- Page 1 300007Q QUEEN SIZE BED ASSEMBLY INSTEUCTIONS COASTER FINE FURNITURE 1 OF 4 2014-5-8...
- Page 2 Headboard 1PC Wood legs 2 PCS HARDWARE PACKAGE HARDWARE PACKAGE 5*23*67mm Allen wrench 1 PC Ø5/16 * Ø16 * Ø1.5 mm Flat washer 2 PCS Long bolt 2 PCS All above hardware pack is located in 300007Q B1 2 OF 4...
- Page 3 Footboard corner bracket 2 PCS Flat washer Ø6.5 * Ø19 * Ø2 mm 18 PCS Short bolt 18 PCS Wood screw 6 PCS Allen wrench 4*23*60mm 1 PC All above hardware pack is located in 300007Q B2 3 OF 4...
- Page 4 IT NEEDS TWO PERSONS AND TAKES ABOUT THIRTY MINUTES TO ASSEMBLE THE ITEM. STEP 1 STEP 1 Attach the wooden foot(B) to the headboard(A) and footboard(D) STEP 2 Align and attach the left and right brackets (4 and 5) to the bed rails (C) using flat washer (7) bolt (8) and tighten with allen wrench (10).
