Optional / Optionnel / Opcional
Lock tilt / Inclinaison vérouillée / Cerradura de la función de inclinación
463589 rev01
SWIFT110
25"
Read through ALL instructions before commencing installation.
Lisez toutes les instructions avant de débuter l'installation.
Lea todas las instrucciones antes de empezar la instalación.
www.swiftmount.com
Swift Mount, PO Box 340, Telford, TF1 9DS, UK
Swift Mount, Chino MBO 532, Chino, CA 91708-9998, USA
64cm
33lbs
15kg
+44 (0)3333 200490 (UK)
1-800 875 0182 (USA)
Advertisement
Table of Contents
Related Manuals for Swift Mount SWIFT110
Summary of Contents for Swift Mount SWIFT110
- Page 1 Lisez toutes les instructions avant de débuter l'installation. Lea todas las instrucciones antes de empezar la instalación. www.swiftmount.com Swift Mount, PO Box 340, Telford, TF1 9DS, UK +44 (0)3333 200490 (UK) Swift Mount, Chino MBO 532, Chino, CA 91708-9998, USA...
- Page 2 55mm (2 ") Haut Parte Superior M4 x 12mm Remove dust from hole Retirez la poussière du trou Ø8mm (5/16") Haut Elimine el polvo del agujero Parte Superior Lubricate screw thread with soap Lubrifiez le pas de vis avec du savon Lubrique la rosca del tornillo con jabón 50mm (2") Ø3mm (1/8")
