Summary of Contents for AusPress VETEC SPM24
- Page 1 Vetec Instruction manual SPM24 c i l Press-Fit, Drainage & Tooling Solutions 127 Corunna Avenue, Melrose Park SA 5039 Phone: 1300 287 773 Email: sales@auspress.com.au Visit us at: www.auspress.com.au...
- Page 2 Vetec SPM24 Please read this instruction manual carefully before you use our product. If you have any doubt or problem, contact our Servicecenter. (Informations are on the last cover page) BLUSPM24 SPM24...
- Page 3 Vetec SPM24 Index Technical data Defi nition of components Accessories supplied with the basic unit Description of signs and symbols General indications Application and use not in conformity with the intended purpose Precautions in using the equipment Storage and transportation...
- Page 4 Vetec SPM24 Technical data Shearing force: 24 kN Max. Lift: 30 mm Battery voltage: 18 V DC Motor: with permanent magnets in continuous current Battery capacity: 1,5 Ah (optionally 3,0 Ah) Time of pressing cycle approx. 3-4 sec. Type of battery: Li-Ion (without memory eff...
- Page 5 Vetec SPM24 Accessories supplied with the basic unit Item Definition [ 1 ] Power pack [ 2 ] Battery charger [ 3 ] USB 2.0 cable with 5 pole mini type connectors: A plug and B socket [ 4 ]...
- Page 6 Vetec SPM24 Description of signs and symbols Danger: Th is indicates a warning; lack of observance may lead to injury or death. Paragraphs: Product safety information. Caution/Important: Th is indicates a warning; not following this warning may lead to da- mage of the equipment or materials.
- Page 7 Vetec SPM24 Precautions in using the equipment Caution: Th e non-observation of the safety instructions may create a situation of danger for the life and health of persons, or may cause material damage to the machine and the surrounding environment!
- Page 8 Vetec SPM24 and can cause situation of danger. Caution: Th e typical A-weighted noise level can exceed 70dB (A) during the working pro- cess. - wear ear protection! Caution: Th e equipment may be operated only with the original BLUCHER power packs.
- Page 9 Vetec SPM24 Instructions for the use of the power pack and battery charger Th e battery charger has dimensions for 230 V CA 50-60 Hz. Th e new batteries are provided partially charged and must be charged before the machine is used for the fi rst time. In order to recharge the battery charger plug must be inserted in a wall socket and the power pack must be placed in the battery charger.
- Page 10 Vetec SPM24 Application ranges max. DN 35* Stainless steel, steel max. DN 35* Copper, copper alloys max. DN 40* Multilayer pipe max. DN 40* PEX-pipe *Specifications/data are system-bound For further information please contact your systems provider Insertion of pressing jaws Open lever [1] by rotating it 180°...
- Page 11 Vetec SPM24 Work process pressing Th e pressing process is carried out automatically on pressing the start/stop button [4] on the handle. Th e resulting connection is permanent and longitudinal force-locked. Th e operation can be interrupted 1. during the initial phase by releasing the start/stop button [4] 2.
- Page 12 Vetec SPM24 Technical and Functional Features • Th e body of the pump and all components are made of high resistance materials and tes- ted. • Th e casing is entirely made of isolating, shock resistant polyamide, reinforced with fi breg- lass.
- Page 13 Vetec SPM24 What to do in case of breakdown In case of failure the crimping/cutting tool is shut down automatically and remains blocked. In case of failure the crimping/cutting tool is shut down automatically and remains blocked. Th e service LED illuminates red or orange. Further process is only possible by changing the Th e service LED illuminates red or orange.
- Page 14 Vetec SPM24 Failure Cause / trouble shooting red light Charging process starts red fl ashing Battery to hot or too cold green light Battery charged green fl ashing Battery defect Extraordinary maintenance/disposal Th e individual components of the group must be disposed of separately. First of all it is neces- sary to drain the oil which must be taken to a special disposal centre.
- Page 15 Vetec SPM24 waste after its normal working life, must be taken to a waste-sorting centre for electrical and electronic appliances or returned to the retailer at the time of purchasing a new equivalent appliance.Th e user is responsible for taking the appliance to the appropriate waste collection centre at the end of its working life.
- Page 16 Vetec SPM24 10.000 cycles, whatever come first. This is in order to guarantee a proper function of the tool. A flashing Service LED on the tool refers the scheduled maintenance. The unit should be cleaned after each use and dry stored. Both battery and charger must be protected against moisture and foreign matter.
- Page 17 EC DECLARATION OF CONFORMITY DECLARACIÓN CE DE CONFORMIDAD DÉCLARATION CE DE CONFORMITÉ Nous AusPress Systems Pty Ltd (Name des Herstellers) (nome del fabbricante) (manufacturer’s name) (nombre del fabricante) (nom du fabricant) 127 Corunna Avenue, Melrose Park SA 5039 (Anschrift) (indirizzo) (address) (dirección) (adresse) erklären in alleiniger Verantwortung, dass das Produkt...
- Page 18 Art.-No.: ....BDA-BLUSPM24 ....BDA-APSPM24 Date: ......28.10.2015 01.09.2019 Version: ........3.0 1 Service...
