Installation instructions
Uponor Push 45U and Uponor Push 45U Electronic
Uponor Push 45U and Uponor Push 45U Electronic must be fi tted
horizontally, with the manifold either on the left or the right. An
Uponor WGF By-pass XL 900 valve must be fi tted to each
underfl oor heating manifold where manifold actuators are fi tted.
At least four manifold assemblies each with a by-pass valve should
be fi tted in the secondary circuit. Alternatively, a larger valve with
suffi cient capacity can be used.
Installationsanvisningar
Uponor Push 45U och Uponor Push 45U Electronic
Uponor Push 45U och Uponor Push 45U Electronic skall monteras
med pumpaxeln horisontellt och kan monteras valfritt i höger-
eller vänsterutförande. I system med styrdon måste en by-pass-
ventil, Uponor WGF By-pass XL 900 eller liknande, monteras för
att säkerställa ett fl öde igenom pumpen.
Monteringsanvisning
Uponor Push 45U og Uponor Push 45U Electronic
Uponor Push 45U og Uponor Push 45U Electronic skal monteres
horisontalt og kan monteres valgfritt i høyre- eller venstreutfø-
relse. Ved bruk av romregulering må det monteres en trykkstyrt
by-passventil i gulvvarmeanlegget med tilstrekkelig kapasitet.
Dette for å unngå trykkoppbygging i anlegget ved lite forbruk.
Installationsvejledning
Uponor Push 45U og Uponor Push 45U Electronic
Uponor Push 45U og Uponor Push 45U Electronic skal monteres
horisontalt og kan monteres valgfrit i højre- eller venstrevendt
udførelse. En bypassventil med en kapacitet på 3600 l/h ved et
trykfald på 35 kPa bør monteres på hver gulvvarmefordeler, der er
udstyret med en telestat.
Asennusohjeet
Uponor Push 45U ja Uponor Push 45U Electronic
Uponor Push 45U ja Uponor Push 45U Electronic on asennettava
vaakasuoraan, joko oikea- tai vasenkätiseksi. Koska Uponor Push 45U
ja 45U Electronic ovat tarkoitetut isoihin järjestelmiin, niin lattialäm-
mitysjakotukki on varustettava Uponor WGF By-pass XL 900 -ohitus-
putkella, jos järjestelmässä on toimilaitteita. Vähintään neljä XL 900
-ohitusputkea on asennettava toisiopuolelle. Vaihtoehtoisesti voidaan
käyttää yhtä suurempaa venttiiliä, jonka suorituskyky on riittävä.
U N D E R F LO O R H E AT I N G
U P O N O R P U S H 4 5 U /
P U S H 4 5 U E L E C T R O N I C
Uponor Push 45U Electronic
Uponor Push 45U Electronic must be fi tted in a dry, frost-proof
location, with the central unit fi tted to the pump and shunt
group. Fit the outdoor sensor in a wind-sheltered location on the
north-facing exterior wall of the building. Connect the outdoor
sensor's signal cables and, where appropriate, those for the indoor
sensor to the central unit at their respective inputs.
Uponor Push 45U Electronic
Se till att centralen monteras över pumpgruppen. Utomhusgivaren
monteras på en vindskyddad plats på husets norra yttervägg och
kopplas in i centralens ingång.
Uponor Push 45U Electronic
Uponor Push 45U Electronic skal monteres på et tørt og frostfritt
sted, da regulatoren er montert på pumpe- og shuntgruppen.
Monter utegiveren på et vindbeskyttet sted på husets nordvegg.
Fra utegiveren strekkes signalkabel som tilkobles regulatoren. Om
ønskelig kan innegiver, bestilles separat, tilkobles regulatoren.
Uponor Push 45U Electronic
Uponor Push 45U Electronic skal monteres på en tør og frostfri plads,
hvor centralenheden er monteret på pumpe- og shuntgruppen. Mon-
ter udendørsføleren på en vindafskærmet plads på husets nordlige
ydervæg. Tilslut udendørsfølerens og – hvis den er monteret – inden-
dørsfølerens signalkabler i centralenheden i de respektive indgange.
Uponor Push 45U Electronic
Uponor Push 45U Electronic on asennettava kuivaan ja ruostu-
miselta suojattuun paikkaan, koska keskusyksikkö on asen-nettu
pumppu- ja sekoitusryhmään. Asenna ulkoanturi tuulelta suojassa
olevaan paikkaan talon pohjoisen puoleiseen ulkoseinään. Kytke
ulkoanturin ja tarvittaessa myös sisäanturin ohjauskaapelit kes-
kusyksikköön niille tarkoitettuihin liitäntöihin.
U P O N O R V V S
03 | 2009
5124

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Push 45U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Uponor Push 45U

  • Page 1 Uponor Push 45U and Uponor Push 45U Electronic Uponor Push 45U Electronic Uponor Push 45U and Uponor Push 45U Electronic must be fi tted Uponor Push 45U Electronic must be fi tted in a dry, frost-proof horizontally, with the manifold either on the left or the right. An location, with the central unit fi...
  • Page 2 Wirsbo Uponor Push 45U Uponor Push 45U Electronic 280 mm G1” G3/4” 240 mm 380 mm Setting the temperature for the control section for Uponor Push 45U Index Approx. supply temperature, °C...
  • Page 3 The control valve (1) which is supplied should be function test the central unit by fi rst resetting mini- installed when the Uponor Push 45U is installed in a switch 1 (see separate operating instructions). The mixed heating system, in a secondary district heating external temperature sensor must be fi...
  • Page 4 Största tillåtna tryckfall över termostatventilen är 45 kPa. Installation av Uponor Push 45U Electronic Uponor ECL Comfort 100 levereras förmonterad. Backventil Observera att Uponor ECL Comfort 100 levereras med Bipackad backventil skall användas då dessa pump- sommarurkoppling aktiverad. Uponor ECL Comfort 100 grupper installeras i sekundära fjärrvärmenät.
  • Page 5 Trykkfall over termostatventil Uponor ECL Comfort 100 leveres forhåndsmontert. Høyeste tillatte trykkfall over termostatventilen er Legg merke til at Uponor ECL Comfort 100 leveres med 45 kPa. aktivert sommerutkobling. Uponor ECL Comfort 100 kobles dermed ut så snart utetemperaturen overstiger 18°C.
  • Page 6 Installation af Uponor Push 45U Electronic Trykfald gennem termostatventil Uponor ECL Comfort 100 leveres formonteret. Vær op- mærksom på, at Uponor ECL Comfort 100 leveres med Det størst tilladte trykfald gennem termostatventilen er sommerfrakoblingen aktiveret. Uponor ECL Comfort 45 kPa.
  • Page 7 Huomaa, että toimitettaessa Takaiskuventtiili Uponor ECL Comfort 100:n kesäajan irtikytkentätoi- minto on käytössä. Uponor ECL Comfort 100 kytkey- Pakkauksessa olevaa takaiskuventtiiliä käytetään sil- tyy pois käytöstä, kun ulkolämpötila nousee 18 ºC loin, kun Uponor Push 45U asennetaan toisiopuolelle yläpuolelle.
  • Page 8 1,8 l/s Uponor AB 0223-380 00 Box 2 0223-387 10 721 03 Västerås W www.uponor.se Uponor AB, Sverige förbehåller sig rätten att utan föregående meddelande ändra specifi kationen av ingående komponenter i enlighet med sin policy om kontinuerlig förbättring och utveckling.
