MODELS: P20X (Attachment for LRH5024V HT31S-5015D)
COBRA POLESAW ATTACHMENT
FOR LRH5024V
OWNER'S MANUAL
Cobra Garden Machinery
Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK
www.cobragarden.co.uk
WARNING：
For your own safety please read this manual before attempting to operate your new unit. Failure to follow
instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your
garden tool before each use. Keep this manual in a safe place, so that the information is available at all
times. If you give the equipment to any other person, hand over these operating instructions and safety
regulations as well.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P20X and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra P20X

Summary of Contents for Cobra P20X

  • Page 1 MODELS: P20X (Attachment for LRH5024V HT31S-5015D) COBRA POLESAW ATTACHMENT FOR LRH5024V OWNER’S MANUAL Cobra Garden Machinery Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK www.cobragarden.co.uk WARNING： For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury.
  • Page 3 Fig.1 Fig.2 Fig.3 Fig.5 Fig.4 1Kg/force Fig.6 Fig.7...
  • Page 4 60mL Fig.8 Fig.9 Fig.11 Fig.10 Fig.13 Fig.12...
  • Page 5 Fig.14 Fig.15 Fig.17 Fig.16 Fig.19 Fig.18...

  • Page 6: Table Of Contents

    Fig.20 Operating Instructions Please read the LRH5024V manual before operating, follow all safety instructions along with those provided in this manual. Contents 1. General power tool safety warnings; Pole chain saw safety warnings and Special safety instructions 3. Special use 4.

  • Page 7: General Power Tool Safety Warnings

    1. General power tool safety warnings WARNING—Reading the operating instructions will reduce the risk of injury. WARNING—Reading all safety risk of injury warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire or serious injury. 1.1 Working area safety a) Keep the working area clean and well illuminated.
  • Page 8 unexpected situations. f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. 1.4 POWER TOOL USE AND CARE a) Do not force the power tool.

  • Page 9: Pole Chain Saw Safety Warnings And Special Safety Instructions

    center. * Do not operate this tool while under the Influence of drugs, alcohol or any medication. * The appliance is not intended for use by young or infirm persons. * Young children should be supervised to ensure that they do not play with the appliance. * The use of an earth-leakage circuit Breaker of residual current device in conjunction with this tool is recommended.

  • Page 10: Special Use

    procedures or conditions and can be avoided by taking proper precautions as given below: ** Maintain a firm grip, with thumbs and fingers encircling the pole chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback force. Kickback forces can be controlled by the operator, if proper precautions are taken.

  • Page 11: Service

    4. SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service Technician. For service we suggest you return the product to your nearest AUTHORISED SERVICE CENTRE for repair. When servicing use only identical replacement parts. WARNING: To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand completely the operator's manual.
  • Page 12 *Stop the motor and remove the battery before setting the chain tension. Make sure the guide bar nut is loose to finger tight, turn the chain tensioning screw clockwise to tension the chain. Note: A cold chain is correctly tensioned when there is no slack on the underside of the guide bar, the chain is snug, but is can be turned by hand without binding.
  • Page 13 *Keep bystanders at least 15m away. Fig.12-13 preparation *Wear non-slip gloves for maximum grip and protection. *Maintain a proper grip on the unit whenever the motor is running. Use your right hand to firmly grip the rear handle while your left hand has a firm grip on the pole shaft. *Hold the unit firmly with both hands.

  • Page 14: Technical Data

    Fig. 20 Clean all foreign material from the product. Always place the scabbard on the saw bar when transporting or storing the pole chain saw. The scabbard is a snug fit and must be attached very carefully due to the sharp teeth on the saw chain. This is best done by grasping the scabbard at one end, in the center portion of the scabbard, and carefully sliding it over the chain.

  • Page 15: Maintenance

    8. Maintenance (Fig. 14-20) 8.1 Chain Sharpening When the chain penetrates into wood with difficultly, it needs sharpening as follows: * Put the chain under tension. * Fasten the bar in a vice so that the chain can slide. * Fasten the file to the file holder and place it on cutter at a 35º angle. * File with forward strokes only until all the worn out part of the cutting edge is taken away.

  • Page 16: Disposal

    9. Accessories or repair part Use only genuine Cobra accessories or repair parts. If you need any accessories, check with your dealer. The main accessories (Chain & Bar) are as below: Model Chain & Bar Oregon Chain 90JG033X & Bar 084MLEA041 Oregon Chain 90PJ033X &...
