HAUSSLER Patio heater Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating instructions
Patio heater
Original operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Patio heater and is the answer not in the manual?

Questions and answers

Summary of Contents for HAUSSLER Patio heater

  • Page 1 Operating instructions Patio heater Original operating instructions...

  • Page 2: Table Of Contents

    Contents 1 Welcome… ......................3 to the world of milling, kneading, baking, and pasta-making! ........ 3 For your safety ....................4 Table of symbols ...................... 4 Intended use ......................4 Basic rules ........................ 4 Safety information ....................4 3 Product guide .....................6 Product description ....................

  • Page 3: Welcome

    Häussler. You have decided to purchase the patio heater. With its contemporary look and the flame generated, the patio heater adds an unforgettable, appealing atmosphere to any environment while radiating cosy warmth.

  • Page 4: For Your Safety

    Häussler are the only ones that may be used. The patio heater is only intended for use as a radiant warmer. The use of any fuel other than wood pellets is prohibited. Any other use shall be considered improper use.
  • Page 5 Do not leave infants, children, or animals unatten- ded in the vicinity of the patio heater.  Let the patio heater cool down completely before touching it. ⚠ Risk of burns from high flames ...

  • Page 6: Product Guide

    Product guide 3 Product guide Product description With this patio heater, you have purchased a very high-quality radiant warmer and a wonderful landscape light. The patio heater is simple to operate, easy-care, and requires virtually no maintenance. Technical data Name...
  • Page 7 Product guide Heat output 15 kW Radiant heat Up to 3 meters Burning period Up to 3.5 hours Tab. 2: Technical data...

  • Page 8: Scope Of Delivery

    Glass insert Grate Burner cartridge Adjusting bolt Patio heater base frame Tab. 3: Scope of delivery Setting up the device  Use Table 4 “Scope of delivery” to help you check the delivery for completeness.  Two people should carefully lift the device due to its high weight. Always set it down on a stable, even work surface.

  • Page 9: Assembling The Device

     The second person now screws in the bolts ma- nually and uses a spanner to tighten them hand- tight crosswise.  Proceed as described above with all tables 5 . Your patio heater is now set up and ready to use.

  • Page 10: Illustrated Set-Up Instructions

    Scope of delivery Illustrated set-up instructions Insert the glass insert Check the glass insert Caution: Fragile Due to the high weight, two When placing the glass insert, make persons should do the work. sure that it is completely mounted in the Lift the glass insert and place it on the base housing.
  • Page 11 Scope of delivery Table assembly Tighten the screws Use a spanner (WAF 10) to tighten the The second person holds the table in screws crosswise. position. First, screw in the table attachment screws hand-tight.

  • Page 12: Fuel To Be Used

    Fuel to be used 5 Fuel to be used ⚠ WARNING Risk of fatality from explosion Darting flame  Never use easily and highly flammable liquids such as denatured alcohol, etc.  Never use an accelerant on pellets that have been fired up and are warm. ⚠...
  • Page 13 Fuel to be used Burning aids Only use wood shaving bundles soaked in wax as a burning aid. They are toxin-free, have a neutral odour and taste, and burn without leaving residue behind. Helpful hint: Wood shaving bundles Wood shaving bundle soaked in wax. Burning period 8-10 minutes.

  • Page 14: Filling And Firing Up

     Ensure that the patio heater is in a stable, even upright position.  In strong wind, ensure that the patio heater is set up in a protected place. A strong gust of wind could lift the cowl off the patio heater.

  • Page 15: Filling Capacity

    Filling and firing up  Before filling with pellets, make sure that the grate is in the firing chamber. Before refilling with wood pellets, make sure that the residual ashes from the previous fire has been removed from the firing chamber and the grate is clean. Filling capacity Designation Air supply hole...

  • Page 16: Illustrated Filling And Firing Up Instructions

    Filling and firing up  Before filling the burner cartridge, make sure that the grate is in place.  Fill the burner cartridge with pellets until just below the air supply holes. In the illustration, the filling level limit B is depicted as a red line. ...
  • Page 17 Pull out the adjusting bolt. The patio heater requires approx. 15 min. to develop a full flame. While the flame is developing, you may hear hissing similar to that of a Bunsen burner. The noise dies down as soon as the flame has fully developed. Afterwards, the hissing noise is audible but very weak.

  • Page 18: Cleaning

    Severe burns on arms and legs  Let the glass insert cool down completely before cleaning it.  Let the patio heater cool down completely before touching it.  After each use, remove the ashes from the burner cartridge and firing chamber of the patio heater.

  • Page 19: Maintenance

    Maintenance 8 Maintenance  Before each use, check the patio heater for damage. In case of damage, replace the defective part(s) before firing up again.

  • Page 20: Troubleshooting

    Troubleshooting 9 Troubleshooting Problem Cause Resolution No flame visible Flame extinguished  Fire up the pellets again. after firing up Flame is too small The burner cartridge  Let the pellets burn out. Wait and grate were not until the device has cooled down cleaned before resolving the problem.

  • Page 21: Transport Dolly And Refill Cartridge

    Transport dolly and refill cartridge 10 Transport dolly and refill cartridge Transport dolly With the transport dolly, you can safely move the patio heater. With the integrated bracket for the burner cartridge, you can safely transport hot and cold refill cart- ridges.

  • Page 22: Refill Cartridge

     When handling the burner cartridge, always wear heat protection mitts. With the refill cartridge for your patio heater, you have the option to refill the patio heater quickly and safely. You can safely set down and transport hot cartridges.

  • Page 23: Disposal

    Disposal 11 Disposal  Keep the patio heater clean at all times and when disposing of residual materials.  Do not remove the ashes until they have completely cooled down.  Only use the intended containers made of metal or noncombustible materials to dispose of the residual waste or ashes.

  • Page 24: Accessories

    Patio heater grate Grate for patio heater. Item number: 055616 Refill cartridge With the refill cartridge for your patio heater, you have the option to refill the patio heater quickly and safely. Item number: 304053 Transport dolly With the transport dolly, you can safely move the patio heater.
  • Page 25 Accessories Häussler pellet starter Our pellet starter is made from 100% raw materials from plants. It contains no paraffins and burns cleanly without any soot. We avoid using fragrances and colourants. Item number: 301011 Wood pellets Our wood pellets consist of dried, untreated wood and are produ- ced without the addition of any chemical binding agents.

  • Page 26: Warranty

    Warranty 13 Warranty You will receive a 12-month factory warranty on your device, beginning on the date of the invoice. Karl-Heinz Häussler GmbH produced your device in accordance with the technological state of the art. All devices that leave our factory are made from high-quality materials and were thoroughly inspected.

  • Page 27: For Your Notes

    For your notes 14 For your notes...
  • Page 28 Visit our baking centre… Under the name of Häussler, we have devoted our work to the pleasure of doing it yourself for more than 40 years. We are a family-run company with more than 90 employees and our headquarters is in Heiligkreuztal/Upper Swabia.
  • Page 29 Our service for you  Information on other destinations and places to stay in the area  Cosy consulting rooms  Children’s play area  Guest toilets with changing tables  Seating  Loading service  On-site service for your devices on our premises We also offer you ...
  • Page 30 Karl-Heinz Häussler GmbH Nussbaumweg 1 88499 Heiligkreuztal, Germany Telephone +49 73 71/93 77-0 Fax + 49 73 71/93 77-40 Email: info@backdorf.de Version: 11/03/2020...
