T9i
OPERATION GUIDE
Mobile POS Tablet Barcode Scanner
The Barcode Scanner is preinstalled as an option for the T9i series.
Button Management
The default scanner trigger button is on the right side. To assign the Scanner Trigger
button, follow the steps below.
1. Start Button Manager by clicking on
2. Select an available unused button marked with the icon
3. Click on
to go to the second screen of Button Manager.
4. Click on the
icon to assign the Scanner Trigger to the unused button.
5. Click OK to apply configuration settings and close the window.
To Connect Barcode Scanner Module
To connect the Barcode Scanner, you can use the Keyboard Wedge. Tap on the
task bar, a menu displays as shown in the picture below. Select Connect Scanner.
in the system tray.
.
icon in the
