EssentialPhoto PIXAPRO COLLAPSIBLE BEAUTY DISH Assembly Instructions

PIXAPRO COLLAPSIBLE BEAUTY DISH
ASSEMBLY INSTRUCTIONS.
Step 1.
Open up the main body of the collapsible
beauty dish, and push down onto each of
the rods until they click into place.
Step 2.
Once the Beauty dish is fully opened up,
attach the Deflector, which simply screws
onto the top of the spacer rod with a small
thumb-screw.
Step 3.
To add the optional diffuser, simply attach
it to the inner edge of the Velcro strip that
goes around the internal perimeter of the
Beauty dish.
Used to reduce specular highlights.
Step 4.
To attach the optional honeycomb grid, sim-
ply press the edges of the grid the against
the Velcro strip that goes around the internal
perimeter of the Beauty Dish.
Used to narrow the spread of light.
