Summary of Contents for IST TOUCH
- Page 2 Spring Bracket Assembly These are the general mounting instructions for the IST Touch Systems that use a “Spring-type” bracket as shown here. If you have “L-type” bracket, as shown here, please refer to the L-bracket assembly instructions on page 6.
- Page 3 2. Step 2: Carefully lower the top of the touch panel onto the display, and swing the bottom into place. As an alternative method of assembly, you may remove all brackets and have one person hold the panel in place while a second person pro- ceeds to step 3.
- Page 4 On some models of displays, protrusions, such as a logo or buttons, may block the infrared sensor path and it may be necessary to loosen the pinch plate screws and slide the touch panel back a fraction of an inch.
- Page 5 “L-type” Bracket Assembly These are the general mounting instructions for IST Touch Systems that use an “L-type” bracket as shown here. If you have “Spring-type” bracket, as shown here, please refer to the Spring bracket assembly instructions on page Familiarize yourself with the parts of the mounting system.
- Page 6 Step 1: Align the touch panel in front of display and match the mounting brackets to the mounting screws on the rear of the display. In some cases the mounting point will be an empty screw hole, and the correct screw will be provided with the touch panel.
- Page 7 On some models of displays, protrusions, such as a logo or buttons, may block the infrared sensor path and it may be necessary to loosen the pinch plate screws and slide the touch panel back a fraction of an inch.
- Page 8 120AC electrical outlet. The power jack for the transformer’s plug is located on the bottom rear of the touch panel bezel. Plug the round connector from the transformer into the power jack of the bezel.
