EMC2 AX100 Series Replacing

Hide thumbs Also See for AX100 Series:

This document describes how to replace an Uninterruptible Power

Supply (UPS) that is connected to an AX100 (dual-SP) storage system.

Topics include

Before You Start .....................................................................................2

To Replace the UPS................................................................................2

To Verify Operation of the Replacement UPS ...................................3

To Return the UPS .................................................................................4

Replacing an Uninterruptible

Power Supply (UPS)

AX100-Series

Revision A02

November 19, 2004

Table of Contents

Need help?

Do you have a question about the AX100 Series and is the answer not in the manual?

Page 1 AX100-Series Replacing an Uninterruptible Power Supply (UPS) Revision A02 November 19, 2004 This document describes how to replace an Uninterruptible Power Supply (UPS) that is connected to an AX100 (dual-SP) storage system. Topics include Before You Start ..................2 To Replace the UPS................2 To Verify Operation of the Replacement UPS ........3 To Return the UPS .................4...
Page 2 Before You Start Before You Start To complete this procedure, you need a replacement UPS kit. To Replace the UPS As you follow the steps below, refer to Figure 1 and the documentation that shipped with the replacement UPS. 1. Unpack the replacement UPS and save the packaging. 2.
Page 3 To Verify Operation of the Replacement UPS 6. Unplug the battery connector (refer to the documentation that shipped with the replacement UPS). CAUTION The battery must be disconnected before shipping the UPS to the manufacturer. 7. Remove the defective UPS from the cabinet (refer to the documentation that shipped with the replacement UPS).
Page 4 To Return the UPS To Return the UPS 1. Pack the defective UPS in the packaging from the replacement UPS. 2. Return the defective UPS to the address provided with the replacement UPS. Copyright © 2004 EMC Corporation. All Rights Reserved. EMC believes the information in this publication is accurate as of its publication date.
