Page 1 Hottap User Guide...
Page 2: Table Of Contents
Contents Warranty & support HOTTAP Register your product General information Thank you for choosing to buy a Joolca product. Storage Registered Joolca purchases come with a 2-year warranty Setting up covering parts & labour. Operation If you purchased directly from us, your items are already registered.
Page 3: Hottap
Min. water Pressure: 70kPa • The temperature of incoming water can be increased by a maximum 40ºC (e.g. if incoming water is +5ºC, HOTTAP can put out +45ºC water) Max. water Pressure: 900kPa • If you have a 12V pump (included in some kits), you can gradually Gas hose length: 1.2m...
Page 4 Lightweight feet variant 470mm 300mm Heavy duty stand variant Parts overview* HOTTAP unit 2. GasKnect snap-on fitting 3. 1.2m Gas hose 4. Lightweight feet** 5. Shower head 6. 4m shower hose 1m shower hose 8. Shower handle with switch 9. Magnetic shower handle holder 10.
Page 5: Storage
Hottap’s internal 2. Turn off your water supply and disconnect the water hoses. components. 3. Drain water from the Hottap and water hoses then pack away. For additional safety considerations, 4. If storing for extended periods, remove the 2x D-cell batteries.
Page 6 For use with the Off-Grid Plumbing kit, please refer to pages 20-21. To set up your Hottap for use, please cover the following steps: 1. Install 2 D-cell batteries observing the labelling on the battery box and the batteries.
Page 7 Setting up Hottap 3. When mounting your 3.b. Hang the Hottap on a 4. Attach the red shower Hottap, please ensure suitable vertical surface hose to the red quick- that there is sufficient connect fitting. clearance from people Connect the blue hose to...
Page 8: Operation
Hottap operation 1. Ensure that the shower 2. Turn the gas on by 3. Open the valve at your handle switch is in the “off” twisting the cylinder valve water source. Please note position. knob in an anti-clockwise that, since the shower direction one full turn.
Page 9 5. Adjust the red flame lever and the blue water flow dial switch. Flick it on: the water starts to flow and the Hottap find your desired temperature and flow rate. burner automatically ignites. Flick it off: the water flow stops higher...
Page 10: Off Grid Plumbing General Information
12V pump 2. 5m lighter port lead Open flow: 6 LPM 3. 2m intake hose Volts: 12V DC 4. 2m outlet hose 5. Two-stage filter Max pressure: 60 PSI 6. Intake collar Duty cycle: Intermittent Max amps: 5.8A USER GUIDE HOTTAP...
Page 11: Setting Up & Use
“on” position. You the water inlet and outlet. can now start and stop intake collar the pump (as well as the Hottap) simply by flicking the switch on the shower or faucet handle. great for water sources with narrow openings...
Page 12: Troubleshooting
Most technical issues can be resolved without any need for repairs. However, should you require personal advice or service, please don’t hesitate to contact Joolca Customer Support. IMPORTANT! Do not attempt to repair or modify the appliance.
Page 13 Hottap and turn on the water flow. Once complete, • Check the quality of the flame through the viewing window.
Page 14 THE FLOW OR PRESSURE SEEMS TO HAVE BEEN REDUCED • Ensure that hoses are free from kinks and debris blocking water flow. • Ensure that the HOTTAP inlet filter is free from blockages. • Ensure that your 12V battery holds a sufficient charge to power the pump.
Page 15: Safety Warnings
Check and confirm safe water temperature before using this appliance. Water from this appliance may be very hot. WEATHER WARNINGS: RAIN AND FROST Keep unit protected from rain. In cold climates, keep unit safe from frost damage by disconnecting water hoses and draining after use. USER GUIDE HOTTAP...
Page 16: Safety Instructions
Joolca the cylinder. Make sure that the • Do not use adaptors or modify is operating. Customer Support team.
Page 17 FIGURE C2 – Outdoor Area Example 5. With the open side at least 25% Example 2. Example 3. of the total wall area and 30% or more in total of the remaining wall area With both ends open. is open and unrestricted. USER GUIDE HOTTAP...
Page 18: Warranty
Safety features Joolca 2-year warranty Your Joolca appliance comes with a warranty that covers parts Overheating sensor The appliance will automatically shut down when the outlet and labour for 2 years from the date of purchase. Full terms of water reaches +50ºC.
Page 19 Require assistance? support.joolca.com...
