Cor™4
INSTALLATION INSTRUCTIONS
Layout fixture strand in desired configu-
1
ration then trace outline on mounting
surface
Screw fixture to mounting surface
3
5
Connect primary side of power supply to
AC line voltage power source
Primary
Side
Dimmer
HOT (BLACK)
L
N
NEUTRAL (WHITE)
GRD
100-120 VAC
GROUND (GREEN)
Questions/Support | 800-789-3810 | quotes@kelvix.com
24V POWER
SUPPLY
2
Remove backing from 3M adhesive tape
and secure to outlined areas on mounting
surface
Connect power feed to power supply
4
24V POWER
L
N
GRD
SUPPLY
011918NH
