Connections Diagram - Adcom GFA-7807 Owner's Manual

WARNING
WHENEVER CONNECTIONS TO OR FROM
THE GFA-7805 & GFA-7807 ARE BEING
MADE, BE CERTAIN THAT THE AC ON/OFF
SWITCH OF THE AMPLIFIER IS IN THE
OFF POSITION, THE AC CORD OF THE
AMPLIFIER IS DISCONNECTED FROM THE AC
WALL OUTLET AND THAT ALL ASSOCIATED
COMPONENTS ARE OFF.
LS LB
unbalanced input unbalanced input
input select input select
balanced input balanced input
output output
please visit www.adcom.com
Right Surround
Left Surround
RB RS
unbalanced input unbalanced input
input select input select
balanced input balanced input
output output
WARNING:
To reduce the risk of fire or electric shock,
CAUTION
do not expose this appliance to rain or moisture.
ATTENTION:
Pour eviter tout risque de feu ou choc electrique, ` `
RISK OF ELECTRIC SHOCK ne pas exposer cet appareil a la pluie ou a l'humidite. ` ` `
DO NOT OPEN
AVIS:
Risque de choc electrique- ne pas ouvrir. `
RF C
unbalanced input unbalanced input
input select input select
balanced input balanced input
output output
serial number
Model: GFA-7807 Power Amplifier
Power consumption (max): XXXX W
Right Front
Right Back
Left Back
LF
12VDC trigger
unbalanced input
input select
balanced input
output
AC fuse
15ABC 250V
120VAC 50/60 Hz
Left Front
Center
