Summary of Contents for Aseptiscope DiskCover System
- Page 1 Instructions for Use...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................3 Intended Use ......................3 Warnings and Precautions ................... 4 DiskCover System Components and Accessories ..........4 Description ......................5 Install/Replace Clean Cassette ................6 DiskCover System Use ..................7 Clean/Disinfect Dispenser ..................8 Dispenser Installation ..................8 Install/Replace Batteries .................. -
Page 3: Introduction
The AseptiScope™ DiskCover™ System automates the touch-free application of AseptiScope disk covers to stethoscope diaphragms to ensure hygienic patient contact. The DiskCover System includes a wall-mounted dispenser that houses a Clean Cassette™ containing single-use disk covers. Once applied, the disk cover... -
Page 4: Warnings And Precautions
Do not use the dispenser or Clean Cassette if there is visible physical damage. • Disk covers are single use only. Do not reuse. • Only use Clean Cassettes provided by AseptiScope. • Install only Alkaline C batteries. • Dispose of used Clean Cassettes in accordance with federal, state or local regulations. -
Page 5: Description
*Senses objects that could potentially disrupt the proper advancement and positioning of a new disk cover in the application window. If the sensor is triggered and disk cover halted before being fully placed in the application window, see DiskCover System Use for activation steps. -
Page 6: Install/Replace Clean Cassette
Install/Replace Clean Cassette Figure 1 1. Remove Clean Cassette from protective bag (Figure 1). 2. Remove shipping insert from bottom of cassette (Figure 2). Figure 2 3. Open dispenser lid. 4. If replacing, lift the used Clean Cassette by its handle and remove. 5. -
Page 7: Diskcover System Use
DiskCover System Use Figure 6 1. WAVE: Grasp the back of the diaphragm and wave under the touch-free sensor (right side of the dispenser) (Figure 6). 2. APPLY: After light ring turns green, firmly place the stethoscope Figure 7 diaphragm into the application window. -
Page 8: Clean/Disinfect Dispenser
Clean/Disinfect Dispenser The dispenser can be cleaned with mild soap and damp cloth or with non- abrasive disinfecting agents. Dispenser Installation Figure 10 1. Properly orient wall mount as indicated by up arrows facing outward, ensuring horizontal edge is level and with 7”... -
Page 9: Install/Replace Batteries
Install/Replace Batteries Figure 13 1. Open battery door 2. If replacing batteries, remove depleted batteries and dispose appropriately. 3. Insert three (3) C batteries as shown on the inside battery door, placing center battery in last (Figure 13). Figure 14 4. -
Page 10: Clean Cassette Disposal
Clean Cassette Disposal The Clean Cassette is made from recyclable plastics but contains other materials that cannot be recycled. AseptiScope offers a Clean Cassette recycling service. Contact customer service for details. Light Indicators for Normal Operation Illuminating green light ring... -
Page 11: Troubleshooting
Troubleshooting Disk cover did not adhere to Be sure to hold the back of the stethoscope diaphragm diaphragm (do not hold by the tubing) and firmly place the stethoscope diaphragm into the application window. Be sure stethoscope tubing fits within the notch. Do not use excessive force. - Page 12 The dispenser will not Perform system reboot: activate despite working 1. Remove Clean Cassette and batteries. batteries and a Clean 2. Wait 5 seconds. Cassette is installed with 3. Reinstall batteries. disk covers present, no light If green battery indicator light appears, ensure indicators are present shipping insert is removed and reinstall Clean Cassette.
-
Page 13: Specifications
No lights Ensure the shipping insert has been removed from bottom of Clean Cassette. Ensure Clean Cassette is installed. If a Clean Cassette is not installed properly, no lights will illuminate. If after installing a Clean Cassette, no lights appear replace 3-Alkaline C batteries. Specifications Dispenser: •... -
Page 14: Symbols
Symbols Symbol Definition Symbol Definition Manufacturer Battery indicator Date of Manufacture Activation sensor Lot Number Replace Clean Cassette indicator Serial Number RoHS Catalog Number Do not use if package is damaged Keep dry Temperature Limits 50°C -10°C 95°C Humidity Limits 20°C Consult instructions for use... -
Page 15: Warranty
Warranty AseptiScope warrants the dispenser and Clean Cassette shall be free from defects of workmanship and materials for a period of one (1) year from the date of purchase (the “warranty period”). If, during the warranty period, the dispenser or Clean Cassette fails under normal use and a replacement authorization number is obtained from Technical Support, the manufacturer will replace the dispenser at no cost. - Page 16 Learn More at DiskCover.com AseptiScope.com San Diego, CA 92103 USA Customer Support 1-844-980-2998 LBL-0001-00...
