-500 or MS-500-36 Mixed Signal Oscilloscope options. Use of the MSO-MICTOR and/or the
equipment it is connected to in a manner other than specified may impair the protection mechanisms.
•
Connect and disconnect properly. Avoid damage to cables thru excessive bending. When
disconnecting the MSO-MICTOR cable from the MS-250, MS-500, MS-500-36 or Device Under Test
NEVER pull on the blue wires, pull only the black plastic housing.
•
For indoor use only. The MSO-MICTOR cable and associated test equipment is intended for indoor
use and should be operated in a clean, dry, environment.

BASIC OPERATION

Connecting the MSO-MICTOR to the MS-500 or MS-500-36

•
Connect the end of the cable labeled D0 – D17 to the corresponding input of the MS-500 or MS-
500-36 labeled D0 – D17 and fasten thumb screws
•
Connect the end of the cable labeled D18 – D35 to the corresponding input of the MS-500 or MS-
500-36 labeled D18 – D35 and fasten thumb screws

Connecting the MSO-MICTOR to the Device Under Test

•
The MSO-MICTOR cable mates with the Tyco Electronics Pb free part# 2-5767004-2 Mictor
connector.
Looking into Mictor Connector:
Connector Pin #
Connector Pin #
915668-00 Rev A
1.800.561.8187
o
5 to 40
< 80% RH (non-condensing)
2 4 6 8 10 12
D35 NC D34 D33 D32 D31 D30 D29 D28 D27 D26 D25 D24 D23 D22 D21 D20 D19 D18
D17 Gnd D16 D15 D14 D13 D12 D11 D10 D9
1 3 5 7 9 11
MSO-MICTOR Instruction Sheet
www.
C
14 16 18 20 22 24
D8 D7 D6
13 15 17 19 21 23
.com
26 28 30 32 34 36
D5 D4 D3 D2 D1 D0
25 27 29 31 33 35
Page 1 of 2
