Sercel VE432 DPG Installation & Reference Manual

Software version 3.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

VE432 DPG
Installation
& Reference
MANUAL
Software version 3.0
Issue : April 1999
Documentation No. 0311385

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VE432 DPG and is the answer not in the manual?

Questions and answers

Summary of Contents for Sercel VE432 DPG

  • Page 1 VE432 DPG Installation & Reference MANUAL Software version 3.0 Issue : April 1999 Documentation No. 0311385...
  • Page 2 SERCEL has been advised, or knew or should have known of the possibility of such damages.

  • Page 3: Table Of Contents

    Table Of Contents INTRODUCTION -------------------------------------------------------------------------------------------------- 1-1 GENERAL DESCRIPTION ------------------------------------------------------------------------------------1-1 SPECIFICATIONS -----------------------------------------------------------------------------------------------1-5 UNPACKING-------------------------------------------------------------------------------------------------------1-6 CONNECTING A DPG ------------------------------------------------------------------------------------------ 2-1 DPG MOUNTING DIMENSIONS-----------------------------------------------------------------------------2-1 DPG STANDARD CONNECTIONS -------------------------------------------------------------------------2-2 1 APM, 1 DPG -------------------------------------------------------------------------------2-4 CONFIGURATION 3 APM , 1 DPG ----------------------------------------------------------------------2-5 CONFIGURATION 8 APM 4 DPG --------------------------------------------2-6 ONFIGURATIONS WITH UP TO S AND UP TO...
  • Page 4 USING VE432 WITH A RECORDING SYSTEM OTHER THAN SERCEL ----------------------- 5-1 -------------------------------------------------------------------------------------------5-1 ONNECTION DIAGRAM --------------------------------------------------------------------------------------5-2 ISTINCTIONS TO BE MADE TOOLSVEHCI SOFTWARE LOADING UTILITY-------------------------------------------------------- 6-1 DSD --------------------------------------------------------------------6-1 OADING SOFTWARE TO A GROUND VISCOSITY AND STIFFNESS ----------------------------------------------------------------- 7-1 CONVERSION TO NORMALIZED UNITS ----------------------------------------------------------------7-1...

  • Page 5: Introduction

    INTRODUCTION GENERAL DESCRIPTION INTRODUCTION GENERAL DESCRIPTION General The VE 432 is a new generation of Vibrator Digital Control System, using a fully auto- adaptive servomechanism. It enables the use of all advanced Vibroseis techniques such as : - pseudo-random sweeps - multiple simultaneous sources in flip-flop or slip-modes - coded sweeps - cascaded...
  • Page 6 INTRODUCTION GENERAL DESCRIPTION Digital Pilot Generator (DPG) The DPG is connected to the data acquisition system through an Ethernet link and acts as a master control unit for the VE 432 system. The DPG can be : - fully integrated with the SN 388 acquisition system, - or connected to any other type of acquisition system, using its own graphic user interface.
  • Page 7 • • Slip-Sweep* capability With a recording system from SERCEL, there is no need to wait until a sweep is complete to start the next one. (* The Slip-sweep technique, developed by PDO, allows substantial production increase to be achieved).
  • Page 8 INTRODUCTION GENERAL DESCRIPTION • • Recording system’s automatic start of acquisition With a recording system from SERCEL, acquisition by the recording system can be automatically started as soon as the vibrators are ready, using the DSD Ready signal via radio.

  • Page 9: Specifications

    INTRODUCTION SPECIFICATIONS SPECIFICATIONS Signal length : up to 64 s in 1-s steps. Frequency vs. time law : linear, logarithmic, pseudo-random, T , Pulse, user- defined. Frequency range : 1 to 250 Hz in 1-Hz steps. Amplitude vs time law : linear interpolation.

  • Page 10: Unpacking

    (depending on the configuration to be implemented): - Digital Pilot Generator: DPG. - Accessory set. - Digital Servo Drive: DSD (See DSD Installation manual). The VE432 DPG is composed of: a DPG unit (1717075017) including: a DVP board (1717074848) an SAPG board (1717074645)
  • Page 11 INTRODUCTION UNPACKING The accessory set (1718075433) is composed of - a CCU388 software package (1A11072510) - a palmtop computer case (747076405) - a HUSKY palmtop computer (317076033) - a Husky/DSD cable (1718076053) - a Husky/DSD extension cable (1718076123) - a red banana jack (5110011) - a black banana jack (5110065).
  • Page 12 INTRODUCTION UNPACKING 0311385 Issue : April 1999...

  • Page 13: Connecting A Dpg

    CONNECTING A DPG DPG MOUNTING DIMENSIONS CONNECTING A DPG DPG MOUNTING DIMENSIONS Approx. 20 All dimensions in mm 0311385 Issue : April 1999...

  • Page 14: Dpg Standard Connections

    CONNECTING A DPG DPG STANDARD CONNECTIONS DPG STANDARD CONNECTIONS RECORDER (to recording system) COM 1 HI. LINE (to palmtop computer) COM 2 power Radio Fuse GROUND ANALOG PILOTS wing nut PILOT 1 PILOT 2 RETURN PILOT RETURN SWEEP ETHERNET 0311385 Issue : April 1999...
  • Page 15 CONNECTING A DPG DPG STANDARD CONNECTIONS Palmtop computer (Up to 4 DPGs) (Recorder) Recording RDYOUT System VE432 Analog Pilots (See examples Radio Radio of possible Ethernet configurations on next pages) FO : Start order from recording system (either contact closure or voltage pulse).

  • Page 16: Apm, 1 Dpg Configuration

    CONNECTING A DPG 1 APM, 1 DPG configuration 1 APM, 1 DPG configuration CAMERA Ω SQC-Pro READ CAMERA SCSI SN 388 APM M / S BLASTER Ω RECORDER POWER POWER ANALOG (110/220 V) RADIO Pilots to RADIO Analog Pilots: PILOTS 1 to 4 + Return Pilot + Return Sweep (1) RECORDER cable (part No.

  • Page 17: 2 Or 3 Apms, 1 Dpg Configuration

    CONNECTING A DPG 2 or 3 APMs, 1 DPG configuration 2 or 3 APMs, 1 DPG configuration CAMERA MMCI4 POWER (+12 V) Ω READ CAMERA SCSI SCSI CAMERA APM1 (master) APM2 (slave) M / S BLASTER M / S BLASTER M/S terminator (use this connector to connect a third APM if required)

  • Page 18: Configurations With Up To

    (3) APM BLASTER MMI-8 cable 1A13077599A (4) DPG RECORDER MMI-8 cable 1A13077598A (5) ANALOG PILOTS cable see VE432 DPG kit (6) 14-19 plugs, M/S terminator 1A13072560 (with A wired to S, J wired to K) (1), (2), (3), (4), and (6) contained in...

  • Page 19: Dpg

    CONNECTING A DPG Configurations with up to 8 APMs and up to 4 DPGs Description of the links between the different modules (when using an MMI-8 box) (1) M/S cable (14-19S / 14-19S) Used to connect the APM modules together. A plug with pin A wired to S, and J wired to K (M/S terminator) needs to be connected to any unused M/S MMI-8 connector on the MMI-8 box.
  • Page 20 CONNECTING A DPG Configurations with up to 8 APMs and up to 4 DPGs The sweeps then start automatically as soon as the vibrators are ready and a minimum delay has elapsed after the start of the previous sweep. This minimum time is “Slip time”...

  • Page 21: Connecting Ahusky Terminal To Adpg

    CONNECTING A DPG Connecting a HUSKY terminal to a DPG Connecting a HUSKY terminal to a DPG Master DPG With a HUSKY terminal connected to a master DPG (on the COM 1 connector), two menus are available on the terminal: - RADIO LEVEL which allows you to set up the radio output level of the DPG (this set-up is also accessible from the SN388 HCI).

  • Page 22: Dpg Master/Slave Configuration

    CONNECTING A DPG DPG Master/Slave configuration DPG Master/Slave configuration It may be desirable to use two recording trucks in parallel, for example because of geographical considerations. One recording truck is used as "Master" and the other as "Slave". Each recording truck is equipped complete with an acquisition system and a DPG. One of the recording trucks is used as "Master"...
  • Page 23 CONNECTING A DPG DPG Master/Slave configuration After the sweep is complete, the Slave DPG sends a status message to the Master DPG which relays it to the SN388 HCI. That status is like those usually returned by DSDs, with an extra specific code (26) if the Slave acquisition system fails to start. That type of error can be detected by monitoring the RDYIN signal, low during acquisition, high otherwise (pins P and R of the RECORDER connector).
  • Page 24 CONNECTING A DPG DPG Master/Slave configuration 0311385 Issue : April 1999 2-12...

  • Page 25: Output Signal Specifications

    CONNECTING A DPG OUTPUT SIGNAL SPECIFICATIONS OUTPUT SIGNAL SPECIFICATIONS • • ANALOG PILOT connector: ± 2 V, differential output PILOT 1 ± 2 V, differential output PILOT 2 ± 2 V, differential output PILOT 3 ± 2 V, differential output PILOT 4 RETURN SWEEP Same level as DSD:...
  • Page 26 CONNECTING A DPG OUTPUT SIGNAL SPECIFICATIONS • • Sweep Start timing diagram × 390 Radio delay F. O. status DSD 2 Sweep DSD 1 200 ms 40 ms F. O. = Start order from recording system = number of T0 DATA frames (T0 Repeat Times parameter) specified in the T0 Time Setup on the HCI = approx.

  • Page 27: Recorder Cable

    CONNECTING A DPG RECORDER cable RECORDER cable (Cable part No. 1717075949) VE432 DPG SN388 14-19S plug 14-19S plug CLK IN 16-26S plug FO PULSE RDYIN RDYOUT EXT_GO EGOIN TBIN RDYOUT RDYIN Not used EBLAST Not used 14-19S plug Part No. 5010952 14-19S plug Part No.

  • Page 28: Analog Pilot Cable

    CONNECTING A DPG ANALOG PILOT cable ANALOG PILOT cable (Cable part No. 1717075950) 12-14S plug Part No. 5011210 Banana plug Part No. 5110003 (red) 5110053 (black) 12-14S plug solder side 0311385 Issue : April 1999 2-16...

  • Page 29: Radio Cable

    CONNECTING A DPG RADIO cable RADIO cable (Cable part No. 1717075948) 10-6s plug Part No.5010887 0311385 Issue : April 1999 2-17...

  • Page 30: Dpg Connectors

    CONNECTING A DPG DPG CONNECTORS DPG CONNECTORS RECORDER connector Connector Type: 14-19P RECORDER Signal Name CLKIN1 CLKIN2 FO_PULSE+ FO_PULSE- GND1 RDY_OUT1 RDY_OUT2 EXT_GO1 EXT_GO2 RDY_IN1 RDY_IN2 RES_IN1 RES_IN2 not connected not connected FO PULSE input: Input level: FO_PULSE+ 1.5 to 20 V 470 Ω...
  • Page 31 CONNECTING A DPG DPG CONNECTORS ANALOG PILOTS connector Connector Type: 12-14N PILOT Signal Name PILOT1- PILOT2- PILOT3- PILOT4- RETURN-PILOT- RETURN-SWEEP- AGND2 AGND1 RETURN-SWEEP+ RETURN-PILOT+ PILOT4+ PILOT3+ PILOT2+ PILOT1+ COM 2 connector Connector Type: DB9P COM2 Signal Name Not used Not used LGND Not used Not used...
  • Page 32 CONNECTING A DPG DPG CONNECTORS RADIO connector Connector Type: 10-6P RADIO plug Signal Name not connected not connected ⇔ DPG) COM 1 connector (palmtop computer⇔ Connector type: 12-10P HUSKY-DPG plug Signal Name not used not used Charger In HI-LINE connector Input should be (twisted pair) greater than...

  • Page 33: Software Installation

    SOFTWARE INSTALLATION SOLARIS INSTALLATION OR RE-INSTALLATION SOFTWARE INSTALLATION SOLARIS INSTALLATION OR RE-INSTALLATION Check the version on your SOLARIS CDROM : SOLARIS V2.5 or 2.5.1. NOTE: for an ULTRA 5 station, SOLARIS 2.5.1, HW 11/97 is required. • Insert the SOLARIS CDROM into the drive. •...
  • Page 34 SOFTWARE INSTALLATION SOLARIS 2.5 INSTALLATION OR RE-INSTALLATION •In the "IP address" window shows up : - Click in the text box - Type 150.10.128.1 - Click "Continue" • In the "Confirm Information" window : - Click "Continue" if the configuration information you entered is correct (or click Change if required).
  • Page 35 SOFTWARE INSTALLATION SOLARIS INSTALLATION OR RE-INSTALLATION • In the "System Type" window, standalone should be activated (by default). - Click "Continue". •In the "Software" window. should be activated (by default). End user system support - Click "Customize" - In the "Customize Software" window : .
  • Page 36 SOFTWARE INSTALLATION SOLARIS 2.5 INSTALLATION OR RE-INSTALLATION • In the "File system and Disk Layout" window : - Click "Customize" - In the "Customize Disks" window : . Double-click in the text box shown below /export/home and press CUT on the keyboard to clear the value in the text box .
  • Page 37 SOFTWARE INSTALLATION SOLARIS INSTALLATION OR RE-INSTALLATION • In the "Mount Remote File Systems ?" window, click "Continue". • The selected configuration is displayed in the "Profile" window : Installation option Initial System Type Standalone Software End User System Support - Including Point-To-Point protocol Terminal Information File System and Disk Layout...

  • Page 38: Year 2000 Patch

    SOFTWARE INSTALLATION YEAR 2000 PATCH YEAR 2000 PATCH WARNING: Installing the Year 2000 patch for Solaris may take some 10 hours. If you need to install the Year 2000 patch, follow the procedure below. At the hci388 console login prompt type root ↵ This causes the # # prompt to appear.

  • Page 39: Ve432 Standalone Installation

    SOFTWARE INSTALLATION VE432 STANDALONE INSTALLATION VE432 STANDALONE INSTALLATION (For use with recording system other than SN388) Prerequisite :Prior to installing SERCEL software, reboot the workstation (at the # prompt, type reboot <RETURN>). • Insert SERCEL CDROM into the drive. HCI STATION'S PROMPT YOUR ENTRY root ↵...

  • Page 40: Getting Started

    SOFTWARE INSTALLATION GETTING STARTED GETTING STARTED After power-on, wait for the Unix automatic startup procedure to be complete. At the Login prompt, type: user388 <RETURN> if the VE432 is installed on an SN388 workstation user432 <RETURN> if the VE432 is installed on a standalone workstation You do not have to enter any password at this stage (press <RETURN>).

  • Page 41: Custom Sweeps

    The sweep should be defined with 2000 samples per second, one sample per line. Each sample should be a floating value in ASCII format, scaled between -1 and +1. Example : # Sercel Custom sweep # file custom1.asc # 11.03.1999 0.0000001...

  • Page 42: Loading A Custom Sweep File To Adpg

    CUSTOM SWEEPS Loading a Custom sweep file to a DPG Loading a Custom sweep file to a DPG After creating a Custom sweep file you have to move it to the HCI, via a floppy disk. You may put it into the /tmp directory or any directory beginning with /users/ (e.

  • Page 43: Using Ve432 With A Recording System Other Than Sercel

    RADIO Analog Pilots: PILOTS 1 to 4 + Return Pilot + Return Sweep FO : Start order from recording system to VE432 DPG (either contact closure or voltage pulse). TB : Start time, from VE432 DPG to recording system.

  • Page 44: Distinctions To Be Made

    FO and TB signals via the RECORDER connector, the required pilots via the ANALOG PILOTS connector. - All the functions of the VE432 DPG environment on the HCI are available. - The OPERATION environment must be open for production acquisitions to be permitted.

  • Page 45: Toolsvehci Software Loading Utility

    toolsVeHci SOFTWARE LOADING UTILITY Loading software to a DPG or DSD toolsVeHci SOFTWARE LOADING UTILITY Loading software to a DPG or DSD Software for the DPG and DSD is contained in the VE432 CDROM. To load a new software release from the CDROM to a DSD you have to use the toolsVeHci utility available on the HCI workstation.
  • Page 46 toolsVeHci SOFTWARE LOADING UTILITY Loading software to a DPG or DSD · Load DPG slave file to PCMCIA. Used to load the latest version of Slave DPG software to a PCMCIA card. You have to insert a PCMCIA card into the DPG.

  • Page 47: Ground Viscosity And Stiffness

    GROUND VISCOSITY and STIFFNESS CONVERSION TO NORMALIZED UNITS GROUND VISCOSITY and STIFFNESS CONVERSION TO NORMALIZED UNITS × 4000 × base × 15 625 × base = Ground Viscosity (N/m = Ground Stiffness (Ns/m GS432, GV432 Values from VE432 DSD Quality Control Baseplate Mass Baseplate Surface BASE...
  • Page 48 GROUND VISCOSITY and STIFFNESS CONVERSION TO NORMALIZED UNITS 0311385 Issue : April 1999...

  • Page 49: Ve432 Status

    VE432 STATUS VE432 STATUS no hiline sync The DPG started but failed to find the requested 50 Hz synchronization. custom error No sweep (same as DSD status 22) timeout error No sweep, DPG hardware malfunction. Normal, Raw mode. Normal, Filtered mode. Normal, Timing error (indicative of discrepancy between DPG and DSD clocks).
  • Page 50 VE432 STATUS - In a cmdTool (command tool) window, type cd /export/home/sn388/sn388Hci/internalDisk <Return> Sps2TabHci fileName targetFileName < > < > <separator> <Return> The separator is optional (by default < >). The resulting file can be exported to a PC via a DOS floppy disk. 0311385 Issue : April 1999...
  • Page 51 SERCEL - FRANCE 16 rue de Bel-Air - B.P. 439 44474 CARQUEFOU Cedex (+33 (0)2 40 30 11 81 Fax +33 (0)2 40 30 19 48 S.A. CAP 69 984 000 F R.C. 866 800 154 B NANTES Route de Barbazan B.P.
  • Page 52 HOW TO PRINT this manual from an HCI workstation If you are viewing this manual on an HCI UNIX workstation, you have to change the printer command in the PRINT dialog box as follows: Select PRINT from the menu bar acroPrint In the Printer Command text box, type NOTE: The Print Setup allows you to select the paper size.
