R.E.S.C.U.E. Remote Control Systems
American Aluminum Accessories
Please read entire instruction manual prior to starting the
R.E.S.C.U.E. Remote Control System Installation.
Special Features and Applications
Easy to Open
Unlatch and open door - at the touch of a button.
Power
Each output is 5 Amp, switched relays.
Range
Typical antenna range is 100 to 300 feet.
R. E. S. C. U. E.
R. E. S. C. U. E.
Remote Control Systems
Remote Control Systems
914 PowerTouch Remote Control Receiver With
One Key Chain Transmitter & One Oval Transmitter
Manual C841.N2
Drawing C841.N2 Rev 0 05.12.03
Rev A 09.02.03 Page 1 & 10 Only
Rev B 09.10.03 Page 1, 10, & 13 Only
Page -1-
Advertisement
Summary of Contents for American Aluminum Accessories R.E.S.C.U.E
- Page 1 914 PowerTouch Remote Control Receiver With One Key Chain Transmitter & One Oval Transmitter Please read entire instruction manual prior to starting the R.E.S.C.U.E. Remote Control System Installation. Special Features and Applications Easy to Open Unlatch and open door - at the touch of a button.
- Page 2 Manual C841.N2 R.E.S.C.U.E. Remote Control System Contents, Installation Tools, Technical Support Contents Special Features and Applications Page 1 Contents, Installation Tools, Technical Support Page 2 Specifications Page 3 Component Parts List Page 4 Operation: R.E.S.C.U.E. Remote Control Page 5 Installation: Planning Page 6, 7 Installation: Electrical - Receiver Power &...
- Page 3 Current 30 Amp Voltage 12VDC Your R.E.S.C.U.E. Remote Control System comes with a Red Lighted Toggle Switch. When installed and used properly, this WARNING! switch will deactivate the system while the vehicle is in motion. Additionally, DO NOT activate the ‘Child Safety Switch’ as this will prevent the door from opening when the transmitter button is pressed.
- Page 4 Belt Loop Holder, for oval style transmitter Optional S840.B1 Belt loop holder, for keychain style transmitter 1 kit S841.M1 R.E.S.C.U.E. - Fastener / Switch Kit 8” x 1/2” self drilling screw 1 pc SCW.7000 16g blue, butt connector 5 pcs TRM.8014...
- Page 5 Manual C841.N2 R.E.S.C.U.E. Remote Control System Operation: R.E.S.C.U.E. Remote Control System Transmitters: Press and release button Signal is sent to receiver - 1 second pulse Press and hold button Signal is sent to receiver as long as button is held. Signal will stop when button is released.
- Page 6 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Planning Test lights can cause vehicle computer damage if the wrong wires are probed and can cause the air bag systems to activate (deploy). Pay close attention to all caution labels in the vehicle. TouchTronics, Inc., will assume absolutely NO responsibility whatsoever for this, or any other damage done to the vehicle, or any personal injury due to improper installation.
- Page 7 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Planning, Continued On/Off Toggle Switch Select a place on the dash or console that is easily accessible and easily visible so that the status indicator light on the switch may be seen. Factory Door Lock Vehicle door lock circuits are factory designed as positive pulse, negative pulse or reversal rest @ ground circuits.
- Page 8 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Electrical - Receiver Power & Ground 1) Install Power Connect the Red wire to a constant +12v battery power source. Note: For best performance, run a clean +12v (14 gauge wire) directly from the battery or a fuse that is NOT supplying any power to motors, lights or any other type of high current device.
- Page 9 Manual C841.N2 R.E.S.C.U.E. Remote Control System SETUP 1: Door Open Only, Buttons 1 and 2 Open Door Battery +12vFused @ 10 Amps Empty Empty Purple Power +12v - 10 amp Ch 3 - Output, 5 amp PowerTouch Remote Control Empty...
- Page 10 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Electrical - Door Unlock / Lock Circuit Diagram 10a Diagram 10b Positive Pulse System Negative Pulse System Button ‘1’ Button ‘1’ Door Unlatch Door Unlatch Lock Lock Lock Unlock Lock Unlock Unlock Unlock...
- Page 11 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Safety Disable Switch WARNING! If using any type of motor, such as a window motor or a door lock motor - add a Disable switch to prevent the door or window circuit from operating when vehicle is in motion. (Not provided in kit) A disable switch should be installed in any application to deny operation of the motor when a vehicle is in motion.
- Page 12 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Antenna P/N: ANT.1TCBL P/N: ANT.MSTFLEX 1’ cable w/ TNC Connector Flex Whip Antenna 914 Receiver P/N: ANT.BSFLX Mounting Base P/N: ANT.4TCBL 14’ Cable w/TNC Connector & Nipple Connector for Base Antenna Installation 1) Choose location for mounting antenna; on roof of vehicle. Locate the antenna away from other antennas.
- Page 13 Manual C841.N2 R.E.S.C.U.E. Remote Control System Installation: Final Test 1) Turn power toggle switch to Off 2) Replace battery power to vehicle 3) Power toggle switch should be Off - no red light 4) Test remote control buttons a) Press vehicle unlock / lock switch All doors or rear door SHOULD unlock / lock with corresponding switch press.
- Page 14 Manual C841.N2 R.E.S.C.U.E. Remote Control System Trouble Shooting Guide - R.E.S.C.U.E. Remote Control System If a component such as the receiver or transmitter fails; DO NOT remove the entire kit. Remove ONLY the failed component for repair or replacement. Use a digital or analog voltmeter to check power and voltage! Do NOT use a test light!
- Page 15 Manual C841.N2 R.E.S.C.U.E. Remote Control System Trouble Shooting Guide - R.E.S.C.U.E. Remote Control System Use a digital or analog voltmeter to check power and voltage! Do NOT use a test light Symptom Possible Cause Corrective Action 3.0 No power to remote 3.1 Logic ground or...
- Page 16 Manual C841.N2 R.E.S.C.U.E. Remote Control System Trouble Shooting Guide - R.E.S.C.U.E. Remote Control System Symptom Possible Cause Corrective Action 5.0 Poor range 0’ to 25’ 5.2 Receiver installed in 5.2a Disconnect door and / or ramp motor and (pulsating 0’ to 25’) poor locations such as recheck range.
- Page 17 Manual C841.N2 R.E.S.C.U.E. Remote Control System TouchTronics, Inc. Warranty Policies and Procedures The following revised warranty procedures will be implemented and effective March 1, 2002. 1) All products will now be shipped with an individual bar code attached. 2) The bar code will include some or all of the following information.
- Page 18 Manual C841.N2 R.E.S.C.U.E. Remote Control System This space left blank intentionally. May be used for installation notes or drawings. Page -18-...
