Summary of Contents for SHRC H1GPS
- Page 1 INSTRUCTION GPS GLOBAL POSITIONING Thank you for your purchase of this product. Please read the Operation Instruction carefully and conduct operation and usage according to the Operation Instruction. Please keep this User Manual for your reference when conducting daily maintenance and adjustment.
- Page 2 Safety instructions 1． please keep the parts of drone out of the reach of children. 2． this drone is very powerful. When using it for the first time, you should push the left control lever slowly to prevent the drone from rising too fast and causing unnecessary collisions and injuries.
-
Page 3: Table Of Contents
Items List ---------------------------------------------------------------- Drone Drone description -------------------------------------------------------- Battery Charging Steps -------------------------------------------------- Installation and replacement of propeller blades -------- Installing The Protection Ring ---------------------------------- Remote Control Instructions on remote control function keys-------------------------- Instructions of battery of remote control ------------------------------ Preparing for flight Flight environment requirements -------------------------------------- Preflight inspection... -
Page 4: Items List
Items list Please check the items in package before you start. Mini drone: Screws on protective ring: 12 2 type A propeller blades Propeller blade： 2 type B propeller blades Remote control: USB cable: Screwdriver: Instruction of product Drone Description of drone This drone has good controllability and stability. -
Page 5: Installing The Protection Ring
Installing the Propellers The Drone comes with replaceable propellers if the originals are broken or badly damaged. (1) When installing for the first time, please carefully distinguish the propellers type. Model A propeller blade Model B propeller blade (2) Referring to Figure 3, insert the groove of propeller opener into the bottom of propeller which needs to be replaced. -
Page 6: Remote Control
Remote Control Function Instructions One button Indoor/Outdoor switch ascend Follow mode One button return Power Video Right control lever Calibrated geomagnetism Press the button of power switch the remote control light Power switch will be on/Press again the remote control light will be off. Push the control lever upward,the drone will ascend vertically;... - Page 7 The drone will center around the curret head at 2 meters Set-circle mode and make a surround flight. connecting the drone to APP,then press the photography Photography button,drone will taking photo and saving into APP. If the drone is in a state of stationary frequency,pressing One button taking off this button it will taking off.
-
Page 8: Preflight Inspection
Flight Preparation Please have flight training before using the product (User should be guided by a professional.). Please choose appropriate flight environment when using the product. Applying Environment (1) Choose an open place to fly where having no tall buildings. (2) Do not use this product in severe weather,such as strong wind,heavy snow,rain or fog days. -
Page 9: First Use
First use If this product is used for the first time, you should conduct a compass calibration after the frequency match step is completed. Calibrated geomagnetism Calibrated geomagnetism Press the No.13 key on remote control unit for 2 seconds, when the four indicator lights on the drone are flashing quickly, the drone is in the calibration state. - Page 10 Applying Environment Remote control Drone Control method Startup the drone motors Startup pull the two remote control levers as shown in the figure, and hold for 1-2 seconds to start the motors. After the motors start, release levers and push the levers to start flying.
-
Page 11: Advanced Flight Function
Advanced flight function Speed gear adjustment Press the No.4 key on the remote control unit to change the speed of drone. When the drone is switched into low speed gear, the remote control unit will make a beep sound, when the drone is switched into high speed gear, the remote control unit will make two beeps. -
Page 12: Control With A Mobile Phone
Control with a mobile phone Downloading APP Scanning the QR code below and downloading the software Foreign Android System Apple System LW FPV Android version Opening and connecting the software on your phone Enter the “Settings” function of the mobile phone, open the MF option, find the device WF name “WIFI-720P-GPS-XXXXXX”... -
Page 13: Hover Mode
The following functions must be used after the drone has completed the searching satellites and positioning. 1. Hover mode 2. Track and waypoint mode 3. Follow mode 4. Rotation around a point mode Hover mode When the drone is in other flight modes, you can press this mode and make the drone enter normal hover mode. -
Page 14: Follow Mode
Follow mode In the case of close range (it is recommended that the height is not exceeded for 10 meters and the distance is not exceeded for 20 meters), when this mode is opened, the drone will follow the mobile phone to move at a fixed distance from the current distance. - Page 15 Identification Of The Drone SWEEP THE QR CODE Head Flying WATCHING FLIGHT TEACHING Forward/forward VIDEOS REFUSED TO LOSE, REFUSED TO LOSE CONTACT Left Flying To Left/ Right Flying To Left Side Right/ Right Side Tail Flying Backward/backward Geomagnetism Electronic fence Course Calibration Course Out Of Control Return Course Low-voltage Return Course...
- Page 16 Set Point Course Set Circle Fly Course One Button Return Course Gps Follow Course Kindly reminde 1. it is recommended to connect the mobile phone app before completing the take-off operation to ensure that the mobile app is connected successfully with the aircraft. 2.
