Summary of Contents for ParTech 750W2
- Page 1 INSTRUCTION MANUAL 750w² Monitor...
- Page 2 **This page is left blank**...
-
Page 3: Table Of Contents
750w² Monitor Instruction Manual Table of Contents 1 Introduction........................5 1.1 General......................5 1.2 Display......................5 1.3 Keypad......................5 1.4 Sensors......................5 1.5 Manual Conventions..................5 2 Basic Operation......................7 2.1 Power On/Off....................7 2.2 Measure Mode....................7 3 Configuration Structure....................8 3.1 Menu Mode.......................8 3.2 Configuration – Use of Keys................8 4 Monitor Configuration....................10 4.1 Bleeper......................10 4.2 Backlight......................10... - Page 4 750w² Monitor Instruction Manual 7.1 Battery......................14 7.2 Charger......................14 8 Firmware Updates.......................15 8.1 Introduction.....................15 8.2 Updating Firmware..................15 9 Technical Support.......................16 9.1 Returning Equipment for Repair..............16 10 Technical Specification.....................17 10.1 Spare Parts....................17 11 Declaration of Conformity..................18 Page 4 of 20 228538IM Issue 09 Issue Date 20/01/2020...
-
Page 5: Introduction
The manual has been written on the basis that the user has a basic knowledge of instrumentation and an understanding of the type of measurement being made. Training in the use of the 750w² Monitor can be provided by Partech, please contact Partech for further information... - Page 6 750w² Monitor Instruction Manual Figure 2: 750w² Monitor Page 6 of 20 228538IM Issue 09 Issue Date 20/01/2020...
-
Page 7: Basic Operation
750w² Monitor Instruction Manual Basic Operation Power On/Off The 750w² Monitor can be turned on and off using the ON/OFF key. When the monitor is turned on it enters the Measure Mode; (Figure3). The instrument can be switched off at any time by pressing the ON/OFF key. With no sensor plugged in, the status bar will display ‘NO SENSOR’... -
Page 8: Configuration Structure
750w² Monitor Instruction Manual Configuration Structure Menu Mode To access the main menu, press the MENU key when the monitor is in measure mode (Figure 6). Pressing the MENU key when the main menu is displayed will return the monitor to the measure mode. - Page 9 750w² Monitor Instruction Manual 3.2.2 User Value Entry (Figure 8) When a numerical value is to be set, the current value will be displayed with a flashing cursor. The range of adjustment of the value is predefined and therefore only values within this range can be entered.
-
Page 10: Monitor Configuration
750w² Monitor Instruction Manual Monitor Configuration This section explains the options available under the Monitor Configuration menu (Figure 10 and 11). Press the OK key to select Figure 10 Figure 11 Bleeper The Bleeper can be switched off if required (Figure 12). Press OK to enter Bleeper setup. -
Page 11: Set Date & Time
Figure 17 Enable Service mode The 750w² Monitor has a set of hidden menus that provide access to diagnostic information. (Figure 18). These menus are intended for use by Partech engineers. Figure 18 228538IM Issue 09 Date 20/01/2020 Page 11 of 20... -
Page 12: Measurement Configuration
750w² Monitor Instruction Manual Measurement Configuration Measurement Config (Figure 19 and 20) provides access to sensor calibration and other settings relating to the measurement. All these settings are stored within the sensor allowing Figure 19 sensor swapping without reconfiguration. All sensor specific configuration including calibration is explained in the sensor manual. -
Page 13: Recorded Data
Data via USB When the 750w² Monitor is plugged into a PC it will appear like a USB memory drive named “750w2” with a folder “DataRecordings”. Inside this folder will be a CSV file named “DataRecordings”, this is a file that combines all the recorded data and is used for data display on the monitor. -
Page 14: Battery Charging
750w² Monitor Instruction Manual Battery Charging Battery The monitor contains a Nickel Metal Hydride (NiMH) battery pack that supplies the power for operation. This type of battery does not have to be fully discharged prior to charging, although this is a preferred option. It is therefore possible to "top up"... -
Page 15: Firmware Updates
750w² Monitor Instruction Manual Firmware Updates Introduction The firmware on the 750w² can be easily be updated. If advised to do so, follow these steps to put the latest firmware on your 750w². Updating Firmware Ensure the monitor is fully charged. -
Page 16: Technical Support
Application details • Description of fault • Returning Equipment for Repair If equipment needs to be returned to Partech for repair or service the following address should be used: SERVICE DEPARTMENT PARTECH INSTRUMENTS ROCKHILL BUSINESS PARK, HIGHER BUGLE ST AUSTELL, CORNWALL, PL26 8RA UNITED KINGDOM Please include the following information with the returned equipment. -
Page 17: Technical Specification
750w² Monitor Instruction Manual Technical Specification Power Supply........Internal Rechargeable Battery Pack NiMH Charge Input........5 VDC (min 500mA) Partech Charger......USB Power Adaptor, 100 to 240VAC Input, ............5VDC 2.1A Output, 10 Watt. Battery Life........Sufficient for 1 week normal use (30 ............measurements per day) EMC Conformity......EN 61326:2013, IEC 61010-1:2017... -
Page 18: Declaration Of Conformity
EU EMC Directive 2014/35/EU Low Voltage Directive 2011/65/EU RoHS Directive Roger Henderson, Joint Managing Director, 20 January 2020 for Partech Instruments, Rockhill Business Park, Higher Bugle, St Austell, Cornwall PL26 8RA, UK Page 18 of 20 228538IM Issue 09 Issue Date 20/01/2020... - Page 19 750w² Monitor Instruction Manual 228538IM Issue 09 Date 20/01/2020 Page 19 of 20...
- Page 20 Partech Instruments Rockhill Business Park, Higher Bugle, St Austell, Cornwall, PL26 8RA, UK Tel: +44(0)1726 879800 Email: info@partech.co.uk Web: www.partech.co.uk...
