- Page 1 4 input Full HD encoder/modulator HD500MOD USER MANUAL V1.0...
-
Page 2: Table Of Contents
After compressing the video into H264 and audio in AAC or MPEG1-L2, the output is available as DVB-T or as DVB-C signal. To make the configuration of the HD500MOD ultra simple, a special software DTVIface is available that you can download on our website www.revez.eu Contents 1 - Safety considerations ................3... -
Page 3: Safety Considerations
HD500MOD USER MANUAL 1 - Safety considerations 1.1 CONNECTING TO THE MAINS SUPPLY This product has to be connected to the mains supply. If there is the slightest doubt concerning the type of connection available on the installation, please contact your supplier of electricity. Before car- rying out maintenance operation or modification of the installation, the modulator has to be discon- nected. -
Page 4: Description Of The Different Elements
HD500MOD USER MANUAL 2 - Description of the different elements Power supply input (5V/4A) USB input (for programming the HD500MOD by PC) RF output RF input HDMI A input HDMI B input HDMI C input HDMI D input Status of 4 input HD encoder... -
Page 5: Installation
The HD500MOD can be used as a desktop model. The HD500MOD also comes with 19 inch brack- ets and screws. These can be fitted to the HD500MOD in order to install them in a 19 inch rack. The position of the brackets can be chosen in order to select the back or frontpanel facing forward. -
Page 6: Setting The Input Parameters
HD500MOD USER MANUAL 3.4 - Setting the input parameters For each HDMI input you can adjust fol- lowing parameters : - S.I.D : set the service ID - Name : set the programe Name - Bit rate : choose a value between 5000... -
Page 7: Setting The Output Parameters (Dvbt Mode)
HD500MOD USER MANUAL 3.5 - Setting the output parameters (DVBT mode) For the modulator following parameters can be set. N.I.T Version : enter the NIT version ONID : enter the decimal code for the Original Network ID. The original network ID is the coun- try where you are located. -
Page 8: Conversion To Dvb-C Mode
USER MANUAL 3.7 - Conversion to DVB-C mode. The HD500MOD can also act as DVB-C modulator instead of DVB-T. In order to change you have to press the DVBT/C conversion button. This will convert the DVBT modulator in a DVBC modulator or vice versa. Please note that this op- eration takes a couple of minutes.
