Summary of Contents for Innovative Technology DA2
- Page 1 DA2 Installation Guide Installation Guide Pre-release Development Issue Innovative Technology Ltd Page 1 of 12...
-
Page 2: Table Of Contents
DA2 Installation Guide CONTENTS Section 1 System Requirements Page 4 Section 2 Installing your DA2 Page 4 Section 2.1 Windows 98/98SE Installation Page 5 Section 2.2 Windows 2000 Installation Page 6 Section 2.3 Windows XP (Home and Professional) Installation Page 9... - Page 3 You will have received the following items in your DA2 kit. • • USB type-A to type-B cable • DA2 to NV7/NV8 cable • DA2 CD If any of these items are missing please contact Innovative Technology Ltd to arrange for replacement. Innovative Technology Ltd Page 3 of 12...
-
Page 4: System Requirements
1.2 Hardware The DA2 is a Universal Serial Bus (USB) device. It must be connected to a USB port on your A USB type-A to type-B cable is included with the DA2. The type-A plug connects to your PC. - Page 5 Click on Next > The following screen allows you to select a method for finding the driver for the DA2. Make sure that “Search for the best driver for your device” is selected. Click on Next > Make sure that “specify a location” is checked. In the location box type “χ:\drivers”...
- Page 6 DA2 Installation Guide 2.2 Windows 2000 Before connecting your DA2 insert the DA2 CD-ROM into your PC. Once you have connected your DA2 a window open showing your PC has found a new device. When the Add New Hardware Wizard starts the following screen will be displayed.
- Page 7 DA2 Installation Guide Click on Next > When the driver has been successfully installed, the following screen will be shown. Click on Finish A second New Hardware Wizard will open. Click on Next > Make sure that Search for a suitable driver for my device is checked.
- Page 8 DA2 Installation Guide A browser window will open to allow you to select the driver’s location. In the location box type “χ:\drivers” where χ represents your CD-ROM drive letter (usually D). Click on Next > A box will be displayed indicating that the driver has been found.
- Page 9 2.3 Windows XP (Home and Professional) Before connecting your DA2 insert the DA2 CD-ROM into your PC. Once you have connected your DA2 a message bubble will appear informing you that a new device has been connected. After a few moments the Add New Hardware Wizard will start and the following screen will be displayed.
- Page 10 Windows Logo testing. Click on Continue Anyway When the driver has successfully loaded you will see the following screen. Click Finish Your DA2 is now ready for use. Innovative Technology Ltd Page 10 of 12...
-
Page 11: Verifying Installation
DA2 Installation Guide 3.0 Verifying Installation and identifying the DA2 Com Port 3.1 Windows 98/98SE/Me 1. Right Click on the My Computer icon, then select Properties. 2. Click on the Device Manager tab. 3. Locate the Port (Com & LPT) icon and click on the + sign next to it. -
Page 12: Installing Additional Da2S
4.0 Installing additional DA2s To install additional DA2s follow the instructions for installation for your Operating System. You will not need to insert the DA2 CD-ROM for additional DA2s if you are using Windows XP (Home or Professional). 5.0 Uninstalling the DA2 1.
