- Page 1 Model #: 706725 8hp Kawasaki 706925 8hp Intek 706927 11.5hp Kawasaki 706929 11hp Vanguard Starting Date: 8/2002- Walk-Behind Blower PARTS LIST AND OPERATOR’S INSTRUCTIONS...
-
Page 2: Engine Information
Recording your product information will help you as a customer save time when ordering parts or servicing your unit. It will also help Lesco Technical Support provide you with fast and timely service. -
Page 3: Safety Precautions
INTRODUCTION CAUTION: The Walk-Behind Blower should only be operated and maintained by thoroughly trained individuals. The machine can cause serious injury to anyone who misuses it or does not understand its operation. All operator’s and maintenance personnel are urged to read this entire manual for their personal safety. Note: Safety goggles and long pants should be worn when operating or maintaining this machine. -
Page 4: Engine Maintenance
OPERATING INSTRUCTIONS on the engine to “CHOKE”. Move the throttle control to halfway between “SLOW” and “FAST”. Prior to Each Day’s Use: Grasp the starter grip and pull slowly until the starter engages and then pull the cord rapidly to overcome Disconect the engine’s spark plug wire. - Page 5 Blower Handle Assembly - Figure 1 GD: 01006723-P02 Ref. No. Part No. Description Qty. 012169 Flat Washer, 5/16 013198 Hex Cap Screw, 5/16-18 x 2 083192 Idler Washer 700635 Hex Flange Lock Nut, 5/16-18 702766 Hex Flange Lock Nut, 1/4-20 706907 Upper Handle 706908 Lower Handle 706747 Cap Screw, 1.25...
- Page 6 8hp Kawasaki Engine Assembly - Figure 2 GD: 01006722-P08 Ref. No. Part No. Description Qty. 012382 Hex Cap Screw, 5/16-18, 1-1/2 012169 Flat Washer, 5/16 012470 Cable Tie, 3/16 x .05 x 7.4 700446 Hex Lock Nut, 1/4-20 700635 Hex Flange Lock Nut, 5/16-18 700898 Hex Cap Screw, 1/4-20, 2.50 701002 8HP Kawasaki Engine 706585 Hex Cap Screw, M8-1.25 x 40...
- Page 7 8hp B&S Intek Pro Engine Assembly - Figure 3 14 16 GD: 01007106-P06 Ref. No. Part No. Description Qty. 012169 Flat Washer, 5/16 012470 Cable Tie, 3/16 x .05 x 7.4 700446 Hex Lock Nut, 1/4-20 700635 Hex Flange Lock Nut, 5/16-18 700898 Hex Cap Screw, 1/4-20, 2.50 706922 8HP Briggs &...
- Page 8 11hp B&S Vanguard Engine Assembly - Figure 4 GD: 01007107-P05 Ref. No. Part No. Description Qty. 006129 Hex Cap Screw, 5/16-18, 1-3/4 012169 Flat Washer, 5/16 012470 Cable Tie, 3/16 x .05 x 7.4 700446 Hex Lock Nut, 1/4-20 700635 Hex Flange Lock Nut, 5/16-18 700898 Hex Cap Screw, 1/4-20, 2.50 706923 11HP B&S Vanguard Engine 707248 Hex Cap Screw, 5/16-24 x 1.50...
- Page 9 11.5hp Kawasaki Engine Assembly - Figure 5 GD: 01007108-P04 Ref. No. Part No. Description Qty. 006129 Hex Cap Screw, 5/16-18, 1-3/4 012169 Flat Washer, 5/16 012470 Cable Tie, 3/16 x .05 x 7.4 700446 Hex Lock Nut, 1/4-20 700635 Hex Flange Lock Nut, 5/16-18 700898 Hex Cap Screw, 1/4-20, 2.50 704877 11.5HP Kawasaki Engine 706585 Hex Cap Screw, M8-1.25 x 40...
- Page 10 706904 Housing Assembly 706906 Wire Guard 706397 Finger Guard 706629 Intake Housing 706887 Nozzle 707007 Decal, Lesco Commercial Plus 706896 Decal, Green Monster Logo 708290 17" Cast Impeller Assembly 707182 Decal, Blower Housing Rectangular 707181 Decal, Blower Housing Curved 707332 Decal, Nozzle Lesco...
- Page 11 Blower Frame Assembly - Figure 7 GD: 01006724-P02 Note 1: Use Part No. 050539 General Purpose Gun Grease Ref. No. Part No. Description Qty. 008679 Wheel, 410/350 x 4 - 2Ply 012675 Hex Cap Screw, 1/2-13 x 5-1/2 023649 Spacer, .790 ID x .347 Lg 023796 Flat Washer, .750 x 1.50 x .120 700635 Hex Flange Lock Nut, 5/16-18 700641 Carriage Bolt, 5/16-18 x 1...
-
Page 12: How To Order Parts
Labor is to be performed by the original purchaser. (LESCO will provide purchaser a labor allowance at LESCO’s current flat rate schedule.) LESCO will make the final determination as to the amount of hours to be reimbursed to the purchaser for labor. All defective parts shall be returned to LESCO if requested.
