- Page 1 ENIGMA ‘K’ Chair Enigma ‘K’ Chair Owners Handbook Page 1 of 19 Part Code: Z14999...
-
Page 2: Table Of Contents
1 . C O N T E N T S 1. Contents 2. Introduction 3. Parts Description 4. Adjustment Features 5. Folding Back Mechanism 6. Disassembly and Folding 7. Operation 8. Using the Stepper Tube & Kerbs 9. Using the Wheelchair in a Vehicle 10. -
Page 3: Parts Description
pneumatic racing tyres speed responsiveness, it can be propelled by either the user or an attendant. The wheelchair is designed for a single user up to 115kg (18 stones). All Enigma wheels are manufactured to the highest quality and are CE compliant. Medicare Technology is an ISO 9001 and ISO 13485 certified medical device manufacturer. - Page 4 PUSH HANDLE BACK CANVAS HALF-FOLD MECHANISM ARMREST QUICK RELEASE PIN PARKING BRAKE FRONT CASTOR LEG REST Enigma ‘K’ Chair Owners Handbook Page 4 of 19 Part Code: Z14999...
-
Page 5: Adjustment Features
4 . A D J U S T M E N T F E A T U R E S Armrests For comfort the armrest will flip up, remove and has a height and angle adjustable arm pad. To adjust the height of the armpad, press button (A) whilst adjusting the pad (B) - Page 6 Legrests The length of the leg rests can be adjusted. To adjust the length of the leg rest, first loosen the allen bolt on the legrest using the allen key provided. Then slide the footplate in and out until the desired position is reached.
- Page 7 Rear Wheel Position The horizontal and vertical position of the rear wheels can be altered to suit the user. To do this remove the rear axle bosses and replace in the desired position for both wheels. Alter the position of both brakes if required.
-
Page 8: Folding Back Mechanism
5 . F O L D I N G B A C K M E C H A N I S M The wheelchair has a half fold back mechanism which has been designed so that the wheelchair will fit in to small spaces by reducing the wheelchair height. - Page 9 i. Legrests: The legrests can swing in / out and are removable for convenience. Pull up on the black plastic handle to unlock the legrest and then swing the legrest in or out, as required. To remove the legrest, swing the legrest out approximately 45º...
- Page 10 ii. Rear wheels: The rear wheels on the wheelchair can be easily removed for transportation or storage. With one hand holding up the wheelchair frame, Warning: the other hand Check that the should grip the wheel is securely centre of the wheel, fastened before push the centre pin use by pulling the...
- Page 11 iii. Folding the wheelchair: Then to fold the chair, Firstly, unlock the snap ensure that the link which make the legrests are removed frame rigid, by pushing or the footplates the black knob forwards flipped up. Remove (see photo below) the seat and back cushions and remove the rear wheels if...
-
Page 12: Operation
7 . O P E R A T I O N Before Using the Wheelchair read the safety notices below: • Use slow speeds on gradients. Do not exceed the maximum gradient stated. • The wheelchair is only suitable for single occupancy. - Page 13 i. Propulsion • Either the wheelchair user or an attendant can manually propel the wheelchair. • If the user is propelling the wheelchair, they should use the handrims attached to the rear wheels. The user can slow the wheelchair by applying pressure to the handrim using their hands.
-
Page 14: Using The Stepper Tube & Kerbs
8 . U S I N G T H E S T E P P E R T U B E A N D K E R B S Anti-tip wheels. The stepper tubes have integral anti-tip wheels. The height of the wheels can be altered by pulling the round disc on the stepper tube whilst adjusting the wheel height as required. -
Page 15: Using The Wheelchair In A Vehicle
tube to raise the front castors and tip the user slightly back. Keeping the castors raised, slowly lower the wheelchair down the kerb. Warning: Do not raise the front castors by pushing down on the push handles as this could result in damage to the wheelchair. -
Page 16: Care And Maintenance
1 1 . C A R E A N D M A I N T E N A N C E • Before each use of the wheelchair, the brakes should be checked. • The wheelchair should be stored in a dry environment, away from direct sunlight. -
Page 17: Specification
• The wheelchair comes with a toolkit to perform simple maintenance tasks and the most common adjustments. • 12. SPECIFICATION Model Enigma ‘K’ Chair Overall D* 97 x 71 x 91cm / 38¼” x 28¼” x 36” Folded Width 32cm / 12½” Seat D* 40 x 45 x 48cm / 16”... - Page 18 The above warranty conditions apply to brand new wheelchairs. Ex-demo wheelchairs supplied directly by Medicare Technology carry a six-month warranty period. If you are unsure whether your wheelchair is covered contact your dealer. Under normal circumstances, no responsibility will be accepted where the wheelchair has required assistance as a direct result of: a.
- Page 19 Other Products in the Medicare Technology Range: Please contact your local Medicare Technology Dealer for a catalogue. Medicare Technology Ltd, Dealer Stamp Ainley’s Industrial Estate, Elland, West Yorkshire HX5 9JP. Tel: +44 (0) 1422 314488 Email: enquiries@medicaretechnology.com Web: www.medicaretechnology.com Enigma ‘K’ Chair...
