ELKHART BRASS 8599 Series Replacement Parts

8599 REPLACEMENT PARTS :
NOTE 1
1
NOTE 5
7
NOTE 3
2
NOTE 5
9
13
NOTE 1&2
16
15 & 17
USE PIPE SEALANT
NOTE 1
NOTES:
1. SECURE WITH LOCTITE#242 OR COMMERCIAL EQUIVALENT
NOTE 5
2. TORQUE SCREWS GRADUALLY USING AN X- PATTERN TO 17-18 (FT-LBS). CHECK
10
LATCH IS OPERATING FREELY & SMOOTHLY AFTER ASSEMBLY.
6
3. SECURE MAGNET USING GREEN LOCTITE #680 OR A COMMERCIAL
EQUIVALENT
NOTE 1
4. SECURE SENSOR WITH AN RTV SILICONE ADHESIVE (SENSOR SAFE) OR
4
EQUIVALENT.
5
5. LUBE WITH MEDIUM WEIGHT SILICONE GREASE DURING ASSEMBLY
PART
ITEM NO.
NUMBER
1 10844001
11
2 66677001
3 66678001
4 33409001
12
5 65555000
6 31011000 Grease Fitting (3/16 DR-SS)
7 57314000 O RING AS-568-236 3.234 X.139
14 8 57316000 O RING AS-568-242 3.984 X.139
NOTE 5
9 62157000
10 62158000
3
11 81847001
12 64125000 SCREW .375-16 X .50 LG SHCS SS
13 46054000
8 14 67568000
NOTE 5
15 10499001 ADAPTER-INLET (3"-MNPT) 8598
16 51885000
17 10498001 ADAPTER 3.0 VICTAULIC INLET
DESCRIPTION 88599001/QTY.88599011/QTY.
ADAPTER OUTLET
1
(3"MNPT) 8598
TUBE-MANUAL EXTENSION (INNER) 1
TUBE - MANUAL
1
EXTENSION (OUTER)
SCREW GUIDE/STOP 2
SPACER-STOP/GUIDE SCREW
4
0.870-OD X 0.626-ID X 0.060-THK
2
1
1
U-CUP SEAL
1
(3.375-ID X 3.750-OD X 0.188-W)
SEAL/ROD WIPER 1
LATCH SUB ASM (MANUAL EXTENDER) 1
4
MAGNET-HP 1
SENSOR, PROXIMITY
1
(MANUAL EXTENDER)
1
PLUG - PIPE
1
0.250-18 NPT S/S SOC HD
-
THIS DRAWING CONTAINS INFORMATION THAT IS
PROPRIETARY TO ELKHART BRASS MFG CO., INC.
AND MAY NOT BE USED TO PRODUCE ANY PARTS,
ASSEMBLIES OR PRODUCTS DESCRIBED HEREIN
88599001 PARTS DWG
PAGE
05/31/18
1
1
1
2
4
2
1
1
1
1
1
4
1
1
-
1
1
ELKHART BRASS
Fire Fighting Equipment
WITHOUT EXPRESS WRITTEN PERMISSION
XXXX
OF
1 3
DRAWING
Ver. 1.0
