Installation
Manual
For Cassette Panel
Model: CASS-PNL-18-24-36
Do not install the unit in the following places. It causes failure o the unit in many cases.
* Places where oil (including machinery oil) mist and steam drifts.
* Places where a lots of sulfide gas drifts such as in hot spring.
* Places where inflammable gas may generate or flow.
* Places where air contains high salt contents as coast regions.
* Places where with atmosphere of acidity or alkalinity.
In
case of using equipment
should
he electrical box
from
equipment to avoid any radiation transmitting in the air.
Do not install the unit in
animals or plants.
The standard utilization of this air panel is explained in these instructions.
Improper operation, or operation not made in accordance with these instructions , can result in unsatisfactory
and/or dangerous conditions. In such cases, the warranty does not apply.
Our liability shall not cover defects arising from any alteration performed by a customer.
All information in this manual is based on the latest product information available at the time of approval for printing. We
reserves the right to make changes at any time without notice and without incurring any obligation.
No part of this manual may be reproduced without written permission.
Signal words (CAUTION and NOTE) are used to identify levels of hazard seriousness. Definitions for identifying
hazard levels are provided below with their respective signal words.
NOTE
This manual should be considered as a permanent part of the air conditioning equipment and should remain with the
air conditioning equipment.
Check the model number and accessories to determine if they are correct.
generat
electromagnetic waves, pay a particular attention to unit malfunction . The unit
place where the air flow directly c
IMPORTANTNOTICE
: Hazards or unsafe practices which COULD result in minor personal
injury or product or property damage.
: Useful information for operation and/or maintenance.
READ AND UNDERSTAND
THIS MANUAL BEFORE
USING THIS AIR PANEL.
KEEP THIS MANUAL FOR
FUTURE REFERENCE.
PREFACE
electromagnetic waves. The unit should be placed at least 3m away
animals or plants. It could be the cause of adverse affect to
1
IMPORTANT:
Advertisement
Summary of Contents for DIAL CASS-PNL-18-24-36
- Page 1 Manual IMPORTANT: For Cassette Panel READ AND UNDERSTAND THIS MANUAL BEFORE Model: CASS-PNL-18-24-36 USING THIS AIR PANEL. KEEP THIS MANUAL FOR FUTURE REFERENCE. PREFACE Do not install the unit in the following places. It causes failure o the unit in many cases.
- Page 2 1.Before Installation 2.3 Installing Air Panel ≤ 2.3.1 For cassette cooling capacity 18000Btu supporting panels （ ） Step 1 When the air panel is unpacked, place it on insulation material Set the display board of the panel to the corner of the electric control etc.
- Page 3 Projection 2.3.2 For cassette cooling capacity＞18000Btu supporting panels （ ） Step 1 Remove the corner pocket cover as shown below(4 portions). Pull the fixing hook towards the arrow mark according to the order “①”, “②” and “③”. Band The corner pocket cover can be lifted. After lifting, move it in “④”direction, disconnect the L-shaped hook and dismantle the corner pocket cover.
- Page 4 2.4 Wiring Connection for Air Panel The wiring connector is located at the panel as shown in the figure. If the long screws are tightened insufficiently, it may cause of the failure. Air Leakage Smudge Dewing When there is still the gap even after tightening the long screws firmly enough, readjust the height of the indoor unit.
