- Page 1 INSTRUCTION MANUAL PICARD KETTLE MODEL BK-25N, BK-25P, BK-45N, BK-45P SERIAL NUMBER MU-BK-GA-00 16 Septembre 2014...
- Page 3 WARNINGS Purchaser must post, in a prominent location, instructions to be followed in the event the user smells gas. This information shall be obtained by consulting the local gas supplier. WHAT TO DO IF YOU SMELL GAS? 1. IMMEDIATELY CLOSE THE MANUAL GAS VALVE. 2.
- Page 5 NOTE THIS MANUAL SHOULD BE KEPT FOR FUTURE REFERENCE. STORE IT SOMEWHERE EASILY ACCESSIBLE. WARNING DO NOT SPRAY LIQUIDS OR VAPORS ON OR NEAR ELECTRICAL EQUIPMENT. DO NOT USE THIS APPLIANCE IF ANY OF ITS PARTS HAVE BEEN UNDER WATER. IMMEDIATELY CONTACT A QUALIFIED SERVICE TECHNICIAN TO INSPECT THE APPLIANCE AND REPLACE ANY PARTS OF THE CONTROL SYSTEM AND GAS CONTROL SYSTEM WHICH WERE SUBMERGED UNDER WATER.
- Page 7 REQUIREMENTS, WARNINGS AND RECOMMENDATIONS WARNING! All installation and / or service on this PICARD KETTLE must be performed by qualified, certified, licensed and / or authorized installation or technical service personnel. All electrical, gas and plumbing connections must be made by authorized technicians and in compliance with all electrical, gas, plumbing and safety requirements.
- Page 9 LABELS YOU WILL FIND ON YOUR OVEN: ATTENTION BRÛLANT C A U T I O N H O T...
-
Page 13: Table Of Contents
TABLE OF CONTENTS CONGRATULATIONS!____________________________________________________________________ Pg 15 Pg 17 INSTALLATION _________________________________________________________________________ Pg 17 EXTERNAL DIMENSIONS __________________________________________________________ GENERAL COMPONENTS __________________________________________________________ Pg 18 MINIMAL DISTANCES _____________________________________________________________ Pg 19 GAS CAPACITY AND PRESSURE ___________________________________________________ Pg 19 CONNECTION LOCATIONS ________________________________________________________ Pg 20 VENTILATION HOOD INSTALLATION ________________________________________________ Pg 21 RECOMMANDED USAGE_________________________________________________________________ Pg 22... -
Page 15: Congratulations
MANUFACTURING OVENS USING STATE OF THE ART TECHNOLGIE Rugged, efficient and easy to use, the Picard Kettle is well known for its reliability. This kettle is perfect for a wide variety of products such as bagel. - Page 16 This page has been left blank intentionally...
-
Page 17: Installation
SECTION: INSTALLATION EXTERNAL DIMENSIONS (BK-45) - Page 18 EXTERNAL DIMENSIONS (BK-25)
-
Page 19: General Components
GENERAL COMPONENTS Gas hook- up: ¾ inch NPT. Control button. Splash guard Cauldron Electrical panel Exhaust: 8” OD (203 mm) Drain: 2” NPT (BK-45) 1” NPT (BK-25) Cover Drain strainer Flame verification hole... -
Page 20: Gas Capacity And Pressure
HI – W.C. NOTE Picard gas units are manufactured to only be used with the type of gas specified on the rating plates. The installation must conform to local codes, or in the absence of local codes, to the ANSI Z223.1 / NFPA 54 (National Fuel Gas Code) CAN/CSA-B149.1 (Natural and or propane gas installation code) -
Page 21: Connection Locations
CONNECTIONS LOCATIONS GAS ENTRY CONNECTION The kettle must be connected to the gas line by flexible tubing. A gas pressure regulator that complies with ANSI Z21.18 is required and must be vented properly. A « quick connect » type connection is recommended (furnished by the client). This will facilitate moving the kettle for cleaning the walls and floors and it’s long term maintenance. -
Page 22: Ventilation Hood Installation
WARNING The Picard kettle must be interlocked with a type 2 venting hood, using a pressure or a vacuum switch (refer to the electrical diagram on page 26). A flue riser of 8” in diameter must be attached to the kettle exhaust. The top of the flue riser must be 2 feet below the hood. -
Page 23: Usage Instructions
SECTION: RECOMMENDED USAGE USAGE INSTRUCTIONS BEFORE OPERATING, smell for gas odors around the appliance. Be sure to include close to the floor because some gases, like propane, are heavier than air and will settle on the floor. START UP Connect kettle’s electric plug to a commune plug of 120V/1ph/15A. Fill the cauldron with water Turn the selector button to the “HI”... - Page 24 CONTROL PANEL OPERATION “OFF” – Turns off the burner “LOW” – Reduce the burner to low fire rate. Use this mode once the water is boiling. “HI” – Increase the burner to maximum fire rate.
-
Page 25: Général Maintenance
SECTION : GENERAL MAINTENANCE FICHE D’ENTRETIEN IT IS VERY IMPORTANT TO DISCONNECT THE POWER SUPPLY BEFORE SERVICING AND MAINTENANCE Clean the kettle in general. Client Distributor / Clean the burner pilot Certified technician Distributor / Change the burner pilot and wire Certified technician Distributor / Verify and clean the burner... -
Page 26: Cleaning
CLEANING THE KETTLE: • All cleaning of the kettle must be made without hosing or spraying. A short damp clothe can be used with the cleaning product of your choice. • Avoid liquids from dripping as they can infiltrate into the electrical and mechanical components causing short and long term problems. -
Page 27: Spare Parts
SPARE PARTS Quantity Description Part No Maintenance Reference Pilot PL69-0017 Ignition wire EL35-0006 Fuse 5 amps EL36-0006... -
Page 28: Troubleshooting
-Verify that the electrodes are clean. -Change the igniter. -Change the ignition wire. The burner goes out when it set The low fire parameters Communicate with Picard Ovens Customer adjustments are Service department to schedule a readjustment of to “LOW” position inadequate. -
Page 29: Verification List
Verification list Client: Dealer Installation date: Model: Serial Number: Circle one Gas connections already installed on site Ventilation Hood Installed Verify all buttons of control panel Do you have a pressure Indicator (U tube) Verify gas pressure is between 4 - 6 W.C for natural gas and 10 – 12 W.C. - Page 30 ELECTRIC PLANS...
-
Page 32: Limited Warranty
In the event of warranty claim or otherwise, the sole obligation of Picard Ovens shall be to repair and / or to replace equipment or equipment components, at their own discretion. Such repair or replacement shall be at the expense of Picard Ovens with the exception of travel over 100 miles or two hours, overtime and holiday charges which shall be at the clients expense. - Page 33 Warranty labor charges will be calculated and paid using reasonable normal business hours and rates. This is to say Picard will pay 8 hours labor at a regular (Monday through Friday 8a.m. to 5 p.m.) hourly rate and within a 100 miles distance.
- Page 35 S-0001 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) BK45002 (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) Fax: (819) 395-5343 14-08-19 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
- Page 36 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 BK45005 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) 14-08-14 Fax: (819) 395-5343 BK45002 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
- Page 37 S-0001 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) BK25002 (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) Fax: (819) 395-5343 14-08-19 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
- Page 38 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 BK25005 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) 14-08-14 Fax: (819) 395-5343 BK25002 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
- Page 39 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 BK00007 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) 14-08-18 Fax: (819) 395-5343 BK00006 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
- Page 40 (TOLERANCES) (DRAWING N°) (REVISION) St-Germain de Grantham x.x ±0.01" X.XXX ±0.001" (Qc) J0C 1K0 BK00006 NO° D'ASSEMBLAGE: DATE: (ASSEMBLY NO°) (YY/MM/DD) Tél: (819) 395-5151 (AA/MM/JJ) 14-08-18 Fax: (819) 395-5343 BKXX002 LES FOURS PICARD INC. / PICARDS OVENS INC. Internet: www.picardsoven.com...
