Firenock AEROVANE User Manual

Congratulations on purchasing the world's most ac-
curate fletching jig. No more guessing on whether the
fletching is exactly 120 degrees apart. With the Aerovane
Jig system and its accessories, every vane fletched is per-
fectly spaced every time.
The Aerovane Jig is available in 2 standard packages:
the Enthusiast Set and the Ultimate Set. Additional ac-
cessories and optional parts can be purchased to make
the Aerovane Jig meet your individual needs.
Arrow
Leveler
Adjustable
Hook
Jig Base
AEROVANE
Long Feather
Adaptor
Jig User Manual
™
Aerovane Jig, and its acces-
sories available for pur-
chase / upgrade (complete
list):
1. Jig Body
2. Clamp
3. Adjustable Neck
4. Base Plate
5. Fixed Chuck
0.166" (for VAP, G nock)
0.204" (Axis, Kinetic)
0.225" (H)
0.244" (GT, CX)
0.285" (CX bolts)
0.300" (Bolts, 22 series)
Pin Nock
6. Slide Hook (up to 1.5 degree
offset capability)
0.204" in red (Axis, Kinetic)
0.244" in black (GT, CX)
0.300" in gold (Bolts, 22 series)
7. Adjustable Chuck
8. Adjustable Hook
9. Arrow alignment Leveler
10. Laser Module
11. Camo case with water cut in-
serts
12. Long Feather Adaptor
13. 3 or 4, optional 7 Index
Adjustable
Chuck
Enthusiast Set includes:
1. Jig Body
2. Clamp
3. Adjustable Neck
4. Base Plate
5. 1 Fixed Chuck of your choice
6. 1 Hook of your choice
7. 3 or 4, optional 7 Index
Ultimate Set includes:
Enthusiast Set plus the following:
1. All 7 Fixed Chucks
2. All 3 Slide Hooks
3. Adjustable Chuck
4. Adjustable Hook
5. Arrow Leveler
6. Laser Alignment Module
7. Long Feather Adaptor
8. 3 or 4, optional 7 Index
9. Deluxe carrying case with wa-
ter cut foam insert
Laser
Module
Jig Body
Adjustable
Neck
Aerovane
Clamp
