Cost Effective Paging Horn for 70V Paging Systems
The 25AE-70V paging horn provides
economical paging coverage for 70 Volt
paging systems.
In
outdoor
factory
environments, 25AE-70V paging horns are
the
best
method
understandable
environments the directional design allows
the installer to focus the sound cone down
aisles and toward work areas.
The 25AE-70V paging horn provides a
built-in step-down transformer for use with
25V or 70V paging systems such as Viking
models PA-30, PA-60, PA-250, PA-250-IP
and PP-250. The transformer has a range
of 5 separate switch selectable power
taps, which can be used to adjust the
Features
• 5 inch diameter horn
• 10 watt power handling
• Compatible with 25V or 70V paging systems
• Adjustable base for easy mounting and
directional adjustment
• Compact design for discrete mounting
• Five switch selectable power taps
• High efficiency
• Designed to meet IP53 ingress protection
rating when mounted with horn pointing
downward at least 45 degrees from horizontal
www.VikingElectronics.com
Information: 715-386-8861
PRODUCT
MANUAL
or
warehouse
of
producing
sound.
In
these
volume of each speaker. These higher
voltage distributed audio paging systems
also have the advantage of being able to
connect more speakers using lighter
gauge wire runs while having less volume
lost in wire resistance. This saves wiring
costs compared to 8 ohm systems.
Add additional speakers and coverage areas to
existing paging systems such as Viking
models:
- PA-30 (DOD 489)
- PA-60 (DOD 493)
- PA-250 (DOD 500)
- PA-250 (DOD 500)
- PP-250 (DOD 511)
Max Power : 10 Watts
70V Power Taps: .62W, 1.25W, 2.5W, 5W, 10W
25V Power Taps: .08W, .16W, .31 W, .62W,
1.25W
Viking Taps: .16W, .31W, .62W, 1.25W, 2.5W
Connection: 12" 22 awg Pigtail wires
Dimensions: 5" (127mm) Diameter
Shipping Weight: 3.5 lbs (1.59kg)
Frequency Response: 400 Hz to 7,000 Hz
25AE-70V
70 Volt
Paging Horn
May 13, 2020
25AE-70V
Applications
Specifications
