- Page 1 Manual Retractable Awning 3,95x2,5m w/Remote Control 27-02-2020...
- Page 2 Retractable Awning 3.95x2.5m...
-
Page 3: Specification
Specification Shade Actual size Net weight Dimension Inclination angle Artical number Fabric Wind resistance class (cm) (Kg) (cm) 295×200 0° ～ 45° BW23000 287×200 Polyester Class 1 (28Km/h) 395×250 0° ～ 45° 387×250 Polyester BW23000 Class 1 (28Km/h) Precautions and safety warning for installation and operation Attention! Before opening the awning, make sure all the fixing bolts and security devices are properly installed and tightened. -
Page 4: Accessories And Required Tools
Accessories and required tools Washer Ø6.5 Nut M6 Bolt M6×50 Bolt ST4×15 Nut M6 Bolt M6×8 Bolt M6×12 Bolt ST5×15 Bolt M5×15 Bolt ST5×25 Bolt M4×10 Nut M8 Instruction... - Page 5 Please prepare below tools before installation: 1 、 2 、 3 、...
- Page 6 4 、 5 、 PicA PicB 6 、 through from Through the fabric into roller and front bar 7 、...
- Page 7 8 、 9 、 12 、 Bolt M6×55...
- Page 8 13 、 tight tight tight tight 14 、 3.95x2.5M: 3.95x2.5M: C=A+0.17*L...
- Page 9 15 、 Installation of awning to wall brackets Remove the bolts on the front of the wall brackets.Install the awning to the wall brackets by attaching the square torsion bar to the wall brackets.Lock the awning in place by replacing the bolts and nuts on wall brackets.Tighten the nuts to ensure the awning is attached to wall brackets securely.
- Page 10 17 、 tight tight Open Check if the awning is level with the use of the spirit level on the front bar.Adjust the angle adjuster at either end by loosening the locking nuts of the angle adjuster ,turn the jack bolt to adjust the pitch.Adjust the arm until the front profile is level.Tighten the locking nuts again to fix the level of awning.
-
Page 11: Remote Control
Remote control Press button Function Retract / close the awing Stop Down Stop stop opening/closing process extract / open the awning Down Shade travel limit adjustment 1. Customers can adjust and set the positions of sun shade travel limit by themselves. 2. - Page 12 4. After setting,open and close the awning with the remote control and check if the setting is satisfactory.If not,repeat step 1. Description of mistake Warning: When the front bar touches the roller as shown in the figure, don't try to make them closer, otherwise the product might be damaged. Re-initialization of the remote control Turn off the power supply for about 10s, then power on.
-
Page 14: Contact Information
Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: 70 26 76 20 Spain: 911 436 828 denmark@dancover.com espana@dancover.com UK: 020 8099 7570 Italy: 02 479 21 198 uk@dancover.com...
