Summary of Contents for Priva FS Cradle
- Page 1 Installation manual FS Cradle...
- Page 2 This publication has been developed with care. However, the products shown may differ in dimensions and design from the actual products. Priva B.V. will not accept any responsibility for damages caused by any errors or deficiencies in this publication. Priva B.V. may modify its products and the associated manuals without prior notice.
- Page 3 FS Cradle FS Cradle – Installation manual – 1.2...
-
Page 4: Table Of Contents
Commissioning ............................13 Operation ......................13 Taking out of operation .................. 14 Troubleshooting ....................14 Troubleshooting - general ........................14 Maintenance and repair ................. 15 Disposal of waste equipment ................ 16 Appendices ....................... 17 FS Cradle – Installation manual – 1.2... - Page 5 EC Declaration of Conformity ......................17 Technical specifications ........................18 FS Cradle – Installation manual – 1.2...
-
Page 6: About This Manual
About this manual Aim and scope This manual concerns the FS Cradle, a docking and recharging module for use with the FS Reader in the horticulture industry. This manual contains all of the information required to safely and correctly transport, install, commission and maintain the FS Cradle. -
Page 7: Explanation Of Symbols In This Document
Information Terms and abbreviations The list below states the abbreviations and terms relating to the Priva labour and production registration units of FS Performance. Therefore, abbreviations and terms that do not apply to your specific unit and as a result are not used in this manual may still be found in the list below. -
Page 8: Safety
Keep the product clean and the surroundings tidy. • Report faults or damage to Priva immediately. Inactivate the equipment and do not use it if a deficiency is observed. Only use original spare parts for repairs (refer to the price list). -
Page 9: Installation
Installation Only Priva approved installers are allowed to install and configure the product. Troubleshooting In case of problems, in most cases a message will be generated. This manual describes the problems you might be able to solve yourself. FS Cradle – Installation manual – 1.2... -
Page 10: Product Description
Functions and intended use Functions The FS Cradle should be used to activate new FS Readers that will be operated for the first time. Placing the FS Reader in the FS Cradle triggers the FS Reader: To awake from its ‘transport mode’. -
Page 11: Transport And Storage
• 2 plugs and 2 screws for mounting the FS Cradle to a wall. 4 rubber base sticky feet for positioning the FS Cradle on a flat surface. • Separate from the package, a power cord is delivered with the FS Cradle. -
Page 12: Installation - Positioning The Unit
For mounting the FS Cradle to a wall: • Select a wall that is amply strong enough to hold the weight of the FS Cradle and that can withstand the repeated pressure of putting FS Readers into the charging positions of the FS Cradle. -
Page 13: Installation - Electrical Part
The installer makes sure that the led on the FS Cradle is on. The installer places the FS Reader in each of the docks on the FS Cradle, to ensure that each of the docks can charge an FS Reader. -
Page 14: Taking Out Of Operation
Priva B.V. Taking out of operation In order for the FS Cradle to be taken out of operation, the following steps need to be undertaken: The installer disconnects the power cord. In case the FS Cradle is mounted to the wall, it should be lifted from the mounting screws. -
Page 15: Maintenance And Repair
Connect the power cord to the FS Cradle and power socket. If the FS Cradle is in need of repair, the customer will contact Priva B.V. after which the product can be sent back to Priva B.V. for repair or possible replacement. -
Page 16: Disposal Of Waste Equipment
FS Cradle – Installation manual – 1.2... -
Page 17: Appendices
(SRD) operating on frequencies between 9 kHz and 40 GHz EN 55022:2011 Information technology equipment - Radio disturbance characteristics - Limits and methods of measurement The technical file was compiled by the department Product Development of Priva B.V. The Netherlands, De Lier, March 2015 M. Prins Managing Director... - Page 18 10 .. 95 % Ambient pressure: 70 .. 105 kPa Operating conditions: • Temperature (ambient): 0 .. 40 °C Temperature change: max 30 °C / day Relative humidity: 20 .. 95 % Approvals / certifications: • FS Cradle – Installation manual – 1.2...
- Page 19 FS Cradle – Installation manual – 1.2...
- Page 20 Priva B.V. Priva B.V. P.O. Box 18 I www.priva.nl Zijlweg 3 2678 ZG De Lier E contact.priva@priva.nl 2678 LC De Lier Nederland Nederland FS Cradle – Installation manual – 1.2...
