  • Page 1 ® DynaQ User Guide...

  • Page 2: Table Of Contents

    ONTENTS Safety Warnings ................................3 BBQ Guru Limited Warranty & Return/Repair Policy ..................... 4 DynaQ Features ................................5 Premium Dishwasher-Safe Probes ..........................5 Variable Flow Rate Power Draft Fans ..........................5 Patent Pending 5-in-1 Magnetic Control Mount ......................6 Assembling the Control Mount ..........................6 Mounting to the Monolith Grill..........................

  • Page 3: Safety Warnings

    AFETY ARNINGS READ AND UNDERSTAND THIS USER GUIDE COMPLETELY BEFORE INSTALLING OR USING THIS PRODUCT. FIRE HAZARD, BURN HAZARD! FLAMES, SPARKS AND LIT EMBERS CAN EXIT ANY OPENING ON THE PIT CAUSING FIRE! Keep the pit located a safe distance away from flammable objects including buildings, walls, solvents, cars, fuel, wood piles, and furniture, and use caution when opening the pit.

  • Page 4: Bbq Guru Limited Warranty & Return/Repair Policy

    Items must be in a condition that permits resale. BBQ Guru will not accept the following items for return: (i) items that have been personalized or customized; (ii) special order items, if not part of the BBQ Guru retail sales offering;...

  • Page 5: Dynaq Features

    NOTE: Each probe jack has an LED indicator light above it. If a probe is securely plugged into the jack while the DynaQ is powered on but the LED does not illuminate, this indicates that the probe is damaged or broken and is not reading temperature properly.

  • Page 6: Patent Pending 5-In-1 Magnetic Control Mount

    OUNT The DynaQ should be placed in a stable position in its stand. The control can be rotated to face any direction and can sit at any desired angle by tightening the mount knob. The built-in magnet allows for versatile placement.

  • Page 7: Mounting To The Monolith Grill

    2. From the underside of the lower stand platform, press the rubber feet into the holes to prevent the stand from sliding. 3. Snap the control onto the upper control bracket facing any direction. 4. Tilt the upper control bracket to the desired angle and tighten the thumb nut on the hex bolt to keep the bracket in the selected position.

  • Page 8: Real Time Visual Pit Status

    TATUS When using the DynaQ for the first time, begin by plugging in the pit probe. Follow by plugging in the food probe and the fan if they will be used before applying power. Corresponding LEDs will illuminate above the probe jacks to indicate that a probe is present.
  • Page 9 Section 10.4 Alarm Deviation. When the DynaQ is connected to power but has no pit probe connected, the outer ring will blink rapidly. This is a safety feature so the fan will not run unless a pit probe is inserted.

  • Page 10: Connecting To A Bluetooth-Enabled Device

    NOTE: If there is a brief or sustained power interruption at any time, the DynaQ will automatically restart and continue to control the pit at the same settings that were set before the interruption. NOTE: To reset the control to its factory defaults, hold down the button on the left side of the control for 4 seconds or see Section10 Using the Mobile Application.

  • Page 11: Using The Mobile Application

    If the control is paired successfully with the DynaQ, the Bluetooth LED indicator light will glow solid blue. If an error occurs during pairing, a notification will be displayed within the application and there will be a prompt to make another attempt.

  • Page 12: Ramp Mode - Patented By Bbq Guru

    10.3 R – P BBQ G ATENTED BY When Ramp Mode is on, the low and slow ramp mode is enabled to prevent food from overcooking. This feature will gradually lower the pit temperature when the food is within 30°F of being done. TIP: To allow the ramp mode to work properly, the pit temperature setpoint must be more than 30°F higher than the desired food done temperature.

  • Page 13: Alarm Deviation

    For the DynaQ to work properly and determine how to adapt, the temperature inside the pit cannot oscillate up and down, and the lid or door must stay closed. If the lid or door is opened often, particularly on startup, the control cannot be expected to maintain setpoint.

  • Page 14: Additional Features

    Normally, the DynaQ will be able to adjust the fan airflow accordingly to deliver precise control so no damper adjustment will be required. If the pit has become overfired or if the fire was built too big, large temperature swings of ±10°F or more may occur.
  • Page 15 The temperature readings and/or screen seems frozen. As soon as you are out of the Bluetooth range of the DynaQ, it will no longer be able to receive real-time temperature readings. Check if the Bluetooth LED indicator light on the DynaQ is solid blue. If it is blinking, it no longer has a Bluetooth connection.

  • Page 16: Contact Bbq Guru

    If the probe wire shows small, reddish bumps on the outside of the stainless-steel mesh braiding, the silicone insulation has started to melt out because the probe was exposed to direct flame or excessive temperatures. Purchase a new probe at bbqguru.com. 13 C BBQ G ONTACT BBQ Guru 359 Ivyland Road Warminster, PA 18974 https://bbqguru.com/ customerservice@thebbqguru.com mobileapp@thebbqguru.com...

This manual is also suitable for:

Ultraq
