- Page 1 NEA WIRING CENTRE NEA HT 230V /24 V...
-
Page 2: Installation Instruction
- for the installation of up to 6 NEA room controllers 230 V or 24 V (do not mix 230 V and 24 V). - for the installation of up to 15 REHAU (UNI) actuators 230 V or up to 1. Boiler connection 15 REHAU (UNI) actuators 24 V (do not mix 230 V and 24 V). -
Page 3: Electrical Connection
Jump switches Switching power 200 VA inductive - Three switches Turn on delay 2 mins - Switch 1 alters the actuator control direction operation from Follow-up time fixed/ 2 mins/ 5-15 mins normally open (NO) to Normally Closed (NC) adjustable - Switch 2 and 3 increases the operation time to 5, 10 and 15 Valve protection 14 days for 10 minutes... - Page 4 Before opening the controller disconnect the wiring centre from mains and ensure it is isolated and locked to stop it from being switched on again. Disconnect external voltages and secure against unintended activation. 24 V 230 V T4AH Cleaning Only use a dry and solvent-free, soft cloth for cleaning. Dismantling WARNING! Electrical voltage! Danger to life! - Before opening the controller disconnect the wiring centre...
- Page 8 Working conditions and use under conditions for which the product was not intended and over which we have no influence exclude any claim resulting from our information. We recommend that a suitable check is made as to whether the REHAU product is suitable for the envisaged purpose. Application, use and processing of the products is carried out beyond the scope of our control and are therefore carried out exclusively at your own responsibility.
