Sowa WA18 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Baby stroller
WA18
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the WA18 and is the answer not in the manual?

Questions and answers

Related Manuals for Sowa WA18

Summary of Contents for Sowa WA18

  • Page 1 Baby stroller WA18 INSTRUCTION MANUAL...
  • Page 2 Important:Keep these instructions for future reference. WARNING:Don't carry additional children, bags, goods or accessories in the stroller except those recommended by the manufacture. WARNING:To avoid injury ensure that your child is kept away when unfolding and folding this product. WARNING:Never leave your child unattended. WARNING:Do not let your child to play with this product.
  • Page 3 Instructions Schematic diagram of frame parts 9. Rear wheel 17.Quick release button 1.Handle grip 10.Wheel cap of the front wheel 2.Adjustable handle 11.Crossbars 18.Front leg tube 3.Safety latch release button 12.Rear leg tube 19.Folding lever 4.Handle tube 13.Front wheel 20.Quick release of the 5.Main connector 14.Front wheel directional rear wheel...
  • Page 4 Instructions Schematic diagram of seat unit parts 29.Safety front bar 25.Seat unit adjustment 21.Seat unit upper 30.Canopy frame button 22.Canopy holder 31.Footrest adjustment 26.Seat unit release catch 23.Connectors of seat unit buttons 27.Seat unit base 24.Safety bar button 28.Seat unit bottom...
  • Page 5 Instructions To open the stroller Gently prise open the safety catch and lift the handle of the pram until the chassis clicks into place. Front wheel Installation Installation: insert the front wheel axles into the connect hole until you hear a click sound, make sure it's installed in place.Repeat thisprocess for both swivel wheels.
  • Page 6 Instructions The front wheels directional use Push in the upper part of the direction lock to lock the front wheel (as A shows), push up the button to achieve 360degree rotation (as B shows). Remove the front wheels Press down the quick release button of the front wheels to release the front wheel.
  • Page 7 Instructions Rear wheel assembly Adjust the direction of the rear axle, make sure you have correctly lined up the flat edge on the axle with the flat edge of the hole. Then push the rear axle into the hole, until you hear a click sound. Ensure that it is engaged before use.
  • Page 8 Instructions To use brakes 1.Step down the brake pedal until you hear a click sound to engage brake mechanism(A). 2.Lift up the brake pedal to unlock the brakes(B). WARNING: Please ensure the brakes are always applied when the stroller is not in use.
  • Page 9 Instructions Canopy release Pull the brackets of the canopy off the metal construction to release. Mounting Seat Unit Position the seat unit connectors above the connection points on the chassis and press down until you hear a clicking sound. The seat unit can be parent facing or world facing.
  • Page 10 Instructions Release Seat unit Press in the release buttons on each side of the seat unit, and lift the seat unit off the chassis. Leg rest adjustment 1.Press the adjustable button both sides at the same time to push it up. 2.Press the adjustable button both sides at the same time to push it down.
  • Page 11 Instructions To use bumper/ safety bar Install: Hold the bumper bar, slide Releasing the bumper bar: Push two the bumper tips into the connection buttons of each side of the bumper bar points until you hear a clicking sound. while pull it out. Push the button on either side of the bumper bar whilst pulling on the bar.
  • Page 12 Instructions Backrest adjustment The back rest is adjusted via the pull belt with clasp.To adjust the backrest,pull the belt while holding the clasp to set the seat in sitting position.Pull the ring on the clasp and pull the clasp down to release the seat to liying position.

  • Page 13: Folding The Pushchair

    Instructions Folding the pushchair IMPORTANT: Always remove your child from the pushchair prior to installation or folding. 1.The direction of the seat must be forward and adjust the seat unit to minimum angle ,make the handle into its original status or lower status when be folded.Remove the seat unit or ensure it is world facing.
  • Page 14 Instructions Collect and put stroller To minimize the volume of the folded stroller, make the adjustable handle into smallest section before folding.(show as A). Care and maintenance 1.Fabric:sponge clean only with a mixture of water and mild detergent. Do not iron. Do not bleach. 2.Periodically check for loose and broken parts.
