- Page 1 Megatouch FORCE Monitor Chassis Board Replacement Visit the Merit Industries, Inc. Web site http://www.meritind.com merit industries, inc. PM0337-01 Rev C...
-
Page 2: Table Of Contents
Table of Contents FORCE Classic Monitor Chassis Board Removal ............p. 1-2 Monitor Chassis Board Replacement ........... p. 2-3 FORCE Elite Analog to Digital Board Removal............p. 3 Analog to Digital Board Replacement...........p. 3-4 FORCE Radion Monitor Chassis Board Removal ............p. 4-5 Monitor Chassis Board Replacement ...........p. -
Page 3: Force Classic
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. Megatouch™ FORCE Monitor Chassis Board Replacement FORCE CLASSIC Disconnect the (2)-pin monitor power connection (black and white wires) To replace the monitor chassis board in your from the power supply and the monitor Megatouch FORCE Classic game: ground wire from the game. -
Page 4: Monitor Chassis Board Replacement
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. 16. Carefully remove the high voltage line 26. Loosely reinstall the monitor assembly from the back of the monitor by lifting with the existing hardware, but do not the rubber seal and pinching the metal secure it. -
Page 5: Force Elite
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. 35. Close and lock the hood. Loosen the 5/16” nuts securing the (2) LCD clips (one on each side piece). 36. Replace and lock the coin box or coin See Figure 9. box/bill acceptor assembly. -
Page 6: Force Radion
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. chassis board, as the replacement chas- 14. Replace the monitor assembly, aligning sis board will not include a mounting it with the support brackets inside the tray. game and making sure the LCD clips fit... -
Page 7: Monitor Chassis Board Replacement
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. Disconnect the touchscreen power 17. Disconnect the rotation switch connec- connector (orange and gray wires) and tor (black and red wires) from P202 on the 4-pin centronics power connector the monitor control board. from the power supply harness. -
Page 8: Force Upright
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. 25. Reconnect the A/C power connector 34. Replace the rear bezel and the (7) on the monitor chassis board. See Fig- screws ((5) along the top edge, (2) at ure 14. the bottom rear) holding the bezel to the game. -
Page 9: Monitor Chassis Board Replacement
COPYRIGHT © 2002 MERIT INDUSTRIES, INC. NOTE: Do not twist the neck board dur- cable clamp to the metal frame. Then ing removal. replace the remaining (3) screws to secure the monitor chassis board as- Disconnect the degaussing power con- sembly to the game. - Page 10 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. FAN POWER CONNECTOR CLEAR DRAINAGE TUBING SPRING-LOADED LEVER GROUND STRAP FIGURE 1 - FORCE CLASSIC HOOD ASSEMBLY FRONT BEZEL FIGURE 2 - FORCE CLASSIC MONITOR ASSEMBLY PM0337-01 Rev C MONITOR CHASSIS BOARD REPLACEMENT...
- Page 11 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. HARD DRIVE CONNECTION (PRIMARY IDE) CENTRONICS CONNECTION (SECONDARY IDE) MOTHERBOARD POWER TOP VIEW OF MOTHERBOARD ETHERNET I/O BOARD AUDIO OUT TOUCHSCREEN MONITOR CONTROLLER SIGNAL (COM 1) CONNECTOR SIDE VIEW OF MOTHERBOARD FIGURE 3 - ECS MOTHERBOARD CONNECTIONS...
- Page 12 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. SCREWS FASTENING CHASSIS BOARD ASSEMBLY TO GAME FIGURE 5 - FORCE CLASSIC - CHASSIS BOARD MOUNTING TRAY GROUND VGA MONITOR CONNECTOR CONNECTOR FIGURE 6 - FORCE CLASSIC NECK BOARD PM0337-01 Rev C MONITOR CHASSIS BOARD REPLACEMENT...
- Page 13 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. YOKE ASSEMBLY DEGAUSSING CONNECTOR POWER CONNECTOR A/C POWER FLYBACK CONNECTOR TRANSFORMER FIGURE 7 - FORCE CLASSIC CHASSIS BOARD SIDE PANEL LATCHES LATCH DETAIL FIGURE 8 - FORCE ELITE SIDE PANEL LATCH ACCESS MONITOR CHASSIS BOARD REPLACEMENT...
- Page 14 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. SCREWS SECURING TOP COVER (BOTH SIDES) LCD CLIPS (BOTH SIDES) FIGURE 9 - FORCE ELITE FRONT BEZEL POWER CONNECTOR CONNECTOR SIGNAL AND POWER CONNECTOR ON-SCREEN DISPLAY CONNECTOR MONITOR SIGNAL CABLE GROUND SCREWS WIRE SECURING...
- Page 15 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. SCREWS SECURING REAR BEZEL (5 PLACES) SCREWS SECURING REAR BEZEL (2 PLACES ON OPPOSITE SIDES) FIGURE 11 - FORCE RADION - SCREWS SECURING REAR BEZEL FAN POWER CONNECTOR ANGLED BRACKET SCREWS (IF APPLICABLE) SECURING HARD...
- Page 16 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. GROUND MONITOR SIGNAL CONNECTOR CONNECTOR FIGURE 13 - FORCE RADION NECK BOARD SCREWS SECURING BOARD TO METAL TRAY (4 PLACES) YOKE ASSEMBLY CONNECTOR DEGAUSSING POWER CONNECTOR A/C POWER CONNECTOR FIGURE 14 - FORCE RADION MONITOR CHASSIS BOARD...
- Page 17 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. SCREWS (WITH SPACERS) FASTENING NECK BOARD BRACKET (4 PLACES) SCREWS FASTENING NECK BOARD BRACKET (3 PLACES) FIGURE 15 - FORCE UPRIGHT NECK BOARD BRACKET MONITOR SIGNAL CONNECTOR GROUND CONNECTOR GROUND CONNECTOR FIGURE 16 - FORCE UPRIGHT NECK BOARD...
- Page 18 COPYRIGHT © 2002 MERIT INDUSTRIES, INC. YOKE ROTATION ASSEMBLY SWITCH CONNECTOR CONNECTOR DEGAUSSING POWER CONNECTOR POWER CONNECTOR FIGURE 17 - FORCE UPRIGHT MONITOR CHASSIS BOARD SCREW SECURING SCREWS FASTENING A/C POWER BOARD ASSEMBLY CABLE CLAMP TO GAME (4 PLACES) FIGURE 18 - FORCE UPRIGHT - SCREWS FASTENING...
- Page 19 NOTES: __________________________________________________________________ _______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ _______________________________________________________________ ________________________________________________________________ __________________________________________________________________ _________________________________________________________________ ______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ _________________________________________________________________ _____________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ________________________________________________________________ _________________________________________________________________ _________________________________________________________________...
- Page 20 NOTES: __________________________________________________________________ _______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ _______________________________________________________________ ________________________________________________________________ __________________________________________________________________ _________________________________________________________________ ______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ _________________________________________________________________ _____________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ________________________________________________________________ _________________________________________________________________ _________________________________________________________________...
- Page 21 NOTES: __________________________________________________________________ _______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ _______________________________________________________________ ________________________________________________________________ __________________________________________________________________ _________________________________________________________________ ______________________________________________________________ ________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ _________________________________________________________________ _____________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ___________________________________________________________________ __________________________________________________________________ ________________________________________________________________ _________________________________________________________________ _________________________________________________________________...
- Page 22 MEGATOUCH FORCE MONITOR CHASSIS BOARD REPLACEMENT PM0337-01 Rev C...
