Discrete Custom Codes For Installers; Placement Of The Gtp-860 - Adcom GTP-860 Owner's Manual

FUNCTION and DATA list for GTP-860(ADCOM)
Discrete (Direct Access) Custom Code: 1Ah E8h
Function
* MAIN POWER ON
* MAIN POWER OFF
* DOLBY PRO LOGIC
* SYMPHONY HALL
* 2 CHANNEL STEREO
* 5 CHANNEL STEREO
* DOLBY PL II MOVIE
* DOLBY PL II MUSIC
* DOLBY PL II PANORAMA 0111 1010
* DOLBY PL II MATRIX
* Delay Front 5mS
* Delay Front 4mS
* Delay Front 3mS
* Delay Front 2mS
* Delay Front 1mS
* Delay Front None
* Dynamic Range Normal 0100 0010
* Dynamic Range 75%
* Dynamic Range 50%
* Dynamic Range 25%
Data(B) D Function
0010 1010 84 * Delay Rear 15mS
1010 1010 85 * Delay Rear 10mS
0111 0000 14 * Delay Rear 5mS
1111 0000 15 * Delay Rear None
1111 0010 79 * Center Trim +
0111 0010 78 * Center Trim -
0011 1010 92 * Rear Left Trim +
1011 1010 93 * Rear Left Trim -
94 * Rear Right Trim +
1111 1010 95 * Rear Right Trim -
0000 0000 0 * Subwoofer Trim +
1000 0000 1 * Subwoofer Trim -
0100 0000 2 * Back Left Trim +
1100 0000 3 * Back Left Trim -
0000 0010 64 * Back Right Trim +
1000 0010 65 * Back Right Trim -
66 * OSD Bypass ON
1100 0010 67 * OSD Bypass OFF
0110 0010 70 * Mute ON
1110 0010 71 * Mute OFF
Placement of your GTP-860
Your system components need a stable, vibration-free supporting surface.
Your ADCOM dealer will be pleased to show you many different types of
audio/video equipment racks and cabinets. Keep the GTP-860 (and other
audio/video components) away from moisture and out of direct sunlight.
Bear in mind that the GTP-860's rear panel is the central connecting point
for almost every component in your audio/video system. Leave sufficient
room behind the rear panel to accommodate cables, antenna leads, power
cords, etc. We recommend a minimum of 5 inches of free space behind the
GTP-860 for maximum flexibility. A distance of 1/2" should be maintained
around the GTP-860 for ventilation. Keep your GTP-860 in a room where
temperatures remain fairly moderate, and never cover it with table cloths,
curtains, newspapers, etc., to avoid potential overheating.
B: LSB first D: decimal
Code Type: NEC2
Data(B)
0110 0000
1110 0000
0010 0010
1010 0010
0001 0000
1001 0000
0101 0000
1101 0000
0001 0010
1001 0010
0101 0010
1101 0010
0011 1000
1011 1000
0111 1000
1111 1000
0110 1000
1110 1000
0110 0001
1110 0001
* OSD bypass is not available on all units.
ADCOM GTP-860 OWNER'S MANUAL | 25
D
6
7
68
69
8
9
10
11
72
73
74
75
28
29
30
31
22
23
86
87
