EMBASSY™ HIGH CHAIR
Assembly Instructions. Adult Assembly Required.
Read all instructions before use.
This manual is part of the product and
must be kept for future reference.
MODEL NUMBERS*:
00933 - Natural
00934 - Cherry
00936 - Espresso
VERSION CODE*:
3.0/0517/TG
* Model and Version numbers are needed
if replacement parts are requested
FOR REPLACEMENT PARTS:
http://www.badgerbasket.com/parts
Badger Basket, PO Box 227, Edgar, WI 54426-0227 USA • Web: www.badgerbasket.com
U.S. Based Customer Service Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310
Phone: 715-352-2311 • Fax: 715-352-3163
3.0/0517/TG
Advertisement
Related Manuals for Badger Basket EMBASSY 00933
Summary of Contents for Badger Basket EMBASSY 00933
- Page 1 * Model and Version numbers are needed if replacement parts are requested FOR REPLACEMENT PARTS: http://www.badgerbasket.com/parts Badger Basket, PO Box 227, Edgar, WI 54426-0227 USA • Web: www.badgerbasket.com U.S. Based Customer Service Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310 Phone: 715-352-2311 • Fax: 715-352-3163 3.0/0517/TG...
-
Page 2: Before You Begin Assembly
/!\ Read all instructions before beginning /!\ BEFORE YOU BEGIN ASSEMBLY: Check all parts and hardware. If anything is missing or not satisfactory, please DO NOT call the store or return the product to them. Please go online to http://www.badgerbasket.com/parts for assistance. - Page 3 • READ ALL INSTRUCTIONS before use of this product. Keep instructions for future use. • Use only the parts and hardware provided by Badger Basket. • Do not use the product if it is damaged, broken, torn, or missing parts.
- Page 4 NOTICE! Proper maintenance of your Embassy™ chair will ensure years of use and enjoyment. Retain these instructions and review and follow them regularly. After initial assembly, keep the ALLEN WRENCH in a safe place! Check and retighten all hardware 1-2 weeks after initial assembly. Thereafter, check to make sure all the hardware remains tight at least on a monthly basis.
- Page 5 PROPER USE OF THE 5 POINT SEAT HARNESS: SEE FIGURE A (BELOW) - YOUR MODEL OF CHAIR MAY VARY FROM SHOWN BUT SEAT HARNESS WORKS THE SAME WAY: When your child is sitting in the high chair, the shoulder straps (3) come up BEHIND the chair and OVER THE TOP OF the CURVED BACK PIECE and then down over the child’s shoulders to hook to the harness buckle in front.
-
Page 6: Parts List
Parts list 1x Left Side 1x Right Side 1x Bottom Rail 1x Curved Back Piece 1x Wood Tray 1x Curved Front Rail 1x Seat Platform 1x Foot Rest 1x Seat Cushion 1x 5 Point Seat Harness 2x Connecting 1x Plastic Tray Platform 1x Seat Cushion Rods... - Page 7 IMPORTANT: DO NOT TIGHTEN THE BOLTS UNTIL THE CHAIR IS FULLY ASSEMBLED or you will not be able to insert the Seat and Footrest Platforms and the Tray. PLEASE ASSEMBLE THE CHAIR ON A CARPETED SURFACE OR ON TOP OF THE BOX IT CAME IN TO PREVENT SCRATCHES OR DAMAGE DURING ASSEMBLY.
- Page 8 The 5 POINT SEAT HARNESS is pre-attached to the SEAT PLATFORM. It is not shown in the diagrams because no assembly is needed. To ensure proper grip and stability: 1. The FOOT REST PLATFORM must be inserted into the slot at least two (2) inches deep to ensure proper grip and stability.
- Page 9 Put Seat Cushion and Plastic Tray onto the chair. Put the chair into its upright position on a flat, level floor. Level the chair, and then securely tighten ALL of the bolts! IMPORTANT: DO NOT DISCARD THE ALLEN. WRENCH. You MUST regularly check the bolts and retighten as needed using the ALLEN WRENCH included with the chair! Check and retighten 1-2 weeks after initial assembly.
