CLS Atmosphere LED-panel
Thank you for choosing the CLS Atmosphere Panel. The Atmosphere panel is a fixture which uses LED color
mixing to create a color changing surface, in a 4 segment configuration. With this technique it is possible to create
a wide range of colors and patterns, making this unit suited for a wide range of decorative and architectural
applications.
The Atmosphere panel offers:
• 4 controllable RGB segments.
• High efficiency LED light source
• Decorative housing
• Rich saturated colors.

Included items

The CLS Atmosphere is shipped in one package containing the following items:
• 1 CLS Atmosphere panel
• 1 AC power cord
• 4 Wall mount adapters

Optional Accessories

• Handheld remote controller
• RJ45-XLR 3p male & power cable
• Cat 5 cable 2.0 meter
• Cat 5 cable 5.0 meter
• Cat 5 cable 10.0 meter
• Cat 5 cable 20.0 meter
Note: It is important to read this manual before you install this product.

SAFETY INFORMATION

Warning! This product is for professional use only, not for domestic use. Read this manual before
powering up or installing the CLS Atmosphere Panel. Follow the instructions listed below and
observe all warnings in this manual.

Protection from electric shock

• Disconnect the fixture and from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Always use end caps on non used 2 pole female power connectors.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• Do not expose the fixtures to rain or moisture.
• Refer all service to a qualified technician.
• 1 RJ45 data cable
• 2 AC power end caps
• 1 user manual
(item nr. 872305)
(item nr. 872307)
(item nr. 706667)
(item nr. 706668)
(item nr. 706669)
(item nr. 706672)
