Summary of Contents for extraspace GardenStore
- Page 1 Assembly Instructions...
- Page 2 Assembly Instructions General assembly instructions • Read instructions thoroughly before commencing assembly • For best results assemble on level, solid ground so as to avoid buckling the chassis which may affect alignment of the wall and ceiling panels •...
- Page 3 STEP Remove the travelling brackets by unscrew the 4 bolts using a 19mm socket spanner. STEP Lift off the roof section and place away from chassis so you have room to work. Gardenstore Assembly Instructions V2...
- Page 4 STEP Remove the components and panels. Discard the packaging and wooden packing blocks. STEP Install the end wall panel (The one without the door or ventilation grilles). Affix to floor chassis using x2 13mm bolts, washers and captive nuts. www.extraspace.com...
- Page 5 Affix to the floor chassis using x2 13mm bolts, washers and captive nuts. STEP Install the second panel to complete the side wall by affixing to the floor chassis using x2 13mm bolts, washers and captive nuts. Gardenstore Assembly Instructions V2...
- Page 6 STEP Install the panel linking strip to join the two wall panels using x6 13mm bolts, washers and captive nuts. STEP Install the second wall panel repeating steps 5, 6 and 7. www.extraspace.com...
- Page 7 Install the end wall/door panel by affixing to the side walls using x3 13mm bolts, washers and captive nuts and to the floor chassis using x2 13mm bolts, washers and captive nuts. STEP Once secure, unlock the door to access the unit. Gardenstore Assembly Instructions V2...
- Page 8 STEP Insert the x4 rubber bungs into the holes in the roof panel. STEP Install the handles by aligning them with pre-drilled holes. Use x2 screws, washers and nuts. www.extraspace.com...
- Page 9 The panel will slot into place ready for securing from the inside. Use 13mm bolts, washers and nuts to affix the roof to all 4 wall panels. STEP Now’s the time to check all the bolts are secured tightly. Gardenstore Assembly Instructions V2...
- Page 10 Accessories Your Gardenstore is now ready for use but don’t forget, we also have a wide range of handy accessories that means you can personalise your units around your own specific needs: Cable / Hose Holder An easy to fit bracket for storing cables and hoses etc.
- Page 11 Folding Ramp For more information or to buy on-line visit www.the-gardenstore.co.uk/accessories Gardenstore Assembly Instructions V2...
- Page 12 Expandachem - Flat-packed office unit home and - Flat-packed storage unit for the commercial use. safe storage of chemicals and lubricants. Gardenstore Bikestore - Flat-packed secure storage unit for all - Flat-packed secure storage unit your garden equipment. for cycles, motorcycles and tools.
