Filming in a New Dimension
_____________________________________________


Thank you for buying the STABILMOVE Camera Crane. You have purchased a tool that will enable
you to create stabilised video camera shots, including flawlessly smooth pans and pivots that were
previously only possible with great technical effort.
Please note the following safety tips:
The camera arm must be used appropriately, which means that the amount of counterweight as well
as the pivoting degree should not exceed the specified ranges.
Manual operation is required for each movement. Be aware of the risk of pinching yourself while
manipulating the crane, and be sure to ensure a free range of pivoting.
Never leave the mounted arm unattended.
The manufacturer cannot be held responsible for any damage caused by incorrect use.
Damaged parts can compromise not only your safety, but the protection of the camera and its
functional reliability. Therefore, please have all essential repair work be carried out by STABILMOVE.
Incorrect repairs and structural alterations can damage the arm and/or the camera as well as lead to
physical injuries.
Always ensure to correctly attach the arm to the tripod and the camera to the arm. Make sure the
control knob is secured at the quick change plate. Always ensure a balanced setting, and make sure
that correct counterweight is added to the camera's net weight where appropriate to the ball head.
When loosening the red knobs, turn them only slightly past their built-in stop. Otherwise you will
destroy the safety measure in place to protect their hold.
Protect your STABILMOVE Crane from moisture, and make sure to keep all dust, dirt, and other
contaminants away from the ball bearings.
When in doubt, please contact info@stabilmove.de.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C 620 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stabilmove C 620

  • Page 1     Thank you for buying the STABILMOVE Camera Crane. You have purchased a tool that will enable you to create stabilised video camera shots, including flawlessly smooth pans and pivots that were previously only possible with great technical effort.
  • Page 2 Mount the ball head onto the camera crane and then your camera onto the ball head. With each attachment, don’t forget to lock the safety catch into place. Balance the crane and turn the red STABILMOVE Knob A slightly. Now pull the arm out until the crane is in equilibrium. Then gently tighten the knob again.
  • Page 3 Make sure the base setting of the guide arm is aligned at an exact right angle to the camera crane. Parallel Panning shot For this shot, adjust the red STABILMOVE Knobs D and E at the exterior insets of the guide arms. Turn the knobs only slightly.
