Summary of Contents for Robur Remote control Eco
- Page 1 Installation and use manual Remote control Eco Control for cooler AD with basic regolation functions...
- Page 2 Proper disposal of this product helps to prevent potential negative consequences for the environment and human health. Revision: A Code: D-LBR755EN This Installation and use manual has been drawn up and printed by Robur S.p.A.; whole or partial reproduction of this Installation and use manual is prohibited. The original is filed at Robur S.p.A.
-
Page 3: Table Of Contents
INDEX OF CONTENTS 1 Preface ................... p. 4 2 Mounting ..................p. 4 3 Electrical hookup ..............p. 4 4 Technical specifications ..........p. 4 5 Operating mode ..............p. 4 6 Command description ............ p. 5 7 Locking/unlocking the remote control unit ....................p. 5 8 Remote control unit on/off ......... -
Page 4: Preface
Change the position of the dip switch of the electronic board of 1: in case of use remote control Evo the cooler, depending on the type of remote control used (Table 5.1 p. 4 ). ON: in case of use remote control Eco... -
Page 5: Command Description
COMMAND DESCRIPTION Table 6.1 Button Action / Result During the parameter programming phase it increases the value on the display. Pressed for more than 2 seconds together with DW command, adjusts the screen contrast. Pressed once with the unit switched OFF (the display shows “oFF”) selects the operating mode: ventilation or cooling only. During the parameter programming phase it decreases the value on the display. -
Page 6: Password Protection Parameters
mode. off: ventilation mode; ▶ finally press the key to switch on the machine in the selected In ventilation mode drain is always open. PASSWORD PROTECTION PARAMETERS It is possible to lock the remote control unit to avoid unauthor- the "user" list. ised tampering. -
Page 7: Display Signals
Type Description PA - password INSTALLER parameters. Carefully read all instructions in this manual, before changing any parameters. FACTORY parameters. These parameters are usually factory preset; the default values may differ from the suggested ones. Changing these parameters may cause a bad functioning of the device. These parameters are visible only by entering the right password. -
Page 8: Electrical Connections To Electrical Panel Of Cooler Ad
To exclude the alarm set Y8=0. a time Y9, it means that there is a problem with the tank fill and the controller signal an alarm. Parameter Y9 sets the delay in signalling the alarm of empty tank; should float 1, full tank float, not change its status within To exclude the alarm set Y9=0. - Page 10 Robur mission Robur is dedicated to dynamic progression in research, development and promotion of safe, environmentally-friendly, energy-efficiency products, through the commitment and caring of its employees and partners. Robur S.p.A. advanced technologies for climate conditioning via Parigi 4/6 24040 Verdellino/Zingonia (BG) Italy +39 035 888111 - F +39 035 884165 www.robur.it robur@robur.it...
