- Page 1 Fremont Outswing Opener Installation Manual...
- Page 2 Thank you for choosing Real Sliding Hardware for your project! We manufacture the highest quality doors and hardware out of the best raw materials in the USA. We stand behind our products and are committed to providing an enjoyable customer experience.
-
Page 3: Table Of Contents
Table of Contents Packaging ........................4 Specifications ........................6 • Motor Carriage..................................8 • Control Unit ..................................10 System Overview ......................12 Installation Instructions ....................14 • Connecting the rails ................................14 • Chain Tensioner ................................. 14 • Wire Connector ..................................15 • Ceiling Bracket ..................................16 •... -
Page 4: Packaging
Note: not needed (16) • Connecting sleeve x2 (3) • Transmitter or remote which is preprogrammed to your opener (17) • Additional track pieces (4) Page 4 Packaging and Parts Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 5 The package dimensions are 15” x 12” x 3” This box will include: • Secondary remote for your Packaging and Parts Page 5 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
-
Page 6: Specifications
24 ft. (up to 2 x 3.59 ft. 3 x 3.59 height with ft. 4 x 3.59 ft.) (7.10 m / up to 2 x extensions 1096 mm 3 x 1096 mm 4 x 1096 Page 6 Specifications Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 7 5 seconds the force values will be deleted • 10 seconds the end position (or close) will be deleted • 30 seconds will be full factory reset Specifications Page 7 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
-
Page 8: Motor Carriage
(blue) potential free PCB label Status LED (green) LEDs opener lighting Reset button (green) MEMO slot MEMO terminal DIP switches USART slot interface Radio button (red) Page 8 Specifications Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 9 (12V/10mA) normally closed contact, potential free Output 12V/DC, max 100mA, +12 V, GND = WH, power supply for optional accessories, finger scanner or external lighting Specifications Page 9 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
-
Page 10: Control Unit
Light slot (white) Terminal for Lumi+ 2-pin Terminal power supply 120 V supplementary lighting AC 50/60 hz 2-pin Terminal Safety Sensors 2-pin Terminal wall station or wall button Page 10 Specifications Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 11 Reinstalling Control Unit Cover After working on the ceiling control unit replace the cover in reverse order. Connect the opener to the main power supply Specifications Page 11 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
-
Page 12: System Overview
(open end) 120 Volt Outlet Control Red Limit Stop Unit Housing Push Rods Motor Carriage Rail Chain Tensioner Chain Tensioner Page 12 System Overview Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 13 • It is highly recommended that you have a profressional low voltage electrician or experienced garage door installer install the Fremont Opener System Overview Page 13 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
-
Page 14: Installation Instructions
3. Proceed to slide other rails (part 4) into the bridges until they meet with the edges of Part 2 Stretch the chain across the length of the track Page 14 Installation Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 15: Wire Connector
3. Rotate the chain 90 degrees and insert into chain holder of wire connector 4. Rotate back 90 degrees Note: Do not tighten the chain on wire connector. Installation Page 15 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 16: Ceiling Bracket
6. Disengage the motor with emergency release chord 7. Unfasten screw shown (the screw is located where the arm connects) 8. Remove the slider from Page 16 Installation Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 17: Header Brackets
1 4. Secure with c-clips 15. Insert u-fitting into the swing arm attachment on both sides 16. Tighten together Installation Page 17 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 18: Push Rods
Note: that the minimum distance from the center of the rail assembly to the center of the door brackets is 3 ¾”. Page 18 Installation Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 19: Mounting Control Unit
“rt” terminal 7. Align the unit (check with level) and firmly 19. Close the housing in reverse order tighten screws with all three screws Installation Page 19 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 20: Inserting Accu (Battery Backup)
6. Set DIP switch 3 to “ON” on the control unit only 7. Plug the connection cable for the membrane keyboard back into the circuit board 8. Place control unit cover back 9. Screw on cover Page 20 Installation Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 21: Photo Eyes
Mount one safety sensor to the left and one to carriage bolt M6 (1) and tighten the wing nut the right of the door. M6 (2) Photo Eyes Page 21 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 22: Autoset Programming
Do not plug the control unit into the outlet until the installation is complete to prevent damage to the opener. The outlet may not exceed 69” away from the control unit. Page 22 Autoset Programming Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 23: Autoset
9. As soon as the programming is complete the hardware. light will remain solid and is then ready for use Autoset Programming Page 23 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 24: After Autoset Completion
1. Opener will not operate • If the motor does not operate or power up at all make sure the chain is not loose and touching Page 24 After Autoset Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 25: Accessories
5. The opener light will remain steady 8. Return the carriage and firmly press and hold 6. Second remote is programmed the desired Homelink button to be programmed Accessories Page 25 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 26: Battery Pack
MEMO and stores information • The MEMO must be remained plugged in. At any time the data can be transferred back to the internal memory or deleted Page 26 Accessories Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 27: Somweb
3. Enter 9 digit reset code 4. Press [M] button 5. Press [P] button 6. The red and amber LED lights will illuminate for 2 seconds and all codes are cleared Accessories Page 27 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... -
Page 28: Wireless Wall Control
As needed Track See below cleaning instructions As needed Cleaning See below ceiling cleaning control unit instructions and carriage housing Page 28 Maintenance and Care Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved... - Page 29 3. If applicable install the battery pack in reverse order of removal Cleaning Photo Eyes 1. Clean the housing reflectors with a moist, lint- free cloth Maintenance and Care Page 29 Real Carriage Door & Sliding Hardware Copyright 2020© all rights reserved...
